Product features and decorations may vary from photo above.
Instructions
Model Number: H7182
WARNING
IMPORTANT! KEEP FOR FUTURE REFERENCE.
Please read these instructions before assembly and use of this product.
Adult assembly is required. Tool needed for assembly: Phillips Screwdriver (not included).
Requires three "AA" (LR6) alkaline batteries for toy operation (not included).
www.fisher-price.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H7182 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fisher-Price H7182

  • Page 1 Product features and decorations may vary from photo above. Instructions Model Number: H7182 WARNING IMPORTANT! KEEP FOR FUTURE REFERENCE. Please read these instructions before assembly and use of this product. Adult assembly is required. Tool needed for assembly: Phillips Screwdriver (not included).
  • Page 2: Warning And Caution

    • Always keep child in view while in the high chair. • Never leave child unattended. • It is recommended that the high chair be used in the upright position only by children capable of sitting upright unassisted. This product contains small parts in its unassembled state.
  • Page 3 Parts Food Tray Electronic Toy Toy Bar 2 Teether Toys Base Tray Seat Back #10 x 2.2 cm Black Screw Hinge Rod Frame Frame Seat Bottom 2 Seat Bottom Tubes #8 x 1.9 cm Screws - 4 2 Screw Retainers #8 x 1.9 cm Screws - 2 #8 x 1.9 cm Screws - 2 Back Base...
  • Page 4 IMPORTANT! Before each use, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Mattel for replace- ment parts and instructions if needed. Never substitute parts. Electronic Toy •...
  • Page 5 Footrest Insert Screws Here #10 x 2.2 cm Black Screw - 2 • Insert two #10 x 2.2 cm black screws through the footrest and into the seat bottom. Tighten the screws. Seat Back Pin Opening Seat Bottom Assembly • Turn the seat bottom assembly upright. •...
  • Page 6 Back Base Hole Screw Retainers Back Base Hole Screw Retainer - 2 #10 x 2.2 cm Black Screw - 2 • Position a frame so that the decorated side is outward. • Insert the back leg of a frame into the back base. •...
  • Page 7 #10 x 2.2 cm Black Screw - 2 Screw Retainer - 2 Front Leg Holes • Insert the frame front legs onto the front base. • Fit a screw retainer over a hole in the front leg. • Insert a #10 x "...
  • Page 8 Seat Height Adjusters Seat Bottom Tube Ends Back and Bottom View • From the back and bottom of the assembly, insert a #8 x 1.9 cm screw through both seat height adjusters and the ends of the seat bottom tube. Tighten the screws. Assembly #8 x 1.9 cm Screw - 2 Hole...
  • Page 9 Shoulder Portion • Insert the crotch belt through the slot in the pad. Make sure the crotch belt is not twisted. • Fold the top of the pad down. • Remove the shoulder portion of the waist/shoulder belts by feeding them through the slots in the seat back. Bottom Slots •...
  • Page 10: Battery Installation

    1.5V x 3 "AA" (LR6) Shown Actual Size Battery Compartment • Loosen the screws in the battery compartment. Remove the battery compartment door. • Insert three “AA” (LR6) alkaline batteries. • Replace the battery compartment door and tighten the screws. Hint: We recommend using alkaline batteries for longer battery life.
  • Page 11: Securing Your Child

    Contact Mattel for replace- ment parts and instructions if needed. Never substitute parts. Place the high chair on a level, stable surface away from electri- cal flexes. Be sure to keep electrical flexes out of child’s reach.
  • Page 12 To change shoulder belt slots: • From the back of the high chair, push the shoulder portion of the waist/shoulder belts through the seat back slots. Securing Your Child...
  • Page 13 WARNING Prevent serious injury or death from falls or sliding out. The child should at all times wear a safety harness correctly fitted and adjusted. The tray is not designed to hold the child in the chair. • Fit the base tray onto the seat armrests. Push down until the base tray "snaps"...
  • Page 14 • While pushing the release bar on the front of the base tray, pull the tray base towards you and remove. • Fit the food tray into the base tray, as shown. Hint: Before use, thorougly wash all parts (the trays) that may contact food. Slot •...
  • Page 15: Adjusting The Seat

    Adjusting the Seat WARNING Prevent serious injury or death from falls or sliding out. It is recommended that the high chair be used in the upright position only by children capable of sitting upright unassisted. Seat Height Adjuster Press Lever...
  • Page 16 • Pull the frame release latches forward and push the rear legs toward the front legs. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052, U.S.A. ©2005 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
