Controls and Connections

General control buttons
1. Power/Stand-by button (
2. Input source select button (SOURCE)
3. Menu button (MENU)
4. Channel up button (CH
5. Channel down button (CH
6. Volume increase button (VOL+)
7. Volume decrease button (VOL- )
8. Remote sensor
9. Power indicator
Sockets (rear and side panel)
1. Audio out (L/R)
2. Component video input sockets (Y Pb/Cb Pr/Cr)
3. Antenna input socket (RF 75 )
4. VGA interface input socket (VGA)
5. PC audio input socket (PC AUDIO)
6. High D
7. USB port (MEDIA)
8. Headphone socket (
9. S/PDIF Coaxial output socket (COAXIAL OUT)
10. Composite video & audio input sockets (VIDEO/L/R)
)
)
)
ultimedia Interface input sockets (HDMI1/2/3)
)
Power supply
Ensure your mains voltage and
frequency correspond with those
on the TV rating label.
