2 HP Fixed Base Router
68341 Router
Read this material before using this product.
Failure to do so can result in serious injury.
Save tHiS manual.
When unpacking, make sure that the product is intact and undamaged.
If any parts are missing or broken, please call 1-800-444-3353 as soon as possible.
visit our website at: http://www.harborfreight.com
©
®
Copyright
2011 by Harbor Freight Tools
. All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for assembly and service may not be included.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 68341 and is the answer not in the manual?

Questions and answers

Summary of Contents for Drill Master 68341

  • Page 1 . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing...
  • Page 2: Specifications

    Ground Fault Circuit interrupter (GFCi) protected supply. Use of a GFCI reduces the risk of electric shock. Page 2 For technical questions, please call 1-800-444-3353. SKU 68341...
  • Page 3: Router Safety Warnings

    9. Keep Handles dry, clean, and free of oil or grease. Such preventive safety measures reduce the This will permit better control of the tool. risk of starting the power tool accidentally. 10. Do not use damaged bits. SKU 68341 For technical questions, please call 1-800-444-3353. Page 3...
  • Page 4: Vibration Safety

    26. People with pacemakers should consult their as tingling, numbness, and white or blue fingers), physician(s) before use. Electromagnetic fields in seek medical advice as soon as possible. close proximity to heart pacemaker could cause Page 4 For technical questions, please call 1-800-444-3353. SKU 68341...
  • Page 5: Double Insulated Tools: Tools With Two Prong Plugs

    14 gauge cord can carry a higher current must be connected to a properly grounded outlet. than a 16 gauge cord. (See table a.) If the tool should electrically malfunction or break SKU 68341 For technical questions, please call 1-800-444-3353. Page 5...
  • Page 6: Extension Cord

    12.1 – 16.0 Properly connect power cord to appropriate outlet. 16.1 – 20.0 * Based on limiting the line voltage drop to five volts at 150% of the rated amperes. Page 6 For technical questions, please call 1-800-444-3353. SKU 68341...
  • Page 7: Instructions For Putting Into Use

    For additional information regarding the parts listed in the following pages, refer to Parts List on page 12. Components Power Switch (23) Scale Ring (46) Handle Handle Figure 1 Collet Nut (1) SKU 68341 For technical questions, please call 1-800-444-3353. Page 7...
  • Page 8: Installing Bits

    (sold separately) Collet Nut with the Wrenches. Collet Nut Collet Collet Nut Collet Wrench (51) Nut (1) Wrench (51) Nut (1) Spindle Spindle Spindle Wrench (50) Spindle Wrench (50) Page 8 For technical questions, please call 1-800-444-3353. SKU 68341...
  • Page 9: Adjusting The Cutting Depth

    Guide facing the workpiece. 3. Adjust the distance between the router bit and the Guide to the desired setting. 4. Tighten the Wing Nuts (27 and 37). Base (45) Guide Poles (28) SKU 68341 For technical questions, please call 1-800-444-3353. Page 9...
  • Page 10: Work Piece And Work Area Set Up

    9. To prevent accidents, disconnect the power supply after use. Clean, then store the Router tool indoors out of children’s reach. Direction WaRninG! moving the router against the recommended direction can cause serious injury from kickback. Page 10 For technical questions, please call 1-800-444-3353. SKU 68341...
  • Page 11: Maintenance And Servicing

    See Extension Cords in Grounding section on page 5. Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect power supply before service. SKU 68341 For technical questions, please call 1-800-444-3353. Page 11...
  • Page 12: Parts List

    LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Page 12 For technical questions, please call 1-800-444-3353. SKU 68341...
  • Page 13: Assembly Diagram

    Diagram SKU 68341 For technical questions, please call 1-800-444-3353. Page 13...
  • Page 14: Limited 90-Day Warranty

    90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
