Microdia SD+USB Operating Manual

TM
SD +USB MEMORY CARD

OPERATING MANUAL

SPECIFICATIONS

Dimension:
Weight:
Operating Voltage:
Operating Temperature:
Clock Frequency:
Operating Humidity:
NOTE: Specifications are subject to change without notice.
REMOVAL oOF THE SD
1. Hold a corner of the blister.
2. Clap the blister on your palm for removing the plastic case.
3. Hold the blister upside down with about an inch of distance
between the blister and the table.
4. Use your finger to push the edge of the SD
5. Then SD TM +USB card will drop on the table.
REMOVAL AND STORAGE OF THE SD
1. Hold the case with both hands when opening and closing.
2. Unlock and open the lid of the case.
3. Store or remove the SD
is placed properly on the tray before closing the case.
4. Lock the plastic case.

PRECAUTIONS FOR HANDLING AND STORAGE

• Keep out of the reach of children. Get medical advice immediately if swallowed.
• Do not touch the interface pin directly by hands, metal or hard objects.
• Do not modify or disassemble the SD
• Do not wet, heat/fire, impact, drop or bend the SD
• Do not use or store in a humid and dusty place; in hot place such as inside a hot car, under a blazing sun, near
fire, a stove, an air-conditioner outlet, etc.
• Do not expose to strong magnet fields, electrical noise and put near corrosive chemicals/gas. This may cause
damage through melting or the emission of heat/smoke or cause product failure.
• Do not place in cooking appliances such as microwave ovens or high-pressure containers.
• Do not detach the label on the SD

DATA PROTECTION

TM
• MICRODIA SD +USB Memory Card comes pre-formatted. Make sure to back up all the data on your
SD+USB card before formatting.
• Slide down Write-Protect Switch to "LOCK" for preventing record/edit the card. Unlock the card before
reading/writing data.
• Do not remove the SD
written and transferred. It can cause data to be destroyed.
TM
• Insert the SD +USB card firmly in the correct orientation. The product will not operate correctly if it is
inserted in an incorrect orientation or not inserted all the way
• Parental Guidance is needed when a child uses the SD
protect the product and insure that the child follows your instructions.
24.0 (W) x 32.0 (L) x 2.1 (T) mm
Approx. 2g
2.7 to 3.6 V
-25°C to +85°C
Up to 25MB/sec
5% to 96% RH
+USB CARD FROM BLISTER
TM
TM
+USB card.
TM
+USB CARD IN PLASTIC CASE
TM +USB card in the tray. Ensure the card
TM
+USB card.
TM
+USB card. Do not attach other stickers/labels on the SD
TM
+USB card and switch off any equipment using the card when data is being read,
CONFIRMATION OF PARTS LIST
TM
SD +USB memory card
Step 1 & 2
TM
+USB card.
TM
+USB card. Teach the child how to use and
Plastic Case
Step 3 & 4
Step 2
TM
+USB card.
Email: info@microdia.com
Website: http://www.microdia.com
Manual
Step 5
Step 3
Unlock Lock
MICRODIA Ltd
