Euromaid MT70 Installation And Operation Manual

600mm built-in
Hide thumbs
Table of Contents

Advertisement

Quick Links

600mm
Built-In Oven
Manual
MODEL
MT70
Installation and Operation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Euromaid MT70

Summary of Contents for Euromaid MT70

  • Page 1 600mm Built-In Oven Manual MODEL MT70 Installation and Operation...

  • Page 2: Using This Manual

    MT70 Installation and Instructions of use  Using This Manual This Owner’s Manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this Owner’s Manual before using your oven and keep this book for future reference.

  • Page 3: Child Safety

    MT70 Installation and Instructions of use  Safety during operation (Continued)  When cooking dishes that contain alcohol, the alcohol may evaporate due to the high temperatures and the vapour can catch fire if it comes into contact with a hot part of the oven. ...
  • Page 4 MT70 Installation and Instructions of use  Cleaning Safety WARNING Make sure the oven is cool before cleaning. We recommend turning the oven off prior to cleaning Clean and user maintenance shall not be made by children without supervision Do not clean the appliance while it is still hot. Some cleaners produce noxious fumes when applied to a hot surface. Wet cloths or sponges can cause burns from steam.

  • Page 5: Disposal Instructions

    MT70 Installation and Instructions of use  Cleaning Safety (Continued) Catalytic Liners (removable) - enamel surface The removable cover casing is coated with a dark gray catalytic enamel that can become coated with oil and fat distributed by circulating air during convection heating. These deposits will burn off at oven temperatures of 200 °C and higher, for example, when baking or roasting.
  • Page 6 MT70 Installation and Instructions of use  Installing the Oven Electrical installation of this appliance must be performed only by a licensed electrician. The oven must be installed according to the instructions supplied. Remove the protective vinyl from the door after installation. Safety instructions for the installer ...
  • Page 7 MT70 Installation and Instructions of use  Connecting to the mains power supply Electrical connections must be made as per the connection plate fixed to the back of the appliance by an approved electrical fitter who must ensure that the appliance has been connected in accordance with fitting instructions and local regulations.
  • Page 8 MT70 Installation and Instructions of use  Tower Installation (Figure 1 below) Figure 2 shows the product dimensions of this oven and the housing must be constructed to fit the oven. The oven should be slid into place at the proper angle of alignment. Minimum carcass dimensions are outlined in Figure 3 to house the oven. The front fascia of the oven rests against the front edges of the carcass.
  • Page 9 Shelf levels are numbered from the bottom up. Levels 4 and 5 are used mainly for the grill function. Please refer to the cooking guides provided throughout this manual to determine appropriate shelf levels for your dishes. NOTE: Rotisserie function is not available on the MT70 Oven controls 1.
  • Page 10 MT70 Installation and Instructions of use  How to set the oven for roasting when using the probe  Insert the probe into the meat. Ensure the probe does not touch any bone as this this can affect the desired result.  Plug the probe into the outlet in the oven. Make sure it is pushed all the way in. If the Probe is inserted correctly, will show on the display.

  • Page 11: Cooling Fan

    MT70 Installation and Instructions of use  If you hear two beeps after inserting the divider, that means you can use divider function. When you take out the divder, two beeps means this fuction can not be used. The baking tray, deep pan and wire grill should be inserted correctly into the side runners.

  • Page 12: Initial Cleaning

    MT70 Installation and Instructions of use  Before You Begin Setting the clock When power is first supplied to the oven, the display on the control panel will light briefly and 0:00 will begin blinking in the display. The oven cannot be operated until the clock is set.
  • Page 13 MT70 Installation and Instructions of use  Food Item Shelf Level Temperature （ ) Accessory Time(min) Pork on bone cutlets Wire grill/ 40-50 (500-1000g) Baking tray DROP OIL,ADD SALT& (for juice PEPPER catching) Baked potato 180-200 Baking tray 30-45 (cut in half) (500-1000g) Meat roll 180-200...
  • Page 14 MT70 Installation and Instructions of use  Food Item Shelf Level Temperature ( ) Accessory Time(min) Pork shoulder in foil 180-230 Baking tray 60-120 (1000-1500g) Better marinate meat Whole chicken 190-200 Baking tray 40-55 (700-1500g) DROP OIL,ADD SALT&PEPPER Meat or fish steaks 180-200 Baking tray with a...
  • Page 15 MT70 Installation and Instructions of use  4. Large Grill (Suggested temperature: 240 °C) The large grill function grills large quantities of flat foods, such as steaks, schnitzels and fish. It is also suitable for toasting. Both the top outside element and the top inside element are on in this mode with the divider removed.
  • Page 16 MT70 Installation and Instructions of use  Fish burger frozen 180-200 Baking tray 20-35 (300-600g) PUT IN COLD OVEN ,DROP Pizza frozen 180-200 Baking tray 23-30 (300-500g) PUT IN COLD OVEN (before preheat) 6. Bottom Heat + Convection (Suggested temperature: 190 °C) The Bottom Heat + Convection mode is for recipes calling for a moist topping and a crisp base, as with foods like pizzas, quiches lorraine, German-style open fruitcakes and cheese-cakes.
  • Page 17 MT70 Installation and Instructions of use  Variant 1 PARTITION Food Item Shelf Cooking Temperature Accessory Time Level Mode (min) UPPER OVEN Meat or fish Top-heat+ 180-200 Baking tray 15-35 Steaks convection with wire (400-800g) roast on top DROP OIL,ADD SALT&PEPPER LOWER Yeast dough pie Bottom Heat+...

  • Page 18: Oven Use

    MT70 Installation and Instructions of use  Seafood Fish whole (1360 to 2270g) Lobster Tails (170-230g each) Poultry Whole Chicken 80-85 (1134 to 1588g) Cornish Hens Unstuffed (453-680g) 80-85 (Stuffed 453-680g) 80-85 Ducking 80-85 (1800-2270g) Turkey, whole* Unstuffed (4536-7260g) 80-85 Unstuffed (8165-10890g) 80-85 Turkey Breast (1814-2720g)
  • Page 19 MT70 Installation and Instructions of use  Upper mode The divider should be inserted. Convection Top Heat + Convection Large Grill Lower mode The divider should be inserted. Convection Bottom Heat + Convection Twin mode The upper and lower modes operate at the same time. It is possible to set which mode activates first. When one of the dishes has finished cooking in twin mode and you would like to change the cooking time or...
  • Page 20 MT70 Installation and Instructions of use  Single mode (continued) Conventional Large Grill Small Grill Bottom Heat + Convection Defrosting...

  • Page 21: Setting The Oven Temperature

    MT70 Installation and Instructions of use  Setting the oven temperature In single, upper and lower modes 1 Press the Temperature Button and hold for about 2 seconds,the tempreture will flash . 2 Turn the Time / Temp/Function Control Knob to adjust the temperature in increments of 5 °C.
  • Page 22 MT70 Installation and Instructions of use  Setting cooking end time You can set the end time during cooking. In single、upper and lower modes 1.Press the Time Button several times untill the end time icon and the three digits on the display begin to flash. 2.Turn the Time / Temp /Function Control Knob to set the desired end time.
  • Page 23 MT70 Installation and Instructions of use  Setting a cook time (continued) In twin mode 1.Press the Time Button several times untill the cook time icon and the three digits on the display begin flash（upper or lower）. 2.Turn the Time / Temp/Function Control Knob to set the desired cook time.

  • Page 24: Checking The Temperature

    MT70 Installation and Instructions of use  Checking the temperature ● Press the Temperature Button and Time Button at the same time to check the tempreture of the upper test probe. ● Press the Temperature Button and upper and lower exchange Button to check the tempreture of the lower test probe.

  • Page 25: Attaching The Door

    MT70 Installation and Instructions of use  Attaching the door 1. With the clips still flipped open, align the door hinges into the hinge holes. 2. Rotate the door toward the horizontal line and flip the clips closed. Disassembling the door 1. Detach the glass 1# from the door with both hands;...
  • Page 26 MT70 Installation and Instructions of use  Disassembling the door (continued) 3. Loose the Embedding stirp; Clean the sheets with warm water or washing-up liquid and polish dry with a soft clean cloth. Assembling the door Reassemble the door by following the above procedures in Reverse order.

  • Page 27: Warranty And Service

    MT70 Installation and Instructions of use  Warranty & Service Refer to separate warranty sheet for terms and conditions of the warranty on your applaince FAQs and Troubleshooting What should I do if the oven doesn’t heat up? Check to see if one of the following actions resolves the issue: ●...

  • Page 28: Technical Data

    MT70 Installation and Instructions of use  Error and Safety codes Error and Safety codes General Functions Solution Er 3 or Er 4 TEMP SENSOR ERROR Call local service centre Er 0 COMMUNICATION FAILURE Call local service centre Technical data Model MT70 Power Source 220-240V ~50/60Hz...
