Summary of Contents for EVGA PC-over-IP Administrative Interface

  • Page 1 PC-over-IP Administrative Interface ® User Manual...
  • Page 2 The information contained in this document represents the current view of EVGA Corporation as of the date of publication. Because EVGA must respond to changing market conditions, it should not be interpreted to be a commitment on the part of EVGA, and EVGA cannot guarantee the accuracy of any information presented after the date of publication.

  • Page 3: Table Of Contents

    PC-over-IP Administrative Interface User Manual Contents CONTENTS ........................2   TABLE OF FIGURES ..................... 5   TABLES .......................... 8   DEFINITIONS ......................... 9   INTRODUCTION ......................10   ADMINISTRATIVE WEB INTERFACE ..............11         Supported Web Browsers ........................ 12  ...
  • Page 4 PC-over-IP Administrative Interface User Manual     Diagnostics Menu ..........................40     1.8.1 Event Log ..........................41     1.8.2 Session Control ......................... 42     1.8.3 Session Statistics ........................43     1.8.4 Host CPU ..........................44  ...
  • Page 5 PC-over-IP Administrative Interface User Manual     USB Device Not Authorized Overlay ....................78     Half-Duplex Overlay ......................... 78     Video Source Overlays ........................79 APPENDIX A: USAGE EXAMPLES ............... 80         Peer-to-Peer Direct Connection Example ..................80  ...

  • Page 6: Table Of Figures

    PC-over-IP Administrative Interface User Manual Table of Figures Figure 1-1: Administrative Web Interface ................. 11 Figure 1-2: Administrative Web Interface Overview ............12 Figure 1-3: Log In Webpage ..................... 14 Figure 1-4: Home Page ..................... 15 Figure 1-5: Configuration Menu Navigation ..............17 Figure 1-6: Initial Setup Host Webpage ................
  • Page 7 PC-over-IP Administrative Interface User Manual Figure 1-36: Version Webpage ..................48 Figure 1-37: Attached Devices Webpage ................. 50 Figure 1-38: Upload Menu Navigation ................51 Figure 1-39: Firmware Upload Webpage ................51 Figure 1-40: OSD Logo Upload Webpage ................ 52 Figure 2-1: OSD Connect Screen ..................
  • Page 8 PC-over-IP Administrative Interface User Manual Figure 4-6: Peer-to-Peer Connect Screen ................ 86 Figure 4-7: Portal Connection Management DHCP & Discovery Configuration ....87 Figure 4-8: Portal Discovery Webpage Enable Discovery Configuration ......87 Figure 4-9: Portal Network Webpage DHCP Configuration ..........88 Figure 4-10: Portal PCoIP Processor Webpage DHCP &...

  • Page 9: Tables

    PC-over-IP Administrative Interface User Manual Tables Table 1-1: Home Webpage Parameters ................16 Table 1-2: Step 1: Audio Parameters ................20 Table 1-3: Step 2: Network Parameters................20 Table 1-4: Step 3: Host Session Parameters ..............21 Table 1-5: Step 3: Portal Session Parameters ..............21 Table 1-6: Connection Manager Method ................

  • Page 10: Definitions

    PC-over-IP Administrative Interface User Manual Definitions Certificate Authorities Connection Management Interface – interface provided by the Portal or Host, used to communicate with an external connection management server Connection Management Server – an external management entity (3rd party) that manages and controls the Portal/Host through the CMI interface...

  • Page 11: Introduction

    PC-over-IP Administrative Interface User Manual Introduction Users and administrators can interact with the PC-over-IP®, or PCoIP®, Portal and Host via an embedded HTTPS web interface. The Portal can also be accessed via the local Graphical User Interface (GUI) On Screen Display (OSD). As well, messages are displayed over the user screen when required.

  • Page 12: Administrative Web Interface

    PC-over-IP Administrative Interface User Manual Administrative Web Interface The PCoIP Administrative Web Interface allows an administrator to interact with the device remotely using an internet browser. Figure 1-1 shows an example of the Administrative Web Interface with seven regions highlighted: •...

  • Page 13: Supported Web Browsers

    PC-over-IP Administrative Interface User Manual Figure 1-2 shows an overview of the configuration webpages available in the Administrative Web Interface. Figure 1-2: Administrative Web Interface Overview 1.1 Supported Web Browsers The webpage servers on the Host and Portal have been tested and are compatible with the following web browsers: •...

  • Page 14: Web Interface Security

    PC-over-IP Administrative Interface User Manual Once the administrator has determined the IP address, enter it into the browser to access the Administrative Web Interface, e.g. https://192.168.1.123. 1.3 Web Interface Security The web interface uses HTTP over an SSL socket (HTTPS), and cannot be accessed without an administrative password.

  • Page 15: Log In

    PC-over-IP Administrative Interface User Manual 1.4 Log In The Log In page allows the administrator to securely log into the administrative webpages. Figure 1-3: Log In Webpage 1.4.1 Warning The Warning displays pertinent information regarding the device the administrator is logging in to when there is an administrative session already in progress.

  • Page 16: Home/Initial Setup Webpages

    PC-over-IP Administrative Interface User Manual 1.5 Home/Initial Setup Webpages When an administrator logs in, the Home webpage is shown. The Home webpage provides an overview of the status. If configured in the firmware defaults, the Initial Setup webpage is optionally used the first time an administrator logs in.

  • Page 17: Initial Setup

    PC-over-IP Administrative Interface User Manual Table 1-1: Home Webpage Parameters Parameter Comments Time since boot Length of time that the PCoIP processor has been running (refer to Section 1.8.7) Possible states: Disconnected, Connection Pending, Connection State Connected (refer to Section 1.8.3) Packet Statistics Packets sent (refer to Section 1.8.3)

  • Page 18: Initial Setup

    PC-over-IP Administrative Interface User Manual • Language • • Image • Monitor Emulation • Time • Password • Reset Parameters Figure 1-5: Configuration Menu Navigation 1.6.1 Initial Setup The Initial Setup webpage contains the configuration parameters that the administrator must first set when using the Host and Portal devices. The webpage simplifies the out-of- box experience and reduces the time for initial users to establish a 1-to-1 PCoIP session.

  • Page 19: Figure 1-6: Initial Setup Host Webpage

    PC-over-IP Administrative Interface User Manual Figure 1-6: Initial Setup Host Webpage...

  • Page 20: Figure 1-7: Initial Setup Portal Webpage

    PC-over-IP Administrative Interface User Manual Figure 1-7: Initial Setup Portal Webpage 1.6.1.1 Step 1: Audio Step 1: Audio allows the administrator to configure the audio parameters. Table 1-2 summarizes the applicable parameters.

  • Page 21: Table 1-2: Step 1: Audio Parameters

    PC-over-IP Administrative Interface User Manual Table 1-2: Step 1: Audio Parameters Parameter Comments Enable HD Audio Enables audio support on Host or Portal (refer to Section 1.7.2). Enable Microsoft® Windows Enables 64-bit mode on Host (refer to Section Vista® 64-bit Mode 1.7.2).

  • Page 22: Network

    PC-over-IP Administrative Interface User Manual Table 1-4: Step 3: Host Session Parameters Parameter Comments Accept Any Portal Allows the Host to accept any Portal for a PCoIP Session (refer to Section 1.6.5). Allows the administrator to specify the Portal MAC address Portal MAC Address for a PCoIP Session (refer to Section 1.6.5).

  • Page 23: Figure 1-8: Network Configuration Webpage

    PC-over-IP Administrative Interface User Manual Figure 1-8: Network Configuration Webpage 1.6.2.1 Enable DHCP When the Enable DHCP option is enabled, the device will contact a DHCP server to be assigned an IP address, subnet mask, gateway IP address, and DNS servers. When disabled, these parameters must to be set manually.

  • Page 24: Connection Management

    PC-over-IP Administrative Interface User Manual 1.6.2.6 Secondary DNS Server The Secondary DNS Server is the device’s secondary DNS IP address. This field is optional. If the DNS server IP Address is configured when using a Connection Manager, the Connection Manager address may be set as a FQDN instead of an IP address (see Section 1.6.3.2).

  • Page 25: Figure 1-9: Connection Management Configuration Webpage (Ip Address)

    PC-over-IP Administrative Interface User Manual Figure 1-9: Connection Management Configuration Webpage (IP Address) Figure 1-10: Connection Management Configuration Webpage (FQDN) 1.6.3.1 Enable Connection Management If the Enable Connection Management option is enabled, the device can be configured and controlled by an external connection manager.

  • Page 26: Discovery

    PC-over-IP Administrative Interface User Manual Table 1-6 shows the configuration parameters available when either method is chosen. If an invalid IP address or DNS name is entered, the web interface will prompt the administrator to correct it. Table 1-6: Connection Manager Method...

  • Page 27: Session

    PC-over-IP Administrative Interface User Manual Enable Host Discovery The Enable Host Discovery feature allows the Portal to discover Hosts that are not in a PCoIP session. When enabled, the Portal is able to display up to 10 available hosts in the order that they were discovered.

  • Page 28: Figure 1-12: Session Configuration Webpage

    PC-over-IP Administrative Interface User Manual Figure 1-12: Session Configuration Webpage Figure 1-13: Session Configuration Webpage (RDP) 1.6.5.1 Accept Any Peer If the Accept Any Peer option is enabled, the host will accept connections from any Portal. If this option is disabled, the administrator must specify the peer MAC address.

  • Page 29: Bandwidth

    PC-over-IP Administrative Interface User Manual 1.6.5.2 Session Type The administrator can choose a PCoIP session or an RDP session. For information on the Portal RDP client, see Section 6 Appendix C: Portal RDP Compatibility This option is only available on a Portal; on the Host it is disabled and non-editable.

  • Page 30: Rdp

    PC-over-IP Administrative Interface User Manual Figure 1-14: Bandwidth Configuration Webpage 1.6.6.1 Device Bandwidth Limit The Device Bandwidth Limit parameter defines the maximum bandwidth peak for the PCoIP system. The bandwidth setting on the Host side defines the bandwidth from the Host to the Portal (e.g.

  • Page 31: Figure 1-15: Rdp Configuration Webpage

    PC-over-IP Administrative Interface User Manual For information on the Portal RDP client, see Section 6 Appendix C: Portal RDP Compatibility. This option is only available on a Portal; on the Host it is disabled and non-editable. Note: The Portal RDP parameters can also be configured using the Portal OSD. See Section 2.3.7 RDP.

  • Page 32: Language

    PC-over-IP Administrative Interface User Manual 1.6.7.4 Audio Mode The Audio Mode field configures where the audio playback occurs for the RDP session. Possible options are: • Do not play • Play on client • Play on host 1.6.7.5 Enable Wallpaper The Enable Wallpaper field enables the use of wallpaper with the RDP session.

  • Page 33: Osd

    PC-over-IP Administrative Interface User Manual 1.6.9 OSD The OSD webpage allows the administrator to modify the On Screen Display (OSD) parameters. This option is only available on a Portal; on the Host it is disabled and non-editable. Note: The Portal OSD parameters can also be configured using the Portal OSD. See Section 2.3.9 OSD.

  • Page 34: Monitor Emulation

    PC-over-IP Administrative Interface User Manual Figure 1-18: Image Configuration Webpage 1.6.10.1 Minimum Image Quality The Minimum Image Quality slider allows the administrator to make compromises between image quality and frame rate when network bandwidth is limited. Some usage cases may require lower-quality images at a higher frame rate, while in other cases higher-quality images at a lower frame rate may be preferred.

  • Page 35: Time

    PC-over-IP Administrative Interface User Manual This option is only available on a Host; on the Portal it is disabled and non-editable. Figure 1-19: Monitor Emulation Configuration Webpage 1.6.11.1 Enable Monitor Emulation When Enable Monitor Emulation is disabled, the Host will only respond to Display Data Channel (DDC) when in a PCoIP session.

  • Page 36: Password

    PC-over-IP Administrative Interface User Manual 1.6.12.2 Enable NTP The Enable NTP field allows the administrator to enable and disable the NTP feature. 1.6.12.3 Identify NTP Host By The Identify NTP Host by selector allows the administrator to choose whether the NTP Host is identified by IP address or by Fully Qualified Domain Name (FQDN).

  • Page 37: Reset Parameters

    PC-over-IP Administrative Interface User Manual Figure 1-21: Password Configuration Webpage 1.6.13.1 Old Password The Old Password field must match the current administrative password for the update to take place. 1.6.13.2 New Password The New Password field will be the new administrative password for both the web interface and the local OSD GUI.

  • Page 38: Permissions Menu

    PC-over-IP Administrative Interface User Manual 1.7 Permissions Menu The Permissions menu contains links to pages that define the range of functionality exposed to the user. The webpages in the Permissions menu are: • • Audio • Power Figure 1-23: Permissions Menu Navigation 1.7.1 USB...

  • Page 39: Table 1-9: Usb Device Authorization Entry Types

    PC-over-IP Administrative Interface User Manual button allows a new device or device group to be added to the list and the Remove button allows a device or device group to be removed from the list. Selecting the Add new button allows USB authorization by ID or Class. If ID is selected, then this entry authorizes a USB device by Vendor ID and Product ID.

  • Page 40: Audio

    PC-over-IP Administrative Interface User Manual 4. Authorized Device Class/Sub Class/Protocol (lowest priority) Table 1-9 summarizes the USB unauthorization entry types and the associated data fields. Table 1-10: USB Device Unauthorization Entry Types Entry Required Hexadecimal Value Comments Type Fields 0-FFFF...

  • Page 41: Power

    PC-over-IP Administrative Interface User Manual 1.7.2.2 Enable Audio Compression The Enable Audio Compression option enables and disables audio compression to reduce the data bandwidth used for audio. 1.7.2.3 Enable Microsoft® Windows Vista® 64-bit Mode The Enable Microsoft® Windows Vista® 64-bit Mode option enables the 64-bit work- around for Vista64 to avoid memory corruption when audio is enabled on host systems that are running 64-bit operating systems and that have more than 4 GB of RAM.

  • Page 42: Event Log

    PC-over-IP Administrative Interface User Manual • Session Control • Session Statistics • Host CPU • Audio • Display • PCoIP Processor Figure 1-27: Diagnostics Menu Navigation 1.8.1 Event Log The Event Log webpage allows the administrator to view and clear event log messages from the Portal or Host.

  • Page 43: Session Control

    PC-over-IP Administrative Interface User Manual 1.8.1.2 Event log filter mode The Event log filter mode pull-down menu allows the event log to be filtered. The options are: • Verbose • Terse 1.8.2 Session Control The Session Control webpage allows control of the device session.

  • Page 44: Session Statistics

    PC-over-IP Administrative Interface User Manual Peer MAC Address The Peer MAC Address displays the MAC address of the peer currently in session. When not in session, the field is blank. 1.8.3 Session Statistics The Session Statistics webpage allows the administrator to view PCoIP-specific statistics.

  • Page 45: Host Cpu

    PC-over-IP Administrative Interface User Manual PCoIP Packets Lost PC0IP Packets Lost reports the total number of PCoIP packets lost in the current session. 1.8.3.3 Bytes Statistics Bytes Sent Bytes Sent reports the total number of bytes sent in the current session.

  • Page 46: Audio

    PC-over-IP Administrative Interface User Manual Figure 1-31: Host CPU Webpage 1.8.4.1 Host Identity The Host Identity field displays the host computer identity string (if data is available). 1.8.4.2 Current Power State The Current Power State field displays the current host power state.

  • Page 47: Display

    PC-over-IP Administrative Interface User Manual Figure 1-32: Audio Diagnostics Webpage 1.8.5.1 Generate an audio test tone (portal only) There are two buttons available: The Start button starts the test tone and the Stop button stops the test tone. This option is only available on a Portal; on the Host it is disabled and non-editable.

  • Page 48: Pcoip Processor

    PC-over-IP Administrative Interface User Manual • 1600x1200 • 1920x1200 This option is only available on a Portal; on the Host it is disabled and non-editable. 1.8.6.3 Start/Stop The Start button starts the test pattern and the Stop button stops the test pattern.

  • Page 49: Version

    PC-over-IP Administrative Interface User Manual • Attached Devices Figure 1-35: Info Menu Navigation 1.9.1 Version The Version webpage allows the administrator to view hardware and firmware version information. Note: The Portal Version information can also be viewed using the Portal OSD. See Section 2.5 Information.

  • Page 50: Attached Devices

    PC-over-IP Administrative Interface User Manual Table 1-11: VPD Information MAC Address Portal/Host unique MAC address Unique Identifier Portal/Host unique identifier Serial Number Portal/Host unique serial number Firmware Part Number Part number of the current PCoIP firmware Hardware Version Portal/Host hardware version number 1.9.1.2 Firmware Information...

  • Page 51: Upload Menu

    PC-over-IP Administrative Interface User Manual Figure 1-37: Attached Devices Webpage 1.9.2.1 Monitors The Monitors section reports the Name, Serial Number, Vendor Identification (VID), Product Identification (PID), Date, and Status of the monitor attached to each port. The first line provides information for monitor 1 and the second line provides information for monitor 2.

  • Page 52: Firmware

    PC-over-IP Administrative Interface User Manual • Firmware • OSD Logo Figure 1-38: Upload Menu Navigation 1.10.1 Firmware The Firmware webpage allows the administrator to upload a new firmware build to the Portal or Host. Figure 1-39: Firmware Upload Webpage 1.10.1.1...

  • Page 53: Osd Logo

    PC-over-IP Administrative Interface User Manual 6. Select the webpage OK button on the warning window that reads, “Are you sure? This will upload a new firmware image. This operation may take a few minutes.” 7. Wait for the firmware upload to complete. The following message appears when complete: “Success Flash successfully programmed! You must reset the device for...
  • Page 54 PC-over-IP Administrative Interface User Manual 3. Select the webpage Upload button 4. Select the OK button on the warning window that reads, “Are you sure? This will upload a new logo for local GUI. This operation may take a few minutes.”...

  • Page 55: On Screen Display (Osd)

    PC-over-IP Administrative Interface User Manual On Screen Display (OSD) The On Screen Display (OSD) local GUI (Portal only) is displayed to the user when the device is powered on and a PCoIP session is not in progress. The OSD provides a mechanism to connect to a host device via the Connect Screen.

  • Page 56: Connect Button

    PC-over-IP Administrative Interface User Manual 2.1.1 Connect Button Selecting the Connect button initiates a PCoIP or RDP session, depending on the session settings. While the PCoIP connection is pending, the OSD local GUI will display a “Connection Pending” message. When the connection is established, the OSD local GUI will disappear and be replaced with the session image.

  • Page 57: Configuration Window

    PC-over-IP Administrative Interface User Manual Figure 2-3: OSD Options Menu 2.3 Configuration Window The Configuration window allows the administrator to access window tabs with settings that define how the Portal operates and interacts with its environment. The tabs in the Configuration window are: •...

  • Page 58: Unlocking The Configuration Settings

    PC-over-IP Administrative Interface User Manual 2.3.1 Unlocking the Configuration Settings All settings in the configuration tabs are password-protected. To unlock the settings: 1. Select the Unlock button in the bottom left corner of the Configuration window 2. Enter the password 3.

  • Page 59: Figure 2-5: Network Configuration

    PC-over-IP Administrative Interface User Manual Figure 2-5: Network Configuration 2.3.2.1 Enable DHCP When Enable DHCP is enabled, the device will contact a DHCP server to be assigned an IP address, subnet mask, gateway IP address and DNS servers. When disabled, the device requires these parameters to be set manually.

  • Page 60: Connection Management Tab

    PC-over-IP Administrative Interface User Manual 2.3.2.6 Secondary DNS Server The Secondary DNS Server field is the device’s secondary DNS IP address. This field is optional. If DHCP is enabled, this field is not editable. This field must be a valid IP address;...

  • Page 61: Discovery Tab

    PC-over-IP Administrative Interface User Manual 2.3.3.1 Enable Connection Management If the Enable Connection Management option is enabled, the device can be configured and controlled by an external connection manager. 2.3.3.2 Identify Connection Manager By The Identify Connection Manager selector allows the administrator to choose whether the connection manager is identified by IP address or by Fully Qualified Domain Name (FQDN).

  • Page 62: Session Tab

    PC-over-IP Administrative Interface User Manual Figure 2-7: Discovery Configuration 2.3.4.1 Enable Discovery If the Enable Discovery option is enabled, the device will dynamically discover peer devices and management entities, without requiring prior knowledge of their locations in the network. This can dramatically reduce configuration and maintenance effort for complex systems.

  • Page 63: Figure 2-8: Session Configuration

    PC-over-IP Administrative Interface User Manual Figure 2-8: Session Configuration 2.3.5.1 Session Type The Session Type allows the administrator to configure the Portal for a PCoIP session or RDP session. For information on the Portal RDP client, see Section 6 Appendix C: Portal RDP Compatibility.

  • Page 64: Bandwidth Tab

    PC-over-IP Administrative Interface User Manual 2.3.5.4 Session Timeout The Session Timeout configures the timeout for a connection. If the PCoIP processor does not detect a network within the timeout period, the PCoIP processor will disconnect the session. 2.3.6 Bandwidth Tab The Bandwidth tab allows the administrator to limit the Portal bandwidth.

  • Page 65: Rdp Tab

    PC-over-IP Administrative Interface User Manual See Section 4.3 Bandwidth and Image Configuration Example for an example on setting the Device Bandwidth Limit. 2.3.7 RDP Tab The RDP tab allows the administrator to configure settings specific to the Remote Desktop Protocol (RDP).

  • Page 66: Language Tab

    PC-over-IP Administrative Interface User Manual 2.3.7.2 Bit Depth The Bit Depth is the RDP session colour bit depth. Possible values are: • 8 bpp (bits per pixel) • 16 bpp • 24 bpp 2.3.7.3 Terminal Server Port The Terminal Server Port field sets the port number that the RDP client connects to.

  • Page 67: Osd Tab

    PC-over-IP Administrative Interface User Manual Figure 2-11: Language Configuration 2.3.8.1 Language The Language field allows the administrator to configure the language of the OSD. Refer to Section 5 Appendix B: Portal Language and Keyboard Support for supported languages. 2.3.8.2 Keyboard Layout The Keyboard Layout field allows the administrator to change the keyboard layout.

  • Page 68: Reset Tab

    PC-over-IP Administrative Interface User Manual Figure 2-12: OSD Configuration 2.3.9.1 Screen-Saver Message The Screen-Saver Message field allows the administrator to change the OSD screen- saver text. The text can be up to 240 characters. The screen-screen saver is a simple black screen with the screen-saver text jumping randomly.

  • Page 69: Diagnostics Window

    PC-over-IP Administrative Interface User Manual Figure 2-13: Reset 2.3.10.1 Reset Parameters The Reset Parameters Reset button resets all configuration and permissions to factory default values. When this button is selected, the OSD will prompt the administrator for confirmation to prevent accidental resets.

  • Page 70: Session Statistics Tab

    PC-over-IP Administrative Interface User Manual Figure 2-14: Event Log 2.4.1.1 View event log message The View event log messages field displays log messages with timestamp information. There are two associated buttons available. Refresh Selecting the Refresh button refreshes the event log messages displayed.

  • Page 71: Figure 2-15: Session Statistics

    PC-over-IP Administrative Interface User Manual Figure 2-15: Session Statistics 2.4.2.1 PCoIP Packets Statistics PCoIP Packets Sent The PCoIP Packets Sent field reports the total number of PCoIP packets sent from the Portal to the Host in the last active session.

  • Page 72: Pcoip Processor Tab

    PC-over-IP Administrative Interface User Manual 2.4.3 PCoIP Processor Tab The PCoIP Processor tab allows the administrator to view the uptime of the Portal PCoIP processor since last boot. Note: The PCoIP Processor Uptime can also be viewed in the Webpage Administration Interface.

  • Page 73: Information Window

    PC-over-IP Administrative Interface User Manual Figure 2-17: Ping 2.4.4.1 Ping Settings IP Address IP Address to ping Interval Interval between ping packets Packet Size Size of ping packet 2.4.4.2 Packets Sent Number of ping packets sent Received Number of ping packets received 2.5 Information Window...

  • Page 74: Figure 2-18: Version

    PC-over-IP Administrative Interface User Manual Figure 2-18: Version 2.5.1.1 VPD Information Vital Product Data (VPD) is information provisioned by the factory to uniquely identify each Portal or Host. Table 2-3: VPD Information MAC Address Portal unique MAC address Portal unique identifier...

  • Page 75: User Settings Window

    PC-over-IP Administrative Interface User Manual 2.5.1.4 Bootloader Information The Bootloader information reflects the current PCoIP bootloader details. Table 2-5: Firmware Information Bootloader Version Version of the current PCoIP bootloader Bootloader Build ID Revision code of the current PCoIP bootloader Bootloader Build Date Build date of the current PCoIP bootloader 2.6 User Settings Window...

  • Page 76: Keyboard Tab

    PC-over-IP Administrative Interface User Manual Mouse Speed The Mouse Speed field allows the Portal mouse cursor speed to be configured. 2.6.2 Keyboard Tab The Keyboard tab allows a user to change the keyboard repeat settings for the OSD and RDP sessions.

  • Page 77: Password Window

    PC-over-IP Administrative Interface User Manual Figure 2-21: Image Minimum Image Quality The Minimal Image Quality slider allows a user to make compromises between image quality and frame rate when network bandwidth is limited. Some usage cases may require lower-quality images at a higher frame rate, while in other cases higher-quality images at a lower frame rate may be preferred.

  • Page 78: Figure 2-22: Change Password

    PC-over-IP Administrative Interface User Manual Figure 2-22: Change Password Old Password The Old Password field must match the current administrative password for the change to take place. New Password The New Password field will be the new administrative password for both the web interface and the local OSD GUI.

  • Page 79: Overlay Windows

    PC-over-IP Administrative Interface User Manual Overlay Windows Overlay windows provide a mechanism for displaying information to the user while a PCoIP session is in progress. These windows are occasionally displayed on top of the user’s remote session. Status overlay windows are used to show network, USB device status and monitor status in the form of icons and text.

  • Page 80: Video Source Overlays

    PC-over-IP Administrative Interface User Manual Figure 3-3: Half-Duplex Overlay Half-duplex network connection The overlay will be displayed until the session ends. Refer to Section 1.6.2.7 Ethernet Mode for more information on network configuration. 3.4 Video Source Overlays Improper connection of the Host video source is denoted by two possible overlays.

  • Page 81: Appendix A: Usage Examples

    PC-over-IP Administrative Interface User Manual Appendix A: Usage Examples 4.1 Peer-to-Peer Direct Connection Example This example provides an overview of configuring a Portal and Host for a direct connection, i.e. without the use of a Connection Management Server or the Enable Host Discover option.

  • Page 82: Figure 4-1: Portal Connection Management Peer-To-Peer Configuration

    PC-over-IP Administrative Interface User Manual Figure 4-1: Portal Connection Management Peer-to-Peer Configuration 4. Ensure Enable Connection Management is not selected 5. Select the Session webpage from the Configuration menu...

  • Page 83: Figure 4-2: Portal Session Webpage Peer-To-Peer Configuration

    PC-over-IP Administrative Interface User Manual Figure 4-2: Portal Session Webpage Peer-to-Peer Configuration 6. In the Identify Peer by field, select IP address 7. Enter the Host IP address in Peer IP Address field, e.g. 192.168.50.107 8. Enter the Host MAC address in Peer MAC Address field, e.g. 00-1C-8A-03-00-CA 9.

  • Page 84: Configuring The Host Peer-To-Peer Operation

    PC-over-IP Administrative Interface User Manual Figure 4-3: Portal PCoIP Processor Webpage Peer-to-Peer Configuration 11. Select the Reset button to reset the PCoIP processor 4.1.2 Configuring the Host Peer-to-Peer Operation Configure the Host for peer-to-peer direct connection: 1. Open the Host Administration Web Interface by using an internet browser to open the Host IP address, e.g.

  • Page 85: Figure 4-4: Host Connection Management Peer-To-Peer Configuration

    PC-over-IP Administrative Interface User Manual Figure 4-4: Host Connection Management Peer-to-Peer Configuration 4. Ensure Enable Connection Management is not selected 5. Select the Session webpage from the Configuration menu...

  • Page 86: Initiating The Peer-To-Peer Session

    PC-over-IP Administrative Interface User Manual Figure 4-5: Host Session Webpage Peer-to-Peer Configuration 6. Ensure Accept Any Peer is not selected so that other Portals cannot start a PCoIP session with the Host 7. Enter the Portal MAC address in Peer MAC Address field, e.g. 00-1C-59-00-05-0E 8.

  • Page 87: Dhcp And Enable Host Discovery Example

    PC-over-IP Administrative Interface User Manual Figure 4-6: Peer-to-Peer Connect Screen 2. When connected, the Host computer is ready to use over PCoIP 4.2 DHCP and Enable Host Discovery Example This example covers configuring the Portal and Host for use with a DHCP server and the Host Discovery feature without the use of a Connection Management Server.

  • Page 88: Figure 4-7: Portal Connection Management Dhcp & Discovery Configuration

    PC-over-IP Administrative Interface User Manual 2. Log in to the Portal Administration Web Interface 3. Select the Connection Management webpage from the Configuration menu Figure 4-7: Portal Connection Management DHCP & Discovery Configuration 4. Ensure Enable Connection Management is not selected 5.

  • Page 89: Figure 4-9: Portal Network Webpage Dhcp Configuration

    PC-over-IP Administrative Interface User Manual 7. Select the Apply button to accept the changes 8. Select Continue to complete configuration 9. Select the Network webpage from the Configuration menu Figure 4-9: Portal Network Webpage DHCP Configuration 10. Select Enable DHCP 11.

  • Page 90: Configuring Host Dhcp And Discovery

    PC-over-IP Administrative Interface User Manual Figure 4-10: Portal PCoIP Processor Webpage DHCP & Discovery Configuration 13. Select the Reset button to reset the PCoIP processor 4.2.2 Configuring Host DHCP and Discovery Configure the Host for DHCP and Discovery: 1. Open the Host Administration Web Interface by using an internet browser to open the Host IP address, e.g.

  • Page 91: Figure 4-11: Host Connection Management Dhcp & Discovery Configuration

    PC-over-IP Administrative Interface User Manual Figure 4-11: Host Connection Management DHCP & Discovery Configuration 4. Ensure Enable Connection Management is not selected 5. Select the Discovery webpage from the Configuration menu Figure 4-12: Host Discovery Webpage Enable Discovery Configuration 6. Select Enable Discovery 7.

  • Page 92: Figure 4-13: Host Network Webpage Dhcp Configuration

    PC-over-IP Administrative Interface User Manual Figure 4-13: Host Network Webpage DHCP Configuration 9. Select Enable DHCP 10. Select the Apply button to accept the changes Note: Once configured for DHCP, the IP address will be leased from the DHCP server.

  • Page 93: Initiating Dhcp Discovery Session

    PC-over-IP Administrative Interface User Manual 12. Select the Reset button to reset the PCoIP processor Note: The Host will not reset immediately. The reset will be deferred until the Host PC restarts, enters standby, hibernates or powers off. 4.2.3 Initiating DHCP Discovery Session Start the DHCP discovery session: 1.

  • Page 94: Configuring The Host Bandwidth Limit To 25 Mbps

    PC-over-IP Administrative Interface User Manual Figure 4-17 shows simplified bandwidth requirements for each user assuming they each had the full 100 Mbps available. The figure shows that network demand for each user peaks only for short periods (e.g. when opening/closing windows, scrolling a page, etc.).

  • Page 95: Figure 4-18: Host Bandwidth Limit Configuration (25 Mbps)

    PC-over-IP Administrative Interface User Manual Note: For this example, it is assumed that very little data is required from the Portal back to the Host (i.e. USB keyboard and mouse data), and therefore the only the Host bandwidth is limited. To be complete, the Portal bandwidth limit could also be configured.

  • Page 96: Configuring Image Properties

    PC-over-IP Administrative Interface User Manual Figure 4-19: Simplified User Bandwidth Requirements (25 Mbps) 4.3.2 Configuring Image Properties In the above section, the bandwidth was limited to 25 Mbps with a bandwidth target of 20 Mbps. Depending on the usage, it is possible that users may occasionally require more than that bandwidth limit to fully render their display information at maximum quality and full frame rate.

  • Page 97: Figure 4-20: Portal Minimum Image Quality Configuration

    PC-over-IP Administrative Interface User Manual can reduce the amount of bandwidth required per user while maintaining a minimum limit on the user experience. Note: This example uses the Administration Web Interface for configuring the Portal for Minimum Image Quality and Maximum Initial Image Quality. The Portal OSD may also be used to configure the Portal.

  • Page 98: Configuring The Host Bandwidth Limit To 0 Mbps (No Limit)

    PC-over-IP Administrative Interface User Manual the Maximum Initial Image Quality to 60 was a preferable way of reducing bandwidth requirements than setting a hard limit on the Device Bandwidth Limit. Regardless of the Maximum Initial Image Quality setting, the PCoIP system will always build unchanged regions of the display to a lossless image.

  • Page 99: Usb Permissions Example

    PC-over-IP Administrative Interface User Manual 4. Enter 0 in the Device Bandwidth Target field to enable no limit 5. Select the Apply button to accept the changes 6. Repeat for the other three users’ Hosts The bandwidth limit and target are now set to 0 Mbps (no limit) for each user. Due to the nature of the users’...

  • Page 100: Figure 4-23: Usb Permissions Example: Add New Button

    PC-over-IP Administrative Interface User Manual Figure 4-23: USB Permissions Example: Add new Button 2. When the entry fields expand, select Class from the Add New drop-down menu to authorize a class of devices Figure 4-24: USB Permissions Example: Selecting the Class Entry Type...

  • Page 101: Figure 4-25: Usb Permissions Example: Selecting The Device Class

    PC-over-IP Administrative Interface User Manual Figure 4-25: USB Permissions Example: Selecting the Device Class 4. Select Printer from the Sub Class drop-down menu to authorize a specific class of printers (otherwise, the sub class and protocol could be left as Any) Figure 4-26: USB Permissions Example: Selecting the Sub Class 5.

  • Page 102: Authorizing Usb Device By Vendor/Product Id

    PC-over-IP Administrative Interface User Manual Figure 4-27: USB Permissions Example: Selecting the Protocol 6. Select Apply to save the changes to flash and complete the configuration Figure 4-28: USB Authorization Example: Class Authorization 4.4.2 Authorizing USB Device By Vendor/Product ID...

  • Page 103: Figure 4-29: Usb Permissions Example: Add New Button

    PC-over-IP Administrative Interface User Manual Figure 4-29: USB Permissions Example: Add new Button 2. When the entry fields expand, select ID from the Add New drop-down menu to authorize a device by its vendor/product ID Figure 4-30: USB Permissions Example: Selecting the Class Entry Type...

  • Page 104: Figure 4-31: Usb Permissions Example: Entering Vendor Id And Product Id

    PC-over-IP Administrative Interface User Manual Figure 4-31: USB Permissions Example: Entering Vendor ID and Product ID 4. Select Apply to save the changes to flash and complete the configuration Figure 4-32: USB Permissions Example: Vendor ID and Product ID Authorization...

  • Page 105: Appendix B: Portal Language And Keyboard Support

    PC-over-IP Administrative Interface User Manual Appendix B: Portal Language and Keyboard Support The Portal Firmware can support various languages and keyboard layouts. Information concerning configuring the language and keyboard layout can be found in Section 1.6.8 Language for the web interface and Section 2.3.8 Language for the OSD.
  • Page 106 PC-over-IP Administrative Interface User Manual Japanese 106x Latin American Latin American (accent keys) Portuguese ISO-8859-1 Portuguese ISO-8859-1 (accent keys) Italian ISO-8859-1 Spanish ISO-8859-1 Spanish ISO-8859-1 (accent keys) Spanish ISO-8859-15 (accent keys) Swiss-French ISO-8859-1 Swiss-French ISO-8859-1 (accent keys) Swiss-French Codepage 850...

  • Page 107: Appendix C: Portal Rdp Compatibility

    PC-over-IP Administrative Interface User Manual Appendix C: Portal RDP Compatibility The Portal Firmware also supports a Remote Desktop Protocol client. This can be enabled for a lower-than-PCoIP experience. Table 6-1 below outlines the Portal RDP client capability. For information concerning enabling the RDP client, see Sections 1.6.5.2 Session Type, 1.6.7 RDP, 2.3.5.1 Session Type and 2.3.7 RDP.
  • Page 108 PC-over-IP Administrative Interface User Manual (Vista)

Table of Contents
