- Page 1 IDX-803 8 Channel DMX Console 【 User Manual】 IKAN CORPORATION Website：http://www.ikancorp.com/ E-mail: info@ikancorp.com IKAN IDX-803 [EUM-A]...
- Page 2 Chapter 1. IDX-803 Instruction 1-1 Feature Standard DMX512 signal control 8 dimming control channel 8 control scene setting Chaser Function: 1.Channel chase 2.Scene chase 3.Speed control 4.Chase direction FLASH Audio control 1-2 Specification ...
- Page 3 1-3 IDX-803 Function Master Dimming Control MASTER-VR MASTER Master Flash Control Audio/Chase Speed Control SPEED/ AUDIO BLANK Pause SC/CH Scene/Channel Control Chase 1 CHASE 1~4 CHASE 5~8 Chase 2 PROG Scene/ Chase direction control Signal Display VR-1…VR-8 Set 1…8 dimming channel ...
- Page 4 1-4 IDX-803 Rear Panel Power Supply：DC 12V / 1A Power Switch Audio Input:100mV DMX Connector：XLR 5-PIN DMX Connector：XLR 3-PIN DMX Connector：PHONE JACK RJ11 1-5 IDX-803 Audio Sensitivity Control Audio Sensitivity Control IKAN IDX-803 [EUM-A]...
- Page 5 Chapter 2 IDX-803 Operation 2-1 SCENE Setting Select 【CH】 mode, and move the fader to set the dimming value Press【PROG】+【1~8】 to save control scene. STEP-1：Press【SC / CH】to select the control channel LED：OFF in CH Mode in SC Mode LED：ON...
- Page 6 ○ STEP 2 ○ ○ ○ ○ ○ ○ ● ○ STEP 3 ○ ○ ○ ○ ○ ○ ○ ● STEP 4 Repeat… STEP-3：to adjust the speeding of chase, press【SPEED】to adjust. STEP-4：Press【PROG】to change the chase direction. IKAN IDX-803 [EUM-A]...
- Page 7 STEP-5 Press【PROG】to change the chase direction 2-3-2 AUDIO CHASE STEP-1：turn 【SPEED】 key to the bottom and feel “ click “ which appointed to audio. 2-4 BLANK Press【BLANK】 for pause, and press once again back to the normal mode. IKAN IDX-803 [EUM-A]...
