SHINDAIWA OWNER'S/OPERATOR'S MANUAL
Model: 65001
MULTI-PURPOSE
TRIMMER TOOL
WARNING!
Minimize the risk of injury to yourself and others!
Read this manual and familiarize yourself with the
contents. Always wear eye and hearing protection
when operating this unit.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 65001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shindaiwa 65001

Summary of Contents for Shindaiwa 65001

  • Page 1 SHINDAIWA OWNER’S/OPERATOR’S MANUAL Model: 65001 MULTI-PURPOSE TRIMMER TOOL Minimize the risk of injury to yourself and others! Read this manual and familiarize yourself with the contents. Always wear eye and hearing protection when operating this unit. WARNING! X7502880002 01/11...

  • Page 2: Table Of Contents

    If you have questions regarding your Shindaiwa hand held power equipment, or if you do not understand something in this manual, contact your local Shindaiwa dealer for assistance.

  • Page 3: Safety

    If it has been lost or misplaced, contact a during operation. Never permit a person without training Shindaiwa dealer for a replacement. or instruction to operate this machine! Operating Precautions WARNING! ■...

  • Page 4: Safety Labels

    Safety Labels IMPORTANT! Safety and Information Labels: Make sure all safety and in- formation labels are undamaged, readable and up to date. Immediately replace damaged or missing labels. New labels are available through your local authorized Shindaiwa dealer. Figure 1...

  • Page 5: Product Description

    Product Description Multipurpose Using the illustration as a guide, familiarize your- Trimmer Tool self with your machine and its various compo- nents. Understanding your machine helps ensure top performance, long service life and safer operation. 1 - Outer tube 2 - Gearcase 3 - Trimmer Head 4 - Cutting attachment shield WARNING!
  • Page 6 Disassembling The Pole Sections 1. Place the Multipurpose Tool Carrier and the Tool Assembly on a clean, flat sur- face, loosen the coupler screw knob (D). The spring-loaded coupler protector (G) should pop up. 2. Press down on the latch (F) with your finger or thumb. This releases the cou- pler latch.

  • Page 7: Operation

    Trimmer Head Install the Trimmer Head. 1. Turn the trimmer over so that the gearcase output shaft faces UP. 2. Remove and discard the plastic retaining plug. 3. Rotate the tool holder and shaft until the notch in the holder (A)aligns with the notch on the gearcase (B) flange, and use the long end of the hex wrench to lock the output shaft in position.

  • Page 8: Maintenance

    ■ Remove the cutting attachment and the gear shaft collar (A), and press new grease into the gear case until the old grease has been pushed out. Use only lithium-base grease such as Shindaiwa Gear Case Lubricant or equivalent. Grease...

  • Page 9: Troubleshooting Guide

    Bent main shaft/worn or damaged bushings. Inspect and reinstall as required. Shaft not installed in powerhead or gearcase. Broken shaft. Cutting attachment will not Consult with an authorized Shindaiwa servicing move. dealer. Damaged gearcase. Adjust idle. Check Specifi cations page for correct idle Engine idle too high.
  • Page 10 NOTES...
  • Page 11 NOTES...

  • Page 12: Servicing Information

    Warranty Registration To ensure trouble free warranty coverage it is important that you register your Shindaiwa equipment by filling out the warran- ty registration card supplied with your unit. Registering your product confirms your warranty coverage and provides a direct link if we find it necessary to contact you.
