QSC CM16a Specifications

N E T W O R K
P r e l i m i n a r y
The CM16a Amplifier Network Monitor is a key hardware component of QSControl, QSC's Ethernet based audio network. The CM16a
provides sixteen channels of gain control, monitoring, and amplifier management for DataPort-equipped QSC amplifiers. The CM16a
is operated remotely by a Pentium-based PC or QSC System Controller running QSControl application software. Control and monitoring
data is communicated between the Pentium-based PC or QSC System Controller and CM16a via an Ethernet network.The CM16a, located
in the amplifier rack, is linked to each amplifier via a DataPort.
CM16a Input / Output Control & Monitoring
•
Input sensitivity selection:1V or 3V
•
Input source select:Normal/Page
•
Gain control
•
Pre-/Post-fader audio signal monitoring
•
Mute control
•
Signal polarity control
•
Signal level metering
Amplifier Output Monitoring
•
Output voltage and current metering
•
Amplifier output power in watts
•
Output clip detection monitoring
•
Amplifier headroom metering
•
Output signal (speaker terminal) audio monitoring
Load Monitoring
•
Open / shorted load detection
•
Programmable threshold for detecting load opens and shorts
•
Real-time load impedance measurement
A U D I O S Y S T E M S
S p e c i f i c a t i o n s
Front View
Rear View
Amplifier Management
•
AC standby/operate mode selection
•
AC mode indication (off/standby/operate)
•
Amplifier protect status monitoring
•
Amplifier operating temperature metering
•
Amplifier gain control monitoring
•
Amplifier model ID indication
•
Bridge Mono/Parallel/Stereo mode indication
Other Features
•
Sixteen configuration presets
•
External RS-232 port for diagnostics and preset control
•
Internal Audio DAC (Digital to Analog Converter) for system diagnostics,
load impedance measurement,or playback of audio files
•
Contact closure input
•
Page input with selectable 1V or 3V sensitivity
•
One floating dry-contact SPDT relay output
•
Single-line balanced summing audio monitor bus
•
Front-panel bypass switch
•
Firmware updateable via network to add future upgrades
