Fantec HDC portable User Manual

Copy station
Hide thumbs

Advertisement

Quick Links

Download this manual
FANTEC
HDC Portable

USER Manual

Version 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the HDC portable and is the answer not in the manual?

Questions and answers

Related Manuals for Fantec HDC portable

Summary of Contents for Fantec HDC portable

  • Page 1: User Manual

    FANTEC HDC Portable USER Manual Version 1.0...
  • Page 2 DC-IN • ON OFF • Source 1 • Source 2 ENT RESET ESC• MUTE • Object 2 • Object 1...
  • Page 3 • Sou rce 1 • S ource 1 • S ource 2 • S ource 2 ENT RESET ENT RESET ESC• MUTE ESC• MUTE • Object 2 • Object 2 • Object 1 • Object 1...

  • Page 4: Operating System

    1. Feature IDE/SATA HDD portable copy-station for all 2.5”&3.5” HDD. USB2.0 Raid bridge external station for all 2.5”&3.5” HDD. Duplicator mode: Copy/Compare/Pre-scan/Erase. Raid mode: Raid0/Raid1/Normal/JBOD. Easy handling over display Stand alone usage without PC(Duplicator mode). 2. Operating System Windows 98SE/2000/XP/Vista, Mac, Linux 3.Package Contents 1 x Copy station 1 x USB cable...
  • Page 5 6. System Mode (1). Duplicator Mode 1. Copy HDD Clone the boot sectors from the source HDD to the object HDD. 2. Compare HDD Compare the sectors of the source HDD to the object HDD. 3. Pre-scan Pre-scan the bad sectors of the source HDD. 4.
  • Page 6 5. Duplicator operating (1) Press the ▲ and ▼ button to select the Menu, and press the ENT Button to enter the next step. (2) For example, the display show the HDD copy information. 6. Raid operating (1) Press the ▲ and ▼ button to change the raid mode.
  • Page 7 (2) Press the ENT button to enter the next step. (3) Press the ENT button to ensure change the mode. (4) Show the raid information.
  • Page 8 5 Click the My Computer , right-clicking pop-up menu, click the Options Management , select the Computer Management , then you can operate the hard disk in your PC. The hard disk information as following, Normal mode...
  • Page 9 JBOD mode RAID0 mode...
  • Page 10 RAID1 mode...
  • Page 11 (6) RAID1 HDD Rebuild. When the system in RAID1 mode, if one HDD has broken, the system will rebuild automatically as following, 1. If the Raid1 system is broken, the “F” will be show as following, and the buzzer will alarm once per second. 2.
  • Page 12 4. Insert a new HDD, and retsart the system, the system will prompt you rebuild the Raid1 system. 5. The display will show the rebuild speed, spare volume and the spare time.
