23 Litre microwave oven
User manual
Model number: RHM2362S
Important safety instructions, please read carefully and keep them for future reference
For Customer Services & Spare Parts please call
0845 209 7461
Opening times: Monday – Friday 9am – 6pm & Saturday 9am – 1pm
Or visit us at www.productcareuk.com
Advertisement
Table of Contents
Related Manuals for Russell Hobbs RHM2362S
Summary of Contents for Russell Hobbs RHM2362S
- Page 1 23 Litre microwave oven User manual Model number: RHM2362S Important safety instructions, please read carefully and keep them for future reference For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday – Friday 9am – 6pm & Saturday 9am – 1pm...
-
Page 2: Table Of Contents
Contents Page About this microwave oven........Unpacking your microwave oven......Safety instructions............. Microwave oven installation........Feature diagram............Turn table installation…………………………………………….. Control panel............How to use your microwave oven......Cooking…………………………......... Additional features…………………………....... Cleaning and care............. Connection to the mains supply....... Problem solving.………..........Guarantee………………………………........ -
Page 3: About This Microwave Oven
About this microwave oven Microwaves are high-frequency electromagnetic waves similar to radio waves. While radio waves may vary in length from one metre to many kilometres, microwaves are very short (less than 12.5 centimetres). Microwaves do not make any heat themselves but only cause water molecules in food to vibrate. -
Page 4: Unpacking Your Microwave Oven
Unpacking your microwave oven Before you use your microwave oven 1. Remove all the packaging. Do not remove the small piece of card from the right hand side of the cavity wall. This is called a wave-guide cover and allows the microwaves to pass through to cook the food. -
Page 5: Safety Instructions
Safety instructions To reduce the risk of fire, electric shock, other injuries and exposure to excessive microwave oven energy, follow these basic precautions: ➢ Do not use the oven for any reason other than preparing food, such as for drying clothes, paper or any other non-food items, or for sterilising purposes. - Page 6 Safety instructions To reduce the risk of fire, electric shock, other injuries and exposure to excessive microwave oven energy, follow these basic precautions: ➢ Do not use this oven near water, in a wet basement, or near a swimming pool ➢...
- Page 7 Safety instructions ➢ Heat from the contents of a container may be transmitted to the container itself, so please be careful when removing it from the oven. Please remember that the food or liquid inside will be releasing some steam or will be spitting. Never cover any container fully, always leave a gap for steam to escape.
- Page 8 Safety instructions ➢ Food containing a mixture of fat and water (e.g. stock) should stand for 30 to 60 seconds in the oven after it has been turned off. This is to allow the mixture to settle and to prevent it from bubbling when a spoon is placed in it, or a stock cube is added. ➢...
- Page 9 Safety instructions To reduce the risk of fire in the oven cavity: ➢ Do not overcook food. ➢ Do not leave the microwave oven unattended while you are using it and if using paper or plastic containers check regularly to ensure they do not ignite. ➢...
- Page 10 Safety instructions Warning: It is dangerous for anyone, other than a qualified person to carry out any service or repair which involves the removal of the cover. This cover gives protection against exposure to microwave energy. Warning: If the door or door seals are damaged, the oven must not be operated until it has been repaired by an engineer.
-
Page 11: Microwave Oven Installation
Microwave oven installation ➢ Place on a level surface that provides enough space for the outlet vents. ➢ A minimum clearance of 7.5cm is required between the oven and any adjacent walls. One side must be open. Leave a minimum clearance of 30cm above the oven. -
Page 12: Feature Diagram
Feature Diagram Door Safety Lock System Oven Window Turntable Ring Control Panel Door Guard Glass Turntable Plastic turntable drive Wave guide cover Warning - do not use the oven when empty or for warming plates. Always keep the oven cavity, door assembly and waveguide cover clean For Customer Services &... -
Page 13: Turn Table Installation
Turn table installation ➢ Before first use, check that any securing tape has been removed from the glass tray and turntable ring assembly. These parts must never be restricted from rotating. ➢ Never place the glass tray upside down. ➢ Both the glass tray and turntable ring assembly must always be used during cooking. -
Page 14: Control Panel
Control Panel MENU ACTION SCREEN Cooking time, power, action indicators, and clock time are displayed. MICROWAVE Press this button to use the microwave function. CLOCK Press this button to set the clock. WEIGHT DEFROST Press this button for the defrost function. TIME DEFROST Press this button for the defrost function. -
Page 15: How To Use Your Microwave Oven
How to use the microwave oven Clock Setting When the microwave oven is first turned on, the oven will display "0:00", the buzzer will ring once. 1) Press “CLOCK” once. “0:00” is shown and the clock symbol illuminates. 2) Use the “TIMER/WEIGHT/AUTO” dial to adjust the hour figures, the input time should be within 0 - 23(24-hour). -
Page 16: Cooking
Cooking Microwave Cooking 1) Press the “MICROWAVE “ button once, and “P100” will be displayed. 2) Turn the “TIMER/WEIGHT/AUTO” to select the microwave power. "P100”, “P80, "P50", “P30”and, “P10” will be displayed. 3) Press “START/+30 SEC./CONFIRM" to confirm the power rating. 4)Turn the “TIMER/WEIGHT/AUTO”... - Page 17 Cooking Quick Start cooking 1) Press the "START/+30SEC./CONFIRM" button in the dial to cook with 100% power level for 30 seconds. Each press on the same key can increases the cooking time by 30 seconds. The maximum cooking time is 95 minutes. 2) During the microwave cooking process, press the "START/+30SEC./CONFIRM"...
- Page 18 Cooking Defrosting by Weight 1) Press " WEIGHT DEFROST" button once, the oven will display "d 1“. 2) Turn the “TIMER/WEIGHT/AUTO” dial to select the weight of the food. At the same time, "g" will illuminate in red. The weight should be set between 100-2000g. 3) Press the "START/+30SEC./CONFIRM"...
- Page 19 Cooking Auto Menu 1) Turn the "TIMER/WEIGHT/AUTO MENU“ dial clockwise, so that "A-1" displays on the screen. Continue to turn for the other auto selections up to A-8. 2) Press "START/+30SEC/CONFIRM" to select the chosen auto , A1-A8. 3) Turn the "TIMER/WEIGHT/AUTO MENU“ to choose the food weight. 4) Press "START/+30SEC/CONFIRM"...
- Page 20 Cooking Pasta 50 (add 450ml water) 100(add 800ml water) Potato 100% Fish Beverage 1 cup 2 cups 3 cups Popcorn...
-
Page 21: Additional Features
Additional features Kitchen Timer 1) Press " CLOCK/TIMER " twice, LED will display 00:00. 2) Use the “TIMER/WEIGHT/AUTO” dial to enter the desired time.(The maximum time is 95 minutes.) 3) Press " START/+30SEC./CONFIRM" to confirm setting. This is at the centre of “TIMER/WEIGHT/AUTO” dial. The clock button will flash as the time counts down. -
Page 22: Cleaning And Care
Cleaning and care ➢ Before you clean the oven, turn it off and unplug it. ➢ Keep the inside of the oven clean. When food or liquids stick to the oven walls, wipe with a damp cloth. We recommend that you do not use harsh detergent or abrasives. ➢... - Page 23 Cleaning and care ➢ Regularly remove the glass turntable to clean it, and wash it in warm soapy water. ➢ Ensure that the turntable support and oven floor are cleaned regularly. Simply wipe the bottom surface of the oven with mild detergent and water, then dry. You can wash the turntable support in mild soapy water.
- Page 24 Important utensil information ➢ Do not use metal pans or dishes with metal handles without food in the microwave/oven ➢ Do not use anything with a metal trim, without food in the microwave/oven. ➢ Do not use paper covered wire twist-ties on plastic bags. ➢...
-
Page 25: Connection To The Mains Supply
Connection to the mains supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of 230V – 240V ~ 50HZ. Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13A plug complying with BS1363. - Page 26 Connection to the mains supply For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which is marked with the letter E or by the earth symbol or coloured GREEN or GREEN/YELLOW.
- Page 27 Non-rewireable mains plug If your appliance is supplied with a non-rewireable plug fitted to the mains lead you will find that it incorporates a fuse, the value of which is indicated either on the base of the plug or on the fuse carrier. Should the fuse need replacing, you must use an ASTA approved fuse (conforming to BS1362) of the same rating.
-
Page 28: Problem Solving
Problem solving The microwave oven may cause interference to your radio, TV or similar equipment. If it does, you can get rid of the interference by moving the radio, TV or equipment as far away from your microwave oven as possible. If the oven doesn’t work - ➢... -
Page 29: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship, the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the store. The following conditions apply: •... -
Page 30: Technical Specification
Specifications Model Number: RHM2362 IB R1 Rated Voltage: 230V – 240V ~ 50Hz Rated Input Power(Microwave): 1250W Rated Output Power(Microwave): 800W Oven Capacity: 23 L Turntable Diameter: 270 mm External Dimensions(LxWxH): 485mmX 395mm X280mm Net Weight: Approx. 13.43 kg For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 9am –... - Page 31 Spares The following spare parts are available from www.productcareuk.com Glass turntable Turntable coupling Wave Guide cover...
-
Page 32: For Customer Services & Spare Parts Please Call 0845 209 7461
For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 9am – 6pm & Saturday 9am – 1pm or visit us at www.productcareuk.com Revision 1 This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is marked on a product/batteries, it means that the product/batteries should not be disposed of with your general household waste.
