Knoll IR55 Installation Instructions

IR55 Infrared Connection Module
Specifications:
Specifications
Infrared carrier frequency: 1-1,000,000 Hz
Maximum wire length:
Wire requirements:
Power requirements:
Dimensions:
Requires 12VDC power supply, emitter(s) and a Knoll
infrared receiver.
Warranty
Knoll Systems warrants its products sold in the USA and Canada by authorized
Knoll dealers to be free of defects in materials and workmanship. This warranty
extends for three full years from the date of purchase by the original consumer.
Any products returned to Knoll Systems and found to be defective by Knoll
Systems within the warranty period will be repaired or replaced at Knoll Systems
option, at no charge. Knoll Systems will not be responsible for the actual cost of
installation or removal of the product, nor for any incidental or consequential
damages. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply to you. This
warranty gives you specific legal rights. You may have additional legal rights
that vary from state-to-state.
Knoll Systems www.knollsystems.com
145 Tyee Drive Point Roberts, WA 98281
14-7163 Vantage Way, Delta BC V4G 1N1
Telephone: (604) 940-1689, Fax (855) 734-3363
www.knollsystems.com
Made in Canada Knoll Systems All Rights Reserved
1000' (300m) or even more with
larger gauge wire
3 conductors, minimum 24-gauge
to 200'; 22-gauge up to 500';
20-gauge to 1000'
12VDC, 200mA+
2.5" x 1" x 2-5/8"
(63mm x 26mm x 67mm)
IR55
Infrared Connection Module
Installation Instructions v2.0
Warning: To be installed and/or used in accordance with
appropriate electrical codes and regulations.
Introduction:
Thank you for your purchase of a Knoll IR55
infrared connection module. This module is the heart of a
scalable infrared repeater system. The IR repeater system can
pick up a remote control signal and relay it on wires to another
location up to 1000' (or more).
Features:
 Easy to install and easy to
use
 No maintenance and no
adjustments
 Connect up to 12 infrared
receivers
 Connect up to 8 emitters to
four emitter ports
 PS1205 power supply
recommended
Installation Tips
1. Follow all local electrical & building code requirements.
2. The IR55 is usually mounted with the stereo and/or video
equipment it is helping to control.
3. Wires to the infrared receivers can be solid or stranded,
shielded or unshielded with a minimum of 28-gauge for runs
under 200', 22-gauge for runs under 500' and 20-gauge for
runs up to 1000'. Wires can be looped from infrared receiver to
receiver or home run. Home runs normally offer more reliability
and future flexibility.
