Fisher 2610 Product Installation Manual

Replacement Parts for Pre-Rinse Units
2924-6000 2914
SPRING STAINLESS STEEL
GOOSENECK HOSE 36"
2922-5000
WASHER
2932-0002
BACKFLOW
WATTS N9
BACK-FLOW
PREVENTER
PREVENTER
2925-6300
HOSE HOOK
2913
INSULATED
HANDLE
2926-3300
PIPE TO HOSE
ADAPTER
2949 ULTRA SPRAY
VALVE
2927-4300
2902-12
3/8" PIPE
2949-9001
WALL BRACKET
21" RISER
SCRUB BRUSH
2600-CV
CONTROL
VALVE
2000-7500
3000-0000
SCREW
RH SWIVEL
REPAIR KIT
2000-8000
RED BUTTON
AND
2000-8001
BLUE BUTTON
2000-2301
LEVER HANDLE
2000-3002
BIBB CAP
2000-0004
10464
RH CHECK STEM
DUCK GASKET
REPAIR KIT
2000-5000 OR
WASHER 2000-0005
LH CHECK STEM
REPAIR KIT
2000-3406
LH CHECK STEM
OR
2000-3407
RH CHECK STEM
2000-6000
SPRING
2000-0001
RETAINER
ASSEMBLY
10456
MANFACTURING COMPANY
LUBE
PO BOX 60, TULARE, CA 93275
(800)421-6162, FAX: (800)832-8238
PART NO. 39101
2949-3001 2949-9002
NOZZLE FOR
BLUE BUMPER
2949 SPRAY
VALVE
1000-5005
O-RING
2912-2501
2912-7501
2400-2103
ELBOWS
2909-6000
1790-1
1792
ANGLE STOP
ANGLE STOP
W/ CROSS
WITH KEY
HANDLES
1000-7502 3000-0011
10464 2000-2301
SEAT SCREW RH SWIVEL
DUCK GASKET LEVER HANDLE
STEM
10456 2000-5000 2000-3002
2000-5003
LUBE WASHER BIBB CAP
SEAT WASHER
3967
16" SWING SPOUT
3964
14" SWING SPOUT
3963
12" SWING SPOUT
3962
10" SWING SPOUT
3961
8" SWING SPOUT
3960
6" SWING SPOUT
12564
2.2 GPM
AERATOR
www.fisher-mfg.com
11355
SPRAY VALVE
REPAIR KIT
1000-3301
1000-5001
2912-6000
Since 1936, Fisher Manufacturing Company has
1000-0001
INCLUDES:
manufactured heavy-duty, high quality plumbing
1000-5003 WASHER
products and hardware specialties for the food service
1000-7502 SCREW
industry. For three generations, the Fisher family has
2922-5000
adhered to a strict dedication of and overall value.
When you install Fisher products... you install
1000-0003
the best. Our hardware is manufactured with the
standardization of internal mechanisms. All chrome
2909-5000
plating is triple plated copper, nickel and chrome
2909-3400
for durability. Every piece of equipment we make is
rigorously tested in both our modern in-house testing
center and in actual fi eld situations under extreme
conditions. Every detail is thoroughly checked. Before
we make our products available to you, they pass
each and every test. You get proven performance.
Guaranteed.
Limited One Year Warranty
Fisher Manufacturing Company warrants its products
and parts thereof (except as noted below) against
2000-7500
defects in materials or workmanship for a period of
SCREW
one year after the date of original purchase. During
this period Fisher Manufacturing Company will
replace a defective product or part without charge to
2000-8000
RED BUTTON you, provided that the entire product is delivered to
AND
Fisher Manufacturing Company. All transportation and
2000-8001
insurance charges for shipping the product to and from
BLUE BUTTON
Fisher Manufacturing Company must be borne by you.
Charges for transportation and insurance may, at the
option of Fisher Manufacturing Company, be refunded
depending upon our investigation of the warranty
claim. This warranty does not cover external fi nish
(except at date of original purchase) or labor costs
2901-0000
not specifi cally authorized by Fisher Manufacturing
ADD-ON CONTROL
Company.
VALVE LESS SPOUT
A full and complete copy of our One Year limited
warranty is available upon request.
15621
SPOUT NUT
2002
SNAP RING
KEEP THIS MANUAL FOR FUTURE REFERENCE
1600-5000
SPOUT
O-RINGS
10456
LUBE
19119
fisher manufacturing company - toll free: 800-421-6162 fax: 800-832-8238
SWIVEL SPOUT
RETRO-FIT KIT
REV. B
fisher manufacturing company
4" C/C Backsplash Pre-Rinse Unit
Product Installation Guide
#2610 - Pre-Rinse Unit: 4" C/C Backsplash Control
Valve, Ultra Spray
#2610-WB - Pre-Rinse Unit: 4" C/C Backsplash Control
ANSI/A112.18.1M, ANSI/NSF 61.9
www.fi sher-mfg.com
Valve, Ultra Spray, Wall Bracket
