- Page 1 User Manual LG EzSign TV Editor Version 1.0 - Nov. 10, 2010 www.lge.co.kr...
-
Page 2: Table Of Contents
Contents Contents Before Using What is LG EzSign TV Editor? Installing LG EzSign TV Editor System Requirements Installing LG EzSign TV Editor Removing LG EzSign TV Editor Using LG EzSign TV Editor Starting LG EzSign TV Editor Using the Quick Guide Creating EzSign TV Content 1 Choosing templates 2. Adding images 3. Entering text 4. Exporting content 10 Managing Content Saving Content on TV Memory Viewing Content on TV Viewing Content Saved in the USB Device Viewing Content Saved on the TV Memory Checking the Location of the Content Being Played Deleting EzSign TV Content from the TV Memory... -
Page 3: Before Using
Before Using Before Using What is LG EzSign TV Editor? LG EzSign TV Editor allows you to create advertising content quickly and easily by providing a wizard-type user interface. Start LG EzSign TV Editor and simply follow the wizard's steps to create and preview your own content. The content created using LG EzSign TV Editor can be played on LG EzSign TV without the need for any separate hardware or software, or it can be played along with TV programs. LG EzSign TV Installing LG EzSign TV Editor System Requirements Item Requirements Pentium M, Pentium 4 or higher 512 MB or more Network Operating System Windows XP SP2/SP3, Windows Vista, Windows 7... -
Page 4: Installing Lg Ezsign Tv Editor
ꔈ If the current version of Adobe AIR is When the LG EzSign TV Editor Wizard appears already installed on your computer, click on the screen, click NEXT. Close in the installation window. ꔈ If you do not have the current version of Adobe AIR installed on your computer, click Update for a version update. When the installation is complete, click Finish. Note ꔈ If a previous version of the program is already installed on your computer, click Yes in the pop-up window to remove it before installing the current version. All the content and pro- Note gram information stored in the previous version ꔈ If you use Windows 7 as your operating sys- will be deleted. Ensure that you save the con- tem, reboot the computer after installing LG tent you need separately before removing/re- EzSign TV Editor. installing the program. . Select the directory in which to install the pro- Removing LG EzSign TV Editor gram, and click Install. The program will be installed automatically. To remove LG EzSign TV Editor from your comput- er, click Start > All Programs > LG EzSign TV Editor > Remove LG EzSign TV Editor. -
Page 5: Using Lg Ezsign Tv Editor
Using LG EzSign TV Editor Using LG EzSign TV Editor You can easily create and play advertising content using the LG EzSign TV Editor. Starting LG EzSign TV Editor ꔈ If you do not want the Quick Guide window to appear automatically when LG EzSign TV Editor starts, click the Do not show at startup check- To start LG EzSign TV Editor, click Start > All box at the bottom left of the Quick Guide win- Programs > LG EzSign TV Editor > LG EzSign TV dow. Editor. ꔈ To see Help while using LG EzSign TV Editor, click Quick Guide at the top right of the win- Note dow. ꔈ To close LG EzSign TV Editor, click at the top right of the window. Creating EzSign TV Content Using the Quick Guide You can easily create content using default tem- The Quick Guide window appears when starting plates provided by LG EzSign TV Editor. LG EzSign TV Editor for the first time. Help is avail- able for LG EzSign TV Editor. -
Page 6: Adding Images
Using LG EzSign TV Editor 2. Adding images Select the template you want in the LG EzSign TV Editor window. (The borders of the template You can create your own content by adding the selected turn blue.) images you want to the selected template. ❶ ❷ Alternatively, click Open in the bottom left of the window to select a user template saved on your computer. ❸ ❹ ❺ ❻ ❼ ❶ Working area. ❷ Image editing area. ❸ Save the current content. Note ꔈ You can open templates saved in other directo- ❹ Save the current content with a new name. ries or content files created previously by click- ❺ Set the image conversion speed. ing Open in the bottom left of the window. Opening a content file will move you to Step "2. ❻ Go back to the previous step. Adding images". ❼ Move to the next step. . Click Template Preview in the bottom right of the window to preview the selected template. - Page 7 Using LG EzSign TV Editor . You can drag and drop the images you want. . Use the options below to edit the selected image. Replace the selected image with another. Adjust the image to show the part you want to display in the image box. Delete the selected image. Note ꔈ To change the playback sequence of the imag- es, drag them into the order you want to play them in. in Edit Photo or the image Alternatively, click box to select images saved on your computer. ⬇ By default, the image selected is aligned to the . Select the speed of the image conversion. The center and cropped according to the ratio of the conversion speed of the image is set according image box. to the option chosen. . Click Next to enter text. Note ꔈ The file formats supported for images are GIF, JPEG, PNG, and BMP. ꔈ Selected GIF or BMP files are automatically converted to JPEG files before being shown. The conversion may decrease the image quality depending on the quality of the original file. ꔈ 4-bit BMP files are not recommended due to poor quality.
-
Page 8: Entering Text
Using LG EzSign TV Editor 3. Entering text ꔈ Font type cannot be specified separately. It is set automatically according to the language set- For advertising or promotional content you can ting. enter text directly. . Click Next to export the content to a USB stor- ❶ ❷ age device. 4. Exporting content You can view the content created in LG EzSign TV Editor, or export it to a USB storage device to play it on a TV. ❶ ❷ ❸ ❹ ❺ ❻ ❶ Text entry area. ❷ Set the font size and color. ❸ Save the current content. ❹ Save the current content with a new name. ❺ ❸ ❹ ❺ ❻ ❼ Go back to the previous step. ❻ Move to the next step. - Page 9 Using LG EzSign TV Editor Go to step1 to start with the template selec- Panel Saver tion. Image sticking is when an image or outline of a . Click Save or Save As to save the content. previous image appears on the screen even after the image has changed. To prevent image sticking, . Connect the USB device to the computer to in LG EzSign TV Editor the images of the content play the content created on LG EzSign TV. are flipped and a different background color is used When the USB device is connected, the drop- for five minutes after the content is played for one down menu to select a USB storage device and hour. After five minutes, the content is played in its the Export to USB option are enabled. original format. Note ꔈ If other existing content files are found on the USB device, they are overwritten with the new content files. It is recommended to save the template before/after exporting it. ꔈ If multiple USB devices are connected, you can select the one you would like to use by clicking the drop-down menu. ꔈ If no USB device is connected, the Insert USB Memory message appears at the bottom of the drop-down menu.
-
Page 10: Managing Content
Managing Content Managing Content Viewing Content on TV The On-Screen Display (OSD) in this manual may be slightly different from your projector. You can play the content saved in the USB device Saving Content on TV Memory or TV memory on LG EzSign TV. . Insert the USB device containing the EzSign TV Viewing Content Saved in the USB content into the USB port on the television. The Device following is displayed on the TV screen. . Insert the USB device containing the EzSign TV EzSign TV Movie List Photo List Music List content into the USB port on the television. The following is displayed on the TV screen. . Select EzSign TV using the TV remote control. . Select Copy to TV memory & Play in the USB EzSign TV Movie List... -
Page 11: Checking The Location Of The Content Being Played
EzSign TV Movie List Photo List Music List on the TV memory. . The highlighted tab with the ꔐ symbol indi- Note cates the location of the file currently being ꔈ For more details on how to set and change a played. TV password, refer to the LG EzSign TV <Playing from TV memory> Manual. ꔐ TV memory EzSignTV content exists. How do you want to manage this content? Play Delete Close <Playing from USB device>...
