Summary of Contents for Linn KABER AKTIV

  • Page 2 The addition of any Linn component will improve the sound quality of your system. Linn has a policy of continuously improving, its equipment allowing customers to retro-fit most product upgrades.
  • Page 3 The KABER AKTIV has been specifically optimised for the KABER loudspeaker. It cannot be used with other loudspeakers. Linn strongly recommends that it be used in conjunction with Linn power amplifiers...
  • Page 4 INSTALLATION Unpack the KABER AKTIV and retain the packing for future transportation. Your Linn Dealer is responsible for ensuring correct installation of the KABER AKTIV system. He is best placed to provide information, address your queries and resolve any problems. If this is not possible, please contact the Linn Products factory in Scotland, or your national distributor.

  • Page 5: Electrical Supplies

    SPARK power supply. Both the LK1 and the KABER AKTIV can drive up to 10 metres of Linn interconnect cable, so that the power amplifiers may be sited near the loudspeakers allowing flexibility in locating this equipment.
  • Page 6 INTERCONNECTIONS NOTE: INVERT THE PHASE BETWEEN THE POWER AMPLIFIERS AND THE SPEAKERS PRE-AMP KABER AKTIV LK280 POWER TREBLE LK280 POWER LK280 POWER BASS RIGHT KABER LEFT KABER LOUDSPEAKER LOUDSPEAKER...

  • Page 7: Operation

    Linn dealer on installation, and needs no further adjustment. If you move the system to another room, or move house, your Linn dealer will be pleased to advise on transfer and set it up in the new position.

  • Page 8: General System Installation

    LOUDSPEAKERS Loudspeakers should be positioned correctly. They should be mounted on rigid stands and not subject to any rocking movement. All Linn speakers except NEXUS and HELIX are designed to be placed very close to the wall. CLEAN CONTACTS lt is important that the electrical contacts in a hi-fi system are kept mechanically sound and clean.

  • Page 9: Maintenance

    Replace the fuse-holder, with the arrow pointing right, and snap the door shut. If the new fuse blows there is a fault and the complete unit should be returned to your Linn dealer.

  • Page 10: Guarantee And Service

    WARNING Refer all enquiries to authorised dealers only. Unauthorised servicing or dismantling of the product invalidates the manufacturer's warranty. If you are in any doubt, please contact your nearest Linn dealer. For information on your nearest dealer, contact the Linn factory in Scotland or your national distributor.

  • Page 11: Specifications

    SPECIFICATIONS DIMENSIONS Width - 320mm Depth - 326mm Height - 80mm Weight - 4kg ELECTRONIC lnput impedance: 10 Kohms Maximum source impedance: 600 ohms Output impedance: 600 ohms Typical load impedance: 5 Kohms Minimum load impedance: 2 Kohms and 10nF in parallel Nominal input level: 1 Vrms Distortion:...
