T4507-93110 (603)
OWNER / OPERATOR MANUAL
POWER AUGER
AG4300
(NOTE: Drill is optional part.)
Thank you for purchasing a RedMax
WARNING
product.
Before using our power auger, please
The engine exhaust from this product
read this manual carefully to understand
contains chemicals known to the State
the proper use of your unit.
of California to cause cancer, birth
defects or other reproductive harm.
APPLICABLE SERIAL NUMBERS : 100101 and up

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AG4300 and is the answer not in the manual?

Questions and answers

Summary of Contents for RedMax AG4300

  • Page 1 T4507-93110 (603) OWNER / OPERATOR MANUAL POWER AUGER AG4300 (NOTE: Drill is optional part.) Thank you for purchasing a RedMax WARNING product. Before using our power auger, please The engine exhaust from this product read this manual carefully to understand contains chemicals known to the State the proper use of your unit.
  • Page 2: Safety First

    Read this manual carefully to understand all safety precautions, controls, proper operation and maintenance of your RedMax power auger. Failure to do so could result in serious injury. SAFETY FIRST Instructions contained in warnings within this manual marked with a...
  • Page 3: Table Of Contents

    CONTENTS 1. SAFETY PRECAUTIONS ................4 IN ORDER TO ENSURE PROPER AND SAFE OPERATION OF YOUR POWER AUGER WORK GEAR AND CLOTHING WARNINGS CONSIDERING HANDLING OF FUEL THINGS TO CHECK BEFORE USING YOUR POWER AUGER THINGS TO CHECK BEFORE STARTING UP THE ENGINE AVOID NOISE PROBLEM THINGS TO BE CAREFUL ABOUT WHEN USING YOUR POWER AUGER NOTES ON CARE AND MAINTENANCE OF YOUR POWER AUGER...
  • Page 4: Safety Precautions

    1. Safety Precautions ■ In order to ensure proper and safe • Avoid running the engine indoors. The operation of your power auger exhaust gases contain harmful carbon monoxide. • Read this Owner/Operator Manual carefully. Be sure you understand how to operate this unit properly before you use it.
  • Page 5: Work Gear And Clothing

    1. Safety Precautions ■ Work gear and clothing ■ Warnings considering handling of fuel • When using your power auger, always be • The engine of the power auger is sure to wear strong, durable, work designed to run on a mixed fuel which clothing;...
  • Page 6: Things To Check Before Using Your Power Auger

    1. Safety Precautions ■ Things to check before using your ■ Things to check before starting up the power auger engine • Before beginning work, look around • Take a careful look around to make sure carefully to get a feel for the shape of the that no obstacles exist within a perimeter land, and whether or not there are any of 15 feet or less around the power auger...
  • Page 7: Things To Be Careful About When Using Your Power Auger

    1. Safety Precautions ■ Things to be careful about when using • Never touch the muffler, spark plug, or your power auger other metallic parts of the engine while the • When using your power auger, grip the engine is in operation or immediately after handles of the power auger firmly with shutting down the engine.
  • Page 8: Notes On Care And Maintenance Of Your Power Auger

    • When replacing drills or any other parts or when replacing the oil or any lubricants, always be sure to use only RedMax products or products which have been certified by RedMax for use with the power auger.
  • Page 9: Fuel

    • These engines are certified to operate on unleaded gasoline. • Make sure to use gasoline with a • The RedMax engines are lubricated by oil minimum octane number of 89 RON specially formulated for air-cooled 2-cycle (USA/Canada: 87AL) gasoline engine use.
  • Page 10: Fueling The Unit

    2. Fuel again for at least one minute. As some 5. In the case of storing the product for a oils may be difficult to agitate depending long period of time, clean the fuel tank on oil ingredients, sufficient agitation is after rendering it empty.
  • Page 11: Operation

    3. Operation ■ INSTALLING LEFT GRIP (F1) • Screw in the left grip to the bracket provided on the frame and tighten the lock nut securely. (1) Left grip (2) Bracket (3) Lock nut ■ INSTALLING DRILL (F2) 1. Slide the ring clip and remove the lock pin from the drill.
  • Page 12: Stopping Engine

    3. Operation aspect while holding the throttle lever, and set the throttle lever in the start position. (F6) (1) Engine switch (2) Start (3) Stop (4) Choke lever (5) Open (6) Close (7) Primer pump (8) Throttle lever (9) Lock button 6.
  • Page 13: Drilling

    3. Operation hands. • A reacting motion may occur on the auger when spinning drill has hit on stones or tree roots under the ground. Always hold the auger securely to control such motion. • Start drilling with half-throttle, and gradually increase the engine speed so that the drill may get into the ground smoothly.
  • Page 14: Maintenance

    4. Maintenance Maintenance, replacement, or repair of the emission control device and systems may be performed by any non-road engine repair establishment or individual. WARNING Before cleaning, inspecting or repairing the auger, make sure that the engine has stopped and cooled down. Disconnect the spark plug terminal to avoid accidental engine starts.
  • Page 15 4. Maintenance CYLINDER FINS (F16) Dust clogging between the cylinder fins will cause overheating of the engine. Periodically check and clean the cylinder fins. (1) Intake air cooling vent SPARK ARRESTER (F17) This engine is equipped with a spark arresting screen at the exhaust port.
  • Page 16: Storage

    • Brush off dirt from the drill surface and apply rust protective oil. • Store the machine in a dry, dust-free place. 6. Specifications Model Name ........................AG4300 Engine Displacement cu.in(cc) ..................2.53 (41.5) Maximum power kW(HP) ..............1.5 (2.0) at 7000 rpm Carburetor ................Diaphragm type (Walbro WYK) ignition system ....................Electric (T.C.I)
  • Page 17: Parts List

    7. Parts list POWER AUGER AG4300 NOTE : 1. Use KOMATSU ZENOAH genuine parts as specified in the parts list for repair and/or replacement. 2. KOMATSU ZENOAH does not warrant the machines, which have been damaged by the use of any parts other than those specified by the company.
  • Page 18 7. Parts list Fig.1 ENGINE UNIT AG4300 (S/N 100101 and up) 18 ...
  • Page 19 Fig.1 ENGINE UNIT AG4300 (S/N 100101 and up) Key# Description Part Number Q'ty Key# Description Part Number Q'ty CYLINDER 848-G6D-12A0 PULLEY 4500-75210 BOLT 1850-12130 SCREW 4500-75511 GASKET,base 4500-13120 PLATE 4500-75310 CRANKCASE COMP. 4500-21101 WASHER 01643-30823 • PIN 2629-21130 INSULATOR 4500-13161...
  • Page 20 7. Parts list Fig.2 DRILL and ACCESSORY GROUP AG4300 (S/N 100101 and up) 20 ...
  • Page 21 Fig.2 DRILL and ACCESSORY GROUP AG4300 (S/N 100101 and up) Key# Part Number Description Q'ty Key# Part Number Description Q'ty 3209-11103 Gear Case Comp 3206-52200 S90 Drill Ass'y (3.5in dia.) 3209-11203 Cover Comp 3206-52220 • Tip, S90 1800-21281 Oil Seal 01225-40620 •...
  • Page 22: Limited Warranty

    ZENOAH AMERICA, INC. AT (770)-381-5147. IMPORTANT: YOU WILL RECEIVE A WARRANTY REGISTRATION CARD AT TIME OF PURCHASE.PLEASE FILL OUT THE CARD AND SEND IT TO RedMax / KOMATSU ZENOAH AMERICA WITHIN SEVEN (7) DAYS. BE SURE TO KEEP A COPY FOR YOUR RECORDS.
  • Page 23 Telles sont les limites de la garantie. Le coût du transport de l'unité jusqu'au revendeur RedMax et depuis celui-ci sera à la charge de l'acheteur. L'acheteur ne supportera pas le coût de main d'oeuvre du diagnostic qui amène à la conclusion qu'une pièce garantie est défectueuse, si ce diagnostic est effectué...
  • Page 24 KOMATSU ZENOAH AMERICA INC. 4344 Shackleford Road Suite 500 Norcross, Georgia 30093 © Printed in Japan...
