Page 1: Parts Manual
Parts Manual MODEL 301ZX / 966681701 Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. - Page 2 When you need spare parts or support in service questions, warranty issues, etc., please consult the following professional: This Parts Manual belongs to the machine with the Engine Transmission manufacturing number: Manufacturing Number The machine’s manufacturing number can be found on the printed plate affixed to the engine compartment.
-
Page 3: Table Of Contents
CONTENTS FRAME ..............4 ENGINE PLATE ............6 STEERING ..............8 IGNITION SYSTEM ..........10 HYDRAULIC PUMP / MOTOR ........ 12 WHEELS / TIRES ............ 14 BRAKE / DECK LIFT ..........16 MOWER DECK / CUTTING DECK ......18 SEAT ............... 20 DECALS .............. -
Page 4: Frame
FRAME... - Page 5 FRAME ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 525 454704 ..1 ..FRAME TUBE, LH YLW 23.. 539 976938 ..4 ..HCS -18 x 2¼ 2.. 525 454904 ..1 ..FRAME TUBE, RH YLW 24.. 539 990629 ..8 ..HCS -16 x 2¼...
-
Page 6: Engine Plate
ENGINE PLATE Torque to 55-75 ft-lbs... - Page 7 ENGINE PLATE ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 539 120812 ..1 ..PULLEY, IDLER 11.. 532 120616 ..3 ..SCREW -16 x 1 THD FRM 2.. 574 872801 ..1 ..PULLEY, ENGINE 12.. 539 990188 ..3 ..WASHER SAE FLAT 3..
-
Page 8: Steering
STEERING... - Page 9 STEERING ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 539 117949 ..1 ..STOP, STEER CNTRL RH 17.. 539 101332 ..2 ..HCS ½-13 x 2¾ 2.. 539 117950 ..1 ..STOP, STEER CNTRL LH 18.. 539 976937 ..2 ..HCS -18 x 2 3..
-
Page 10: Ignition System
IGNITION SYSTEM... - Page 11 IGNITION SYSTEM ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 539 120193 ..1 ..FENDER, RH 24.. 539 912222 ..4 ..CLAMP, HOSE 2.. 539 120192 ..1 ..FENDER, LH 25.. 575 436501 ..2 ..CLAMP, HOSE 3.. 539 107541 ..1 ..SWITCH, IGNITION 26..
-
Page 12: Hydraulic Pump / Motor
HYDRAULIC PUMP / MOTOR... - Page 13 HYDRAULIC PUMP / MOTOR ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 539 120152 ..1 ..HYDRO, RH 12.. 539 976988 ..2 ..HAIRPIN COTTER 2.. 539 120153 ..1 ..HYDRO, LH 13.. 539 976938 ..2 ..HCS -18 x 2¼ 3..
-
Page 14: Wheels / Tires
WHEELS / TIRES 19 21... - Page 15 WHEELS / TIRES ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 575 812201 ..2 ..CASTER TIRE ASSY 12.. 539 102535 ..2 ..CAP, GREASE 2.. 510 186504 ..2 ..YOKE, CASTER YLW 13.. 539 115749 ..2 ..PLUG, CASTER 3..
-
Page 16: Brake / Deck Lift
BRAKE / DECK LIFT... - Page 17 BRAKE / DECK LIFT ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 525 580402 ...1 ..HANDLE, LIFT BLK 15.. 539 115658 ..2 ..L-ROD 3½" 2.. 525 580604 ...1 ..SHAFT, LIFT BLK 16.. 539 976988 ..4 ..HAIRPIN COTTER 3..
-
Page 18: Mower Deck / Cutting Deck
MOWER DECK / CUTTING DECK... - Page 19 MOWER DECK / CUTTING DECK ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 574 453403 ..1 ..DECK w/ SFTY DECALS BLK 27.. 532 415598 ..1 ..WASHOUT PORT 2.. 574 173002 ..1 ..BELT, DECK 28.. 539 976988 ..1 ..HAIRPIN COTTER 3..
-
Page 20: Seat
SEAT... - Page 21 SEAT ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 522 598901 ..1 ..SEAT 6.. 532 198200 ..1 ..SPRING, SEAT SLIDE 2.. 539 132140 ..1 ..SWITCH, SEAT N/C 7.. 539 110303 ..2 ..BOLT, -SHOULDER 3.. 525 580005 ..1 ..PLATE, SEAT YLW 8..
-
Page 22: Decals
DECALS... - Page 23 QTY. DESCRIPTION 1.. 525 798501 ..1 ..DECAL, BELT ROUTING 11.. 575 934802 ..1 ..DECAL, POULAN LT 2.. 539 109908 ..1 ..DECAL, SAFETY GRAPHICS 12.. 576 967501 ..1 ..DECAL, CONTROL PANEL 3.. 539 113213 ..1 ..DECAL, WARNINGS 13..
- Page 24 P/N 115 394227R1 08/12/10...
