PMC-Sierra MSP7162 GPON RG Specifications

MSP7162 GPON RG
Fiber Access Residential Gateway

Product Overview

The MSP7162 Fiber Access Residential Gateway is a second gener-
ation device that combines PMC-Sierra's multi-service 7100 Series
architecture with proven GPON ONT technology for low-cost,
high performance GPON FTTH CPE gateways. It supports an
integrated GPON subsystem, multiple 10/100/1000BaseX MACs,
dual USB 2.0 interfaces, and a DDR2 memory interface. A Linux
software development kit (SDK) that includes voice processing
and GPON management modules are included to streamline
application integration and quicken time to market.
This multifunction residential gateway processor addresses carrier
service delivery needs by simultaneously providing superior data
path performance, application processing, and robust voice
processing in a cost/performance efficient implementation. Its 600
MHz multithreaded 7100 Series core dynamically allocates
resources between voice, video, and data processing services, to
guarantee consistent, high-quality broadband networking perfor-
mance. It supports gateway designs that enable a service-grade
digital home with the gigabit boost required for IPTV.
Its superior packet processing and WT-156–compliant quality of
service (QoS) performance, with advanced remote management
capabilities, addresses continuously evolving digital home use-
cases, and provides carriers the ability to control in-home service
distribution which is essential for a high-value consumer
experience. This powerful engine provides the necessary perfor-
mance and connectivity for service revenue-generating
broadband portals.
The MSP7162 is a multithreaded SoC that shares the MSP7100
Series architecture and Linux-based embedded software. Its ITU-T
G.984 GPON ONT-standard interoperability is compatible with the
MSP7160 GPON RG.
Benefits
The MSP7162 is a second generation device combining a proven
GPON core and SoC. It provides exceptional simultaneous
processing behaviors, which are essential for fiber access
gateways to support triple-play and the evolution to true multi-
service deployments.
PMC-Sierra's residential gateway solution delivers concurrent
complex traffic management, routing, bridging, and firewall tasks
with processing power to guarantee voice, video, and data service
quality. These simultaneous processing capabilities ensure critical
quality of experience (QoE) for all broadband service deploy-
.
ments
PMC-2080747, Issue 1
Copyright © 2008 PMC-Sierra, Inc.
All rights reserved. Proprietary and Confidential to PMC-Sierra, Inc. and for its customers' internal use.
• The 600 MHz multithreaded MSP7100 Series core
achieves industry-leading processing power
• Guaranteed flexible networking performance
Multi-function
with a significant throughput improvement
core provides
compared to single-threaded processors
exceptional
processing
• Dynamic reassignment of processing cycles
power
between diverse functions of the multi-service
digital home with cycle guarantees for robust QoE
• High integration and RBOM optimization
• Based on the field-proven PMC Chicago solution
Full ITU-T G.984
leveraging the ITU-T G.984 GPON MAC
GPON ONT
interoperability
• Supported by a comprehensive software package
• Simultaneous 2.488 Gbit/s downstream and 1.244
Gbit/s upstream sustained PON traffic throughput
at any packet size
GigaPASS Wire-
• Provides essential headroom to address
speed
requirements for evolving services, service
performance
bandwidth, and digital home infrastructure:
stronger management/control, interworking of
HAN technologies for end-to-end QoS and
gateway application processing
• Supports classification, mapping, and filtering,
Advanced
according to L2/L3/L4 fields, double-tagged
classification
VLANs, MLD and IGMP multicast
engine
• Data path processing compliant with DSL forum
Working Text WT-156 at Gigabit rates.
Advanced QoS • Flexible queuing features enable queuing per
features to user/service with per-queue WFQ/SP scheduling,
maintain shaping, and policing
Gigabit
• Provides exceptionally fast networking
throughput
performance to leverage the full potential of next
generation access networks and ultra-high speed
home networking technologies.
• Greater packet processing permits advanced QoS
Multi-service
features for robust service delivery, for high
networking service bandwidth and guarantees for service
growth
• VoIP Terminal Adapter functionality is
guaranteed, independent of all other processing
and traffic conditions
Robust voice
processing
• Centralized voice processing enables resources to
be dynamically allocated to other functions
without influence from software
• Leverages standard tools and a large software
Programmer- ecosystem with best-of-breed components
friendly support
programming
• Linux-based software stack
model
• Open MSP7100 Series programming model
Preliminary Product Brief
