Installation instructions
IZONA CoolDrawer
RB36S & RB90S models
Important!
SAVE THESE INSTRUCTIONS
The models shown in this document may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to our
website www.fisherpaykel.com or contact your local Fisher & Paykel dealer.
1

SAFETY AND WARNINGS

Electrical shock hazard
Disconnect product from main power supply before installing appliance.
Failure to do so may result in electrical shock or death
Cut hazard
Take care - panel edges are sharp.
Failure to use caution could result in injury or cuts.
Tipping hazard
Do not operate this apppliance until it has been securely anchored inside the
cabinetry. The cabinet must be securely anchored to the floor.
Failure to use caution could result in injury or cuts.
Important safety precautions!
Installation of the CoolDrawer requires competent mechanical and electrical skills.
Be sure to leave these Instructions with the Customer.
Installation must comply with your local building and electricity regulations.
At the completion of the CoolDrawer installation, the Installer must perform the Final Check List.
Remove all packaging materials supplied with the CoolDrawer.
The CoolDrawer is manufactured for indoor use only.
WARNING!
WARNING!
WARNING!
The CoolDrawer MUST be installed to allow for future removal from the enclosure if service is required.
Do not seal the CoolDrawer into the cabinetry with silicone or glue. Doing so will make future servicing
difficult. Fisher & Paykel will not be liable for any costs associated with removing or replacing a sealed-in
product, nor for repairing any damage that may be incurred by doing this.
Care should be taken when the appliance is installed or removed to reduce the likelihood of damage to the
power supply cord.
Failure to install the CoolDrawer correctly will invalidate any warranty or liability claims.
If the power supply cord is damaged, it must be replaced. Parts are available from your Authorised
Fisher & Paykel dealer.
Cabinetry must be sufficiently robust to support a combined product and food load of 220 lb (100 kg).
Bearers may be required to support the internal shelf.
Before you install the CoolDrawer, please make sure that
The switched power outlet must be outside the refrigerator drawer cavity so that it is accessible after
installation.
The switched power outlet must be located outside the cavity, within 55" (1400 mm) from the CoolDrawer
cavity if situated on the left-hand side of the cavity and within 33" (840 mm) if situated on the right-hand
side of the cavity.
The services hole in the refrigerator cavity needs to be large enough for the power supply plug to fit
through.
FRAMED CABINETRY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IZONA CoolDrawer RB365 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fisher & Paykel IZONA CoolDrawer RB365

  • Page 1: Safety And Warnings

    Installation instructions IZONA CoolDrawer RB36S & RB90S models Important! SAVE THESE INSTRUCTIONS The models shown in this document may not be available in all markets and are subject to change at any time. For current details about model and specification availability in your country, please go to our website www.fisherpaykel.com or contact your local Fisher &...
  • Page 2: Product Dimensions

    PRODUCT DIMENSIONS Installation diagrams for illustration purposes only Product dimensions (inches [mm]) overall height of product (inc. installation brackets) overall width of product overall depth of product (excl. drawer panel; inc. power cord) depth of drawer (open) (excl. handle) CABINETRY DIMENSIONS Installation diagrams for illustration purposes only Cabinetry dimensions (inches [mm])
  • Page 3 PARTS SUPPLIED Installation brackets Phillips 16 mm Trim brackets (4) (left-hand and right- ( / ” ) wood hand side) (2) screw (6) CAVITY PREPARATION Important! Disconnect power to surrounding appliances before preparing cavity. Recommended to allow the vertical removal of the refrigerator bins. Pan Head Installation Power...
  • Page 4 PANEL PREPARATION D height of D r a Drawer Panel w e r P a n / ” (4 mm) l s e height of False width of Panels Panel SIDE VIEW Benchtop Integrated Panel material Installation diagrams for illustration purposes only / - / ”...
  • Page 5 CREATE CUTOUTS IN FRAME If the cabinetry does not already have cutouts, ensure the modifications below are made. max. / ” (16 mm) 1 / ” (50 mm)* 4” (102 mm) 30 / ” (764 mm)** 1 / ” (4 0 m m ) 8 ½”...
  • Page 6 MOVE PRODUCT INTO CAVITY Important! 1 / ” Do not screw in trim (46 mm) brackets at this stage. Important! Be careful not to damage power supply cord when pushing product into cavity. ATTACH DRAWER PANEL TO FRONT OF DRAWER Close the drawer and check vertical clearances Hook drawer panel onto...
  • Page 7 SECURE PRODUCT TO CABINETRY Open drawer and secure product to cabinetry using four Trim brackets and screws. ATTACH FALSE PANEL Attach the false panel securely as recommended by the cabinet maker. / ” (4 mm) / ” (2 mm) Important! The false panel needs to be removable for servicing.
  • Page 8 FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Has all packaging been removed from the appliance? Is the appliance securely fastened to the cabinetry? Does the drawer slide freely and close properly? Has the outlet duct been installed correctly? Is the appliance level? Are the panels securely attached? Have the panels been properly aligned for correct operation and appearance? Are all clearances even?
