Page 1: Colour Television
Prestigio P400MW / P460MW Colour Television Owner’s Manual Please read this manual carefully before operating your set. Retain it for future reference. See the label attached on the back cover and quote this information to your dealer when you require service. -
Page 2: Table Of Contents
Picture adjustment ........... 19 Displayable Monitor ......... 43 CSM (Colour Status Memory) ....... 19 Specification ............43 PSM (Picture Status Memory) ......20 Manual Picture Control ........20 Troubleshooting ..........44 Picture format ............ 21 Check list ............. 44 PRESTIGIO P400MW / P460MW... -
Page 3: Installation
Unplug the set before cleaning the face of the LCD Screen. Dust the set by wiping the screen and the cabinet with a soft, clean cloth. If the screen requires additional cleaning, use a clean, damp cloth. Do not use liquid cleaners or aerosol cleaners. To preserve the Environment, do not rubbish. PRESTIGIO P400MW / P460MW... -
Page 4: Remote Control Handset
- COLOURED BUTTONS STILL These buttons are used for teletext freezes motion of the sub picture. (only TELETEXT models) or SCAN programme edit. switches on the programme scan mode through 4/16 sub pictures. PRESTIGIO P400MW / P460MW... -
Page 5: Battery Installation
To avoid damage from possible bat-tery leakage, remove the batteries if you do not plan to use the remote con-trol handset for an extended period time. Do not use batteries of differing age or type. Always discard of batter-ies safely. PRESTIGIO P400MW / P460MW... -
Page 6: Controls Of Front Panel
Controls of Front panel -Shown is a simplified representation of the set. -Here shown may be somewhat different from your set. -This manual explains the features available on the P400MW / P460MW series. 1. MAIN POWER 5. INPUT SELECT switches the set On or Off. -
Page 7: Connections Of Back Panel
Connect the audio/video out sockets of the VCR to AV sock- connect the euro scart socket of the VCR to these sockets. ets of the set. 9. AUDIO INPUT / COMPONENT2 INPUT (480i / 480p / 720p / 1080i / 1080p) SOCKETS PRESTIGIO P400MW / P460MW... -
Page 8: Connection To External Equipment
Use the INPUT SELECT button on the remote control to select AV1, AV2, AV3, AV4 or S-VIDEO. (If connected to S-VIDEO, select the S-VIDEO external input source.) Insert a video tape into the VCR and press the PLAY button on the VCR. (See VCR owner’s manual) PRESTIGIO P400MW / P460MW... -
Page 9: Watching Cable Tv
Audio (Left) = white, Audio (Right) = red. Use the INPUT SELECT button on the remote control to select AV1, AV2, AV3, AV4 or S- VIDEO. Operate the corresponding external equip- ment. See external equipment operating guide. PRESTIGIO P400MW / P460MW... -
Page 10: Watching Dvd
576p-50Hz, 720p-50Hz, 720p-60Hz, 1080i-50Hz, 1080i-60Hz, 1080p-50Hz, 1080p-60Hz. HDMI Interface with HDCP Copy Protection enables alldigital rendering of video without the losses. This TV SET can receive the High-Definition Multimedia Interface(HDMI) or Input of Digital Visual Interface(DVI). PRESTIGIO P400MW / P460MW... -
Page 11: Connecting Pc (Dtv)
Audio (Optical) Output port. Connect the other end of the optical cable to the digital audio (optical) input on the audio equip- ment. Note : Digital Audio Output works, when it’s inputted HDMI signal to the set. PRESTIGIO P400MW / P460MW... -
Page 12: Basic Operation
Press the > button and then use /\ / \/ button to select your desired language. All the on screen displays will appear in the selected language. Repeatedly press the MENU button to return to normal TV viewing. PRESTIGIO P400MW / P460MW... -
Page 13: On Screen Menus
Change the setting of an item in the sub or pull-down menu item. menu with < / > or /\ / \/. You can move to the higher level menu with < button and to move to the lower level menu press the > button. PRESTIGIO P400MW / P460MW... -
Page 14: Setting Up Tv Stations
VPS (Video Programme Service), PDC (Programme Delivery Control) or TELE-TEXT data. If no station name can be assigned to a station, the channel number is assigned and stored as C (V/UHF 01-69) or S (Cable 01-47), followed by a number. PRESTIGIO P400MW / P460MW... -
Page 15: Manual Programme Tuning
I : PAL I (U.K./Ireland) DK : PAL D/K, SECAM D/K (East Europe) Press the /\ / \/ button to select Channel. Press the < / > button to select V/UHF or Cable on the Channel pull-down menu. PRESTIGIO P400MW / P460MW... - Page 16 If the reception is poor at the fringe area of TV signal, select Booster to On. Press the /\ / \/ button to select Booster. Press the < / > button to select On or Off. Repeatedly press the MENU button to return to normal TV viewing. PRESTIGIO P400MW / P460MW...
-
Page 17: Programme Edit
TV viewing. If you want to select the skipped programme, directly enter the programme number with the NUMBER buttons or select it in the programme edit or table menu. Repeatedly press the MENU button to return to normal TV viewing. PRESTIGIO P400MW / P460MW... -
Page 18: Calling The Programme Table
3 Paging through a programme table There are 10 programme table pages which contain 100 programmes. Pressing the /\ / \/ or < / > button repeatedly turns the pages. Repeatedly press the MENU button to return to normal TV viewing. PRESTIGIO P400MW / P460MW... -
Page 19: Picture Adjustment
Press the > button and then use /\ / \/ button to select User. Press the 8 button and then use < / > button to make appropriate adjustments. Repeatedly press the MENU button to return to normal TV viewing. PRESTIGIO P400MW / P460MW... -
Page 20: Psm (Picture Status Memory)
Press the > button and then use < / > button to make appropriate adjustments. You can adjust picture contrast, brightness, colour, sharp-ness and tint (NTSC input only) to the levels you prefer. PRESTIGIO P400MW / P460MW... -
Page 21: Picture Format
• You can also select 16:9, 14:9, 4:3, ZOOM1, ZOOM2, SPECTACLE, AUTO in the PIP menu. • You can only select 14:9, ZOOM1, ZOOM2, SPECTACLE, AUTO in TV, AV1, AV2, AV3, AV4, S-VIDEO, COMPONENT1 [480i], COMPONENT2 [480i] mode only. PRESTIGIO P400MW / P460MW... -
Page 22: Sound Adjustment
SSM button on the remote control. The sound Flat, Music, Movie and Speech are programmed for good sound reproduction at the fac-tory and cannot be changed. When changing SSM option in SOUND menu, SRS is automatically changed to Off. PRESTIGIO P400MW / P460MW... -
Page 23: Balance
Press the > button and then use /\ / \/ button to select On or Off. Repeatedly press the MENU button to return to normal TV viewing. This feature maintains an equal volume level; even if you change channels. PRESTIGIO P400MW / P460MW... -
Page 24: Srs
Press the > button and then use /\ / \/ but-ton to select TV Speaker. Press the > button and then use /\ / \/ but-ton to select On or Off. Repeatedly press the MENU button to return to normal TV viewing. PRESTIGIO P400MW / P460MW... -
Page 25: Stereo/Dual/Nicam Reception
When NICAM stereo is received, you can select NICAM STEREO or FM MONO. If the stereo signal is weak, switch to FM mono. When NICAM dual is received, you can select NICAM DUAL I, NICAM DUAL II or NICAM DUAL I+II or MONO. When FM mono is selected the display MONO appears on the screen. PRESTIGIO P400MW / P460MW... -
Page 26: Time Menu
(disconnection or power failure), the clock must be reset. b.Two hours after the set is switched on by the on time func-tion it will automatically switch back to standby mode unless a button has been pressed. PRESTIGIO P400MW / P460MW... -
Page 27: Auto Sleep
SLEEP button once. b.To cancel the sleep time, repeatedly press the SLEEP button until the display ‘ - - - min ’ appears. c.When you switch the set off, the set releases the preset sleep time. PRESTIGIO P400MW / P460MW... -
Page 28: Setup Menu
Repeatedly press the MENU button to return to normal TV viewing. With the lock on, the display Child Lock appears on the screen if any button on the front panel is pressed while viewing the TV. PRESTIGIO P400MW / P460MW... -
Page 29: Connection Of Pc
WXGA (or VGA (Only RGB mode)) a : When the set is inputted WXGA signal, select the desired WXGA resolution. b : When the set is inputted HDMI-480p signal in VGA mode, select 480p on the SETUP menu. PRESTIGIO P400MW / P460MW... -
Page 30: Pip (Picture-In-Picture) Feature
Repeatedly press the MENU button to return to normal TV viewing. 3 Moving the PIP Press the PIP POSITION button. Press the PIP POSITION button repeatedly until desired position is achieved. The sub pictures move clockwise. PRESTIGIO P400MW / P460MW... -
Page 31: Swapping The Pip
4 Swapping the PIP Press the SWAP button to exchange the main and sub pictures. PRESTIGIO P400MW / P460MW... -
Page 32: Selecting A Input Signal Source For The Pip
This function enables you to search all the stored stationson 4 or 16 sub pictures and see your favourite station byexchanging the main and sub pictures. Press the SCAN button repeatedly to selectPOP4/POP16. The selected sub or main pictures search all the storedstations.Press the EXIT button to switch off sub or main pictures. PRESTIGIO P400MW / P460MW... -
Page 33: Teletext (Option)
3. With the green button you can proceed to the next existing page with automatic overflow to the next group. Alter- natively the /\ button can be used. 4. The red button permits to return to previous selection. Alternatively the \/ button can be used. PRESTIGIO P400MW / P460MW... -
Page 34: Direct Page Selection
To continue press this button again. Displays the teletext pages superimposed on the TV pic-ture. To switch the TV picture off press this button again. PRESTIGIO P400MW / P460MW... -
Page 35: External Control Device Setup
PC computer or other external device. Type of connector; D-Sub 9-pin male Communication Parameters • Baud rate : 4800bps (UART) • Data length : 8bits • Parity : None • Stop bit : 1bit • Communication code : HEX code PRESTIGIO P400MW / P460MW... -
Page 36: Command Reference List
Set ID to choose the desired monitor ID number. The adjustment range of Set ID is 1 ~ 99. Use this function to specify a monitor IDnumber.Refer to ‘Real Data Mapping 1’ . Command Reference List PRESTIGIO P400MW / P460MW... -
Page 37: Transmission / Receiving Protocol
Data 0 : Power Off 1 : Power On the PICTURE menu. OK Acknowledgement Transmission [F7][01][SetID][Data][CS][7F] [F6][04][SetID][Data][CS][6F] Data Min : 0 ~ Max : 64 : To show Power On/Off * Refer to ‘Real data mapping1’ . Transmission [F6][01][SetID][FF][CS][6F] OK Acknowledgement [F7][04][SetID][Data][CS][7F] PRESTIGIO P400MW / P460MW... - Page 38 Transmission 08. CSM [F6][0B][SetID][Data][CS][6F] Data Min : 0 ~ Max : 64 : To adjust colour temperature. You can also adjust CSM. In * Refer to ‘Real data mapping1’ . the PICTURE menu. OK Acknowledgement [F7][0B][SetID][Data][CS][7F] PRESTIGIO P400MW / P460MW...
- Page 39 : To select PIP Size. You can also adjust PIP Size. In the PIP menu. : To control TV Speaker On/Off of the set. You can also adjust TV Speaker. In the SOUND menu. Transmission [F6][27][SetID][Data][CS][6F] Transmission Data 0 : Small 1 : Large [F6][0F][SetID][Data][CS][6F] PRESTIGIO P400MW / P460MW...
- Page 40 OK Acknowledgement the PC Control of SETUP menu. [F7][2A][SetID][Data][CS][7F] Transmission 22. Phase [F6][2E][SetID][Data][CS][6F] Data 0 : Execute : To adjust phase. You can also adjust Phase. In the PC Control of SETUP menu. OK Acknowledgement [F7][2E][SetID][Data][CS][7F] PRESTIGIO P400MW / P460MW...
- Page 41 29. Front Light Data Min : 0 ~ Max : 63 * Refer to ‘Real data mapping1’ . : To control front light mode. You can also control Front Light. In the SETUP menu. OK Acknowledgement [F7][36][SetID][Data][CS][7F] PRESTIGIO P400MW / P460MW...
- Page 42 A F :: step 10 step 15 31: -1, 32: 0 33: 1, Left 1 Right 1 10 : step 16 64: +50, Right 50 OK Acknowledgement 64 : step 100 [F7][38][SetID][Data][CS][7F] C8 : step 200 Data 0 : Pr Up 1 : Pr Down OK Acknowledgement [F7][37][SetID][Data][CS][7F] PRESTIGIO P400MW / P460MW...
-
Page 43: Displayable Monitor
If the message “Out Of Range” appears on the screen, adjust the PC as in the ‘Displayable Monitor Specification’ section. g. Supportable resolution may vary as per graphic card. (Synchronization input form : separate) PRESTIGIO P400MW / P460MW... -
Page 44: Troubleshooting
Troubleshooting Check list PRESTIGIO P400MW / P460MW...
