- Page 1 OWNER’S MANUAL Room Air Heat Pump with R-410A: RAH-183G Heat Controller, Inc. • 1900 Wellworth Ave. • Jackson, MI 49203 • (517)787-2100 • www.heatcontroller.com...
-
Page 3: Table Of Contents
Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual Comfort Zone Room Air Conditioner & Heat Pump Use and Care Manual Contents Introduction ............. 1 Introduction ..............1 Safety Information ..........1 Safety Information ............1 Normal Care & Maintenance ........2 Electrical Requirements .......... -
Page 4: Electrical Requirements
Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. WARNING WARNING To avoid death, personal injury or property HIGH TEMPERATURE STRESS HAZARD damage due to electrical shock: This room air conditioner is not meant to • Observe all local codes and ordinances. -
Page 5: Normal Care And Maintenance
Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual Room Heat Pumps Unit Plug Receptacle Circuit Rating, Voltage Room Heat Pumps Unit Plug Receptacle Circuit Rating, Voltage... - Page 6 Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. Front Grille and Filter Removal Optional Air Filter Installation The front contains a removable grille that provides easy Remove air filter from plastic bag. Insert three tabs access to the air filter. To clean the filter use one of the on right side of filter into three slots on filter frame.
-
Page 7: General Operating Instructions
Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual from outer case. Use both hands to grasp basepan and Drain Cup Installation and Use (on some models) pull remaining chassis from outer case. Your air conditioner uses a system where the water removed from the indoor air (condensate) is channeled to the outdoor side of the unit. -
Page 8: Installation Instructions
IMPORTANT Observe all governing codes and ordinances. Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. Note to Installer Be sure to leave thes e instructions with the Consum er. TOOLS YOU WILL NEED Installation... - Page 9 Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual Installation Instructions PARTS INCLUDED Window (A ppearance m ay vary) sash seal Left accordion panel Foam top window gasket mounting rail Right accordion panel V-support (2) Window locking Bolt (2) & nuts (2)
- Page 10 Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. Installation Instructions WINDOW REQUIREMENTS REMOVE THE AIR CONDITIONER FROM THE CASE These instructions are for a standard double-hung window. You will need to Remove the locking screw and locking Remove the locking screw and lock- modify them for other types of windows.
- Page 11 Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual Installation Instructions PREPARE THE CASE INSTALL THE CASE IN THE WINDOW Install the top mounting rail with 4 type B screws from the inside of the case. Carefully slide the case into the window and center the case.
- Page 12 Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. Ins tallation Ins tructions INSTALL SUPPORT BRACKETS INSTALL THE CASE INSTALL SUPPORT BRACKETS AND TOP WINDOW FOAM GASKET IN THE WINDOW (cont.) AND THE FOAM TOP WINDOW GA S K E T...
- Page 13 Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual Ins tallation Ins tructions INSTALL THE AIR CONDITIONER INS TALL THE AIR CONDITIONER INSTALL THE AIR CONDITIONER IN THE CASE IN THE CASE IN THE CASE (cont.) IN THE CASE (cont.)
-
Page 14: Operating Controls
Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. Operating Controls( For Electronic units Controls Operating your air conditioner properly helps you to obtain the Operating Controls(... - Page 15 Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual Cooling Descriptions Timer/Delay OFF— When the air conditioner is on, TIMER OFF—When the air conditioner is on, it can be set to automatically turn off in 0.5 to For Normal Cooling—Select the Cool mode and High or Med fan with a middle set temperature.
-
Page 16: Vent Control
Slide this control to the left for a warmer room temperature, before to the right for a cooler room temperature. Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. the fan d dehu- Vent Control s setting Choose one of the following two settings by sliding the vent... -
Page 17: Before Calling Service
Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual Troubleshooting Before Calling Service WARNING To reduce the risk of electric shock, personal injury, or death, turn the fan control to the off position and remove the unit plug from the wall outlet before doing any inspection or maintenance work. - Page 18 Owner’s Manual Room Air Heat Pump with R-410A Heat Controller, Inc. THIS PAGE WAS LEFT INTENTIONALLY BLANK...
- Page 19 Heat Controller, Inc. Room Air Heat Pump with R-410A Owner’s Manual THIS PAGE WAS LEFT INTENTIONALLY BLANK...
- Page 20 07/2010 66129905195 04/2009...
