IMPORTANT MANUAL
REPAIR PARTS MANUAL
MODEL:
PB22H46YT
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan-pro.com
431617
10.13.09 SR
DO NOT THROW AWAY
03032
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so
can re sult in serious in ju ry.
Printed in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Poulan Pro PRO PB22H46YT
Summary of Contents for Poulan Pro PRO PB22H46YT
- Page 1 Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so PB22H46YT can re sult in serious in ju ry. LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan-pro.com 431617 10.13.09 SR Printed in the U.S.A.
-
Page 2: Table Of Contents
HOW TO USE THIS MANUAL This manual is designed to provide the customer with a means to identify the parts on his/her tractor when ordering repair parts. The illustrations may or may not represent the actual assemblies; therefore, it is not recommended to use this manual as a guide to assemble or disassemble the tractor. Some hardware and parts are drawn larger in order to more readily identify them. -
Page 3: Schematic
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 SCHEMATIC SCH11 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) WHITE WHITE ATTACHMENT CLUTCH (CLUTCH OFF) BLACK CLUTCH/BRAKE GRAY (PEDAL UP) REVERSE SWITCH BLACK (NOT IN REVERSE) BLACK BLACK BLACK BLACK SEAT SWITCH... -
Page 4: Electrical
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 ELECTRICAL T05S With 12V Outlet Option With Service Minder Option... - Page 5 TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 ELECTRICAL PART DESCRIPTION 163465 Battery 74760412 Bolt Hex Head 1/4-20 x 3/4 186491 Box Battery 176138 Switch Interlock Push-In 183759 Harness Socket Light w/4152J 4152J Bulb Light 400253 Cable Battery 412894 Cable Starter...
-
Page 6: Chassis
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 CHASSIS chassis-tex_elite-husq_1_r2... -
Page 7: Chassis
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 CHASSIS PART DESCRIPTION 199647X428 Dash 425404X421 Hood 188264X599 Lens Grille LH 430395 Grille 188263X599 Lens Grille RH 196125 Plate Engine 17060512 Screw 5/16-18 x 3/4 414878X421 Fender 73680500 Nut Crown Lock 5/16-18 412280 Drawbar Upper... -
Page 8: Drive
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 DRIVE drive-tex_K46_pedal_53... - Page 9 TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 DRIVE PART PART DESCRIPTION DESCRIPTION 405257 Latch Brake Parking - - - - - - Transaxle, Tufftorq K46BT (Order 413430 Keeper Belt Centerspan Parts from Transaxle Manufacturer) 137057 Spacer Axle 123583X 198403X505...
-
Page 10: Engine
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 ENGINE SPARK ARRESTER KIT engine-tex_bs-2cyl_51_r1... - Page 11 TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 ENGINE PART DESCRIPTION - - - - - - Engine B&S Model No. 407777-1195-B1 149723 Muffler 194320 Keeper Belt Engine 405472 Pulley Engine 400021 Tank Fuel 430218 Cap Fuel 421473X428 Control Throttle/Choke 416358...
-
Page 12: Steering
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 STEERING ASSEMBLY 53 8 steering-tex_STDSRR_1_r2 PART PART DESCRIPTION DESCRIPTION 414851X421 Wheel, Steering 19183812 Washer 9/16 ID x 2-3/8 x 12 Ga. 73940800 Nut Hex Jam Toplock 1/2-20 unf 195968 Axle Asm., Front 188967... -
Page 13: Seat
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 SEAT ASSEMBLY seat-tex_6.5SL_1_r1 PART PART DESCRIPTION DESCRIPTION 73800500 Nut, Lock 5/16-18 unc 406623 Seat 180166 Bracket Pivot Fender 197661 Handle Slide Seat 198200 Spring Latch Seat 140675 Strap, Asm Fender 74760612 Bolt Fin Hex 3/8-16 unc x 3/4 73800600... -
Page 14: Mower Deck
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 MOWER DECK 69 69 46_tex_lt_pred_26... -
Page 15: Mower Deck
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 MOWER DECK PART PART DESCRIPTION DESCRIPTION 405049 Mower Housing 199477 Arm Brake Mower 405507 Cover Mandrel LH 405138 Linkage Brake 405506 Cover Mandrel RH 198398X428 Handle, Clutch Cable 195186 Arm Suspension 405143... -
Page 16: Decals
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 DECALS PART PART DESCRIPTION DESCRIPTION 430113 Decal, Hood 419394 Decal, Replacement 430341 Decal, Side Panel 430111 Decal, Steering Wheel 430112 Decal, Fender 160396 Decal, Mower Schematic 429556 Decal, Eng H.P . 400981X428 Pad, Footrest Control 411658... -
Page 17: Mower Lift
TRACTOR - - MODEL NO. PB22H46YT (96042010801), PRODUCT NO. 960 42 01-08 MOWER LIFT 101* lift-tex_22 *Key 91 may be substituted for Key 101 PART PART DESCRIPTION DESCRIPTION 422027 Shaft Asm., Lift 17000612 Screw 3/8-16 x .75 Smgml Tap/R.Z 195231 Lever Asm., Lift RH 195270 Link Lift Susp. -
Page 18: Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
