Summary of Contents for Linn RS232 KNEKT INTERFACE
- Page 1 LINN PRODUCT RS232 KNEKT INTERFACE...
-
Page 2: Table Of Contents
RS232 Knekt Interface REVISION HISTORY F:\PROJECTS\MATRIX\MANUAL\RS232KI.DOC Printed 17-Mar-00 Rev. No. Description Author Date V1.0 Initial Release Steve Wood 17 March 97 V1.1 Updated to reflect ASCII command Steve Wood 1 July 97 set of Intersekt software V1.02 beta release V1.2... - Page 3 RS232 Knekt Interface [rSTAT=p] ................................14 [rMLIS=p] ................................14 [rMCTRL=p]................................15 [rMREC=p] ................................15 [rMAIN=p]................................16 ......................... 17 NEKT ECEIVER OMMANDS [rVOL=p] ................................17 [rBAL=p]................................. 17 [rLIS=p] .................................. 17 [rMUTE=p] ................................17 [rFADE=p] ................................18 [rMONO]................................. 18 ..........................19 AJIK...
- Page 4 RS232 Knekt Interface [rMUTE=p] ................................31 [rNORM]................................. 31 [rAINP=p] ................................32 [rVINP=p] ................................32 [rDINP=p] ................................32 [rDREC=in,rout] ..............................33 [rSREC=ain,vin,rout] .............................. 33 [rROUT=p]................................33 [rSTBY=p] ................................34 [rOSG=p] ................................34 [rQUIET=p] ................................34 [rSURR=p] ................................34 RC5 C ............................35...
-
Page 5: Overview
RCU, either at the main system or in the remote room, is the responsibility of the third party controlling device. Other RCU controlled rooms in the Knekt system are unaffected, and operate both Linn and non-Linn sources in the normal way. A4 A3... -
Page 6: Installation
(Linn part PCAS187) in the remote room. The adapter routes the audio signals from its MAIN port to the Balanced Audio input of the Line receiver / Majik, and the bi-directional control signals from its REM port to the RCU port. If local Linn sources are used in the remote room, they are connected as normal. -
Page 7: Av5103 / Kairn "Hybrid" Parallel Main System
AV5103 / Kairn which are not part of the main system i.e. they do not need an associated Intersekt source. Local Linn sources (one cd and one tuner) should be connected into the AV5103 / Kairn remote in/out loop. -
Page 8: Av5103 Remote Room
REMOTE OUT/IN of the line receiver, with its audio going to an AAI of the AV5103. If no local Linn source is used, the REMOTE IN of the line receiver must be looped to its REMOTE OUT via a single phono lead. -
Page 9: System Operation
RS232 port on the Intersekt using its ASCII command language. OMMAND YNTAX The Intersekt provides a simple text-based (ASCII) command set to control and monitor the Linn equipment normally controlled by an RCU. All commands have the following generic format. Command string Parameter string... -
Page 10: Enabling Ascii Command Mode
QUIPMENT To minimises both the RS232 communications between the Intersekt and the controlling device, and the communications between the Intersekt and the Linn equipment being controlled, a two stage monitoring system has been implemented. The current “amplifier” or “source” device status is read into data buffers within the Intersekt when the system commands [rSTAT=AMP] or [rSTAT=SRC] are received, or when a command which automatically reads the current device status is received. -
Page 11: Command -Response Timing
RS232 Knekt Interface CD player has been selected as the “source” device for room eight, sending the command [?8MODE] would return the list of MODE command/parameter combinations available. OMMAND ESPONSE IMING The time interval between receiving a command and the response being returned is dependant on both the type of command, and on the individual equipment the command is destined for. -
Page 12: Example
RS232 Knekt Interface XAMPLE The following diagram shows a typical system configuration and the command/response sequence for controlling room 8 via the RS232 port of the Intersekt. A4 A3 A4 A3 A2 A1 A2 A1 LINE LINE RECEIVER RECEIVER Non Linn Control... -
Page 13: Ascii Command Tables
RS232 Knekt Interface ASCII COMMAND TABLES The following sections define the ASCII command sets provided by the Intersekt via its RS232 port. All room specific commands are preceded with “r”, representing the room number the command is destined for, and must be in the range 1 to 8. -
Page 14: [Baud=P]
RS232 Knekt Interface [BAUD=p] Sets the RS232 baud rate to the specified value. The default baud rate after power up is 9600. The RS232 port remains configured to operate with 7 data bits, 1 stop bit and even parity. Command... -
Page 15: [Rsrc=Name]
RS232 Knekt Interface [rSRC=name] Selects the “source” device command set, or returns the name of the currently selected “source” device. Command Response Description [rSRC=KARIK] !r<CR> Selects Karik/Mimik CD commands [rSRC=KRMLN] !r<CR> Selects Kremlin tuner commands [rSRC=KUDOSvalue] !r<CR> Selects Kudos tuner commands and the... -
Page 16: [Rmctrl=P]
RS232 Knekt Interface [rMCTRL=p] Connects (disconnects) room “r” to (from) the control path of an Intersekt source without affecting the current audio path, or re-connects the control path to the currently selected Intersekt audio source, if any. Command Response Description [rMCTRL=value] !r<CR>... -
Page 17: [Rmain=P]
RS232 Knekt Interface [rMAIN=p] Sets or reads if room 1 operates in parallel to main system, or as a normal room. Note that only room 1 can set the MAIN status, while any room can read it. Command Response Description [1MAIN=Y] !1<CR>... -
Page 18: Knekt Line Receiver Commands
RS232 Knekt Interface NEKT ECEIVER OMMANDS The following commands are used to control the Knekt line receiver “amplifier” device. [rVOL=p] Sets or returns the current volume level. Command Response Description [rVOL=>] !r<CR> Increase volume till stop received or 30secs elapse [rVOL=+] !r<CR>... -
Page 19: [Rfade=P]
RS232 Knekt Interface [rFADE=p] Sets the audio output fade muting status for subsequent [rMUTE=p] commands. Command Response Description [rFADE=N] !r<CR> Disable fade muting (i.e. enable abrupt muting) [rFADE=Y] !r<CR> Enable fade muting [rMONO] Toggles between stereo and mono operation. -
Page 20: Majik / Wakonda Commands
RS232 Knekt Interface AJIK AKONDA OMMANDS The following commands are used to control the Majik and Wakonda “amplifier” devices. [rVOL=p] Sets or returns the current volume level. Command Response Description [rVOL=>] !r<CR> Increase volume till stop received or 30secs elapse [rVOL=+] !r<CR>... -
Page 21: [Rrec=P]
RS232 Knekt Interface [rREC=p] Selects or returns the current audio record input. Command Response Description [rREC=A2] !r<CR> Select AUX2 record input [rREC=TU] !r<CR> Select TUNER record input [rREC=CD] !r<CR> Select CD record input [rREC=A1] !r<CR> Select AUX1 record input [rREC=T1] !r<CR>... -
Page 22: Kairn Commands [Rvol=P]
RS232 Knekt Interface AIRN OMMANDS The following commands are used to control the Kairn “amplifier” device. [rVOL=p] Sets or returns the current volume level. Command Response Description [rVOL=>] !r<CR> Increase volume till stop received or 30secs elapse [rVOL=+] !r<CR> Step up volume by 1 [rVOL=<]... -
Page 23: [Rrec=P]
RS232 Knekt Interface [rREC=p] Selects or returns the current audio record input. Command Response Description [rREC=PH1] !r<CR> Select PHONO1 record input [rREC=PH2] !r<CR> Select PHONO2/AUX2 record input [rREC=TUN] !r<CR> Select TUNER record input [rREC=CD] !r<CR> Select CD record input [rREC=AX1] !r<CR>... -
Page 24: Arik Imik Ommands
RS232 Knekt Interface ARIK IMIK OMMANDS The following commands are used to control the Karik and Mimik CD “source” devices. [rDSPLY] Scrolls through the front panel display options. Command Response Description [rDSPLY] !r<CR> Scrolls front panel display [rINDX=p] Selects or returns the current CD track index number. If the current track does not contain index coding, the command is ignored. -
Page 25: [Rsrch=P]
RS232 Knekt Interface [rSRCH=p] Searches forward or backward through the CD. Command Response Description [rSRCH=>] !r<CR> Start search forward till stop received or 30secs elapse [rSRCH=<] !r<CR> Start search backward till stop received or 30secs elapse [rSRCH=S] !r<CR> Stop search forward/backward operation [rSRCH=C] !r<CR>... -
Page 26: Kremlin Commands [Rtune=P]
RS232 Knekt Interface REMLIN OMMANDS The following commands are used to control the Kremlin Tuner “source” device. [rTUNE=p] Selects or returns the current tune frequency. A Kremlin designed for Europe or USA will accept FM frequencies (MHz) in the range 87.50 to 108.50. A Kremlin designed for Japan will accept FM frequencies in the range 75.50 to 90.50 . -
Page 27: [Rmthr=P]
RS232 Knekt Interface [rMTHR=p] Sets the mute threshold level. When the signal strength falls below the set level, the audio output is muted. Command Response Description [rMTHR=E] !r<CR> Enable mute threshold mode [rMTHR=value] !r<CR> Set mute threshold level, value = 3 to 80 [rMNO=p] Sets or returns the current mono status. -
Page 28: Kudos Commands [Rtune=P]
RS232 Knekt Interface UDOS OMMANDS The following commands are used to control the Kudos Tuner “source” device. [rTUNE=p] Selects or returns the current tune frequency. A Kudos designed for Europe will accept AM frequencies (KHz) in the range 144 to 279 (LW) and 522 to 1611 (MW), and FM frequencies (MHz) in the range 87.50 to 108.50. -
Page 29: [Rnarrow=P]
RS232 Knekt Interface [rNARROW=p] Sets or returns the current narrow function status. Command Response Description [rNARROW=N] !r<CR> Disable narrow function operation [rNARROW=Y] !r<CR> Enable narrow function operation [rNARROW=?] !rNARROW=N<CR> Return current narrow function status !rNARROW=Y<CR> [rMNO=p] Sets or returns the current mono status. -
Page 30: Circuit Switcher Commands
RS232 Knekt Interface IRCUIT WITCHER OMMANDS The following commands are used to control the Knekt Circuit Switcher “source” device. [rRLY=p] Operates or returns the status of individual relays. Command Response Description [rRLY=valueON] !r<CR> Switch relay on, value = 1 to 6 [rRLY=valueOFF] !r<CR>... -
Page 31: Av5103 System Controller Commands
RS232 Knekt Interface AV5103 S YSTEM ONTROLLER OMMANDS This section defines the ASCII command set of the AV5103 System Controller. The commands that are available depend on whether the command set was selected as an “amplifier” or “source” device. All commands are available when called as an “amplifier” device. A subset of these commands are available when called as a “source”... -
Page 32: [Rsel=P]
RS232 Knekt Interface [rSEL=p] Selects the operating mode, and automatically reads back status. After selecting a new mode, the [rSEL=?] command should be used to ensure that the new mode was successfully selected. Command Response Description [rSEL=VOL] !r<CR> Select speaker volume mode [rSEL=FRNT] !r<CR>... -
Page 33: Rainp=P]
RS232 Knekt Interface [rAINP=p] Selects an audio input without affecting the current video input, and automatically reads back status. After selecting an input, the [rAINP=?] command should be used to ensure that the input was successfully selected. Command Response Description [rAINP=NONE] !r<CR>... -
Page 34: [Rdrec=In,Rout]
RS232 Knekt Interface [rDREC=in,rout] Sets up a direct audio or video record path, and automatically reads back status. Immediately after selecting a record path, the [rDREC=?] command should be used to ensure that the record path was successfully set up. When a video input is selected, its linked audio input is also selected. If there is no linked audio input, no audio input is selected. -
Page 35: [Rstby=P]
[rSURR=AC3P] !r<CR> Selects AC-3 Phantom surround mode [rSURR=AC3S] !r<CR> Selects AC-3 3 Stereo surround mode [rSURR=LIM5] !r<CR> Selects Linn LIMBIK 5 surround mode [rSURR=LIM3] !r<CR> Selects Linn LIMBIK 3 surround mode [rSURR=PRTY] !r<CR> Selects Linn party surround mode [rSURR=NXT] !r<CR>... -
Page 36: Generic Rc5 Commands
RS232 Knekt Interface RC5 C ENERIC OMMANDS The following commands, which are only used for test purposes, provide a means of controlling “amplifier” or “source” devices with primitive (low level) RC5 commands. [rSTD=p] Sends a primitive standard RC5 command. The parameters are defined in hex, and represent the device address (aa), the command to send (cc) and the number of times to repeat the command (rr).
