Summary of Contents for EUROCOM Tablet V09.1.20

  • Page 1 V09.1.20...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 6: Instructions For Care And Operation

    Preface Instructions for Care and Operation The computer is rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. •...

  • Page 7: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.

  • Page 8: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Pay careful attention to the instructions on swapping the battery. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 9: Travel Considerations

    Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Disconnect the AC/DC adapter and cables.
  • Page 10 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the computer - For security, don’t let it out of your sight. In some areas, computer theft is very common.
  • Page 11 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
  • Page 12 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...

  • Page 13: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
  • Page 14 Preface Upgrading the Memory and HDD/SSD If you want to upgrade your computer by upgrading the system memory or the hard disk drive/solid state drive you will need to contact your customer service representative. We recommend that you do not do this yourself, since if it is done incorrectly you may damage the mainboard.

  • Page 15: Table Of Contents

    Preface Contents Notice .................I Calibrating the Touch Panel ........1-11 FCC Statement .............II Pen Options & Tablet Settings .........1-13 Instructions for Care and Operation ......IV On-Screen Keyboard ..........1-14 Power Safety ............... V System Map: LCD Panel View - Front ......1-15 Battery Precautions ............
  • Page 16 Preface 5-in-1 Card Reader ............2-3 Conserving Battery Power .........3-11 ExpressCard Slot ............2-4 Battery Life ..............3-12 Inserting and Removing ExpressCards .......2-4 New Battery ..............3-12 Audio Features ...............2-5 Recharging the Battery with the AC/DC Adapter ..3-12 Tablet PC Options ............2-6 Proper handling of the Battery Pack ......3-13 Screen Orientation ............2-7 Battery FAQ ..............3-14 Adding a Printer ............2-12...
  • Page 17 Preface Bluetooth Module ............4-7 Hyperthreading (Advanced Menu) ........5-9 Wireless LAN Module ..........4-7 Security Menu ..............5-10 PC Camera Module ............4-7 Set Supervisor Password (Security Menu) ....5-10 Fingerprint Reader Module ........4-7 Set User Password (Security Menu) ......5-11 Diskette access (Security Menu) ........5-11 BIOS Utilities Virus check reminder (Security Menu) .......5-11 System backup reminder (Security Menu) ....5-12...
  • Page 18 Preface Configuring the COM Port for the GPS Module ..6-23 BIOS ................C-2 RFID Reader Module ..........6-24 Drop Protection ............. C-2 Configuring the COM Port for the RFID Reader ..6-25 Storage ................C-2 Audio ................C-2 Troubleshooting Button Keys ..............C-2 Interface ................
  • Page 19 Preface Video Features .............. D-9 RFID Reader Module ..........D-56 Attaching Other Displays ........... D-12 ExpressCard 34 Approved List Display Modes ............D-13 Power Management Features ........D-17 The Power Sources ............. D-18 Turning on the Computer ..........D-19 Power Schemes ............D-20 System Power Options ..........
  • Page 20 Preface XVIII...

  • Page 21: Quick Start Guide

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 22: Introduction

    Quick Start Guide Introduction This semi-ruggedized tablet computer provides an ideal platform for outdoor computer use with an IP54 (Ingress Protection) rating against dust and spray and features an optional sunlight readable LCD touch panel; all touch panels support both finger and stylus pen input. Hard disk drive protection is provided by G-Sensor software that protects the hard disk drive from a drop of up to 40CM when the system is powered on, and the hard disk drive is shock mounted offering protection from a drop of 120CM when the system is powered off.
  • Page 23 Quick Start Guide Optional Accessories This computer features a range of options including a GPS module (including an optional active aerial), HF RFID reader, as well as a range of optional accessories including car adapter, charger box, USB to RS 232 cable, hand holder, shoulder strap and carrying handle.
  • Page 24 Quick Start Guide Attaching the Optional Hand Holder. The hand holder offers ease of use when using the computer on the move outdoors. Attach the hand holder as follows: Place the hand holder at the rear of the computer with the screws facing inwards towards the computer. Align the screws on the hand holder with the screw holes in the rear of the case (you may need to adjust the straps to do this).

  • Page 25: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - 1 “BIOS Utilities” on page 5 - 1 in the reminder of the User’s Manual.

  • Page 26: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows Vista or XP) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...

  • Page 27: System Software

    Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the following operating systems are sup- ported.

  • Page 28: System Startup

    Quick Start Guide System Startup Remove all packing materials. Place the computer flat on a stable surface with LCD panel facing upwards. Shutdown Touch Panel Input Device Please note that you should always shut your computer down by choosing the Turn Do not use any sharp or point- Off Computer command from the Start ed objects as your input de-...

  • Page 29: Operating System Setup

    Quick Start Guide Operating System Setup If you are installing new system software, or are re-configuring your computer for a different system, make sure you configure the appropriate OS setting in the BIOS before installing a new operating system. 1. Start-up the computer and press <F2> to enter the BIOS. 2.

  • Page 30: System Software Installation

    Quick Start Guide System Software Installation Your computer may come with an operating system software and all necessary drivers pre-installed. If you are installing new system software, or are re-configuring your computer for a different system, you will need to in- stall the drivers after installing the operating system.

  • Page 31: Tablet Notebook Input

    Quick Start Guide Tablet Notebook Input Use the stylus pen provided to interact with the computer in the same way you would use the mouse (tap twice to double-click and keep the pen in contact with the screen to right-click). Before using the stylus pen you should calibrate the touch screen.
  • Page 32 Quick Start Guide 4. Use the stylus pen to touch the blinking symbol until symbol changes color (maintain contact until the symbol stops blinking) and you will be prompted to lift up the pen. 5. Repeat the process for all the remaining screen points. 6.

  • Page 33: Pen Options & Tablet Settings

    Quick Start Guide Pen Options & Tablet Settings Configure the stylus pen input settings, from the Pen and Input Devices control pane in Windows Vista; the Tablet PC Settings control panel allows you to configure the tablet screen appearance. Access the control panels as follows: Click Start, and click Control Panel (or point to Settings and click Control Panel).

  • Page 34: On-Screen Keyboard

    Quick Start Guide On-Screen Keyboard The On-Screen Keyboard allows you to input text without the use of a keyboard. Move the pen over any char- acter and then tap it to activate it. Click Start, and click Control Panel (or point to Settings and click Control Panel). Double-click Ease of Access and click Start On-Screen Keyboard.

  • Page 35: System Map: Lcd Panel View - Front

    Quick Start Guide System Map: LCD Panel View - Front Figure 1 - 10 LCD Panel View - Front Built-In Microphone LED Indicators LCD Touch Panel Screen Speakers Fingerprint Reader 5 Function Buttons Protective Surround System Map: LCD Panel View - Front 1 - 15...

  • Page 36: Led Indicators

    Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Orange DC Power is Plugged In Green The Computer is On Blinking Green The Computer is in Sleep Mode Orange The Battery is Charging Green...

  • Page 37: Function Buttons

    Quick Start Guide Function Buttons The function buttons provide easier access to functions on the computer. Key Buttons Icon Description Page Mode / Zoom Mode Toggle Access / Hide the On-Screen Menu Page Mode = Page Up / Page Down Zoom Mode (for Picture files - Does NOT Zoom the Camera) = Zoom In / Zoom Out Run the BisonCap Application...

  • Page 38: On-Screen Menu

    Quick Start Guide On-Screen Menu Pressing the Menu button (or double-click the Pop Menu icon in the taskbar) on the computer will bring up the on-screen menu (make sure you install the pop menu driver - see “Pop Menu Utility” on page 4 - 6).
  • Page 39 Quick Start Guide Function On-Screen Button Function On-Screen Button Brightness Bluetooth Module Decrease/Increase Power Toggle Volume Decrease/ PC Camera Module Increase Power Toggle G-Sensor Mute Toggle Protection Mode Toggle GPS Module Power Display Toggle Toggle Display Battery RFID Module Level Power Toggle WLAN Module Power Toggle...

  • Page 40: G-Sensor - Hard Disk Drive Protection

    Quick Start Guide G-Sensor - Hard Disk Drive Protection The built-in G-Sensor gives protection to the system and hard disk (the G-Sensor does not function with Solid State Drives) in the event that the computer is accidentally dropped when the system is powered on (40cm drop approved when the system is powered on and 120cm drop approved when the system is powered off).

  • Page 41: System Map: Rear View

    Quick Start Guide System Map: Rear View Figure 1 - 13 LCD Rear View - Built-In PC Camera GPS Active Aerial Socket (for optional Active Aerial) Protective Surround Stylus Pen & Holder Battery Gauge Battery Battery Information “Battery Informa- tion” on page 3 - 9 for full instructions.

  • Page 42: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 14 Left View Security Lock Slot Stylus Pen & Holder DC-In Jack 1 * USB 2.0 Port External Optical (CD/ DVD) Device Drives Touch Panel Input Device To install applications Do not use any sharp or pointed objects as your input de- and drivers etc.

  • Page 43: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 15 Right View Headphone-Out Jack External Monitor Port Card Reader Cover ExpressCard 34 Slot (see below) 5-in-1 Card Reader ExpressCard Support 5-in-1 Card Reader There is a list of approved The card reader allows you to use the most popular digital storage card ExpressCard modules listed formats:...

  • Page 44: System Map: Top & Bottom Views

    Quick Start Guide System Map: Top & Bottom Views Figure 1 - 16 Top & Rear Views Strap Holders (for Carrying Strap) Power Button RFID (Radio Frequency Identification) Reader (Factory Option) RJ-45 LAN Jack 1 * USB 2.0 Ports External Optical (CD/DVD) Device Drives To install applications and drivers etc.

  • Page 45: Windows Vista Start Menu & Control Panel

    Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 46: Video Features

    Quick Start Guide Video Features You can switch display devices, and configure display options, from the Display Settings control panel (in Per- sonalization) in Windows Vista as long as the appropriate Intel video driver is installed. To access Display Settings in Windows Vista: Click Start, and click Control Panel (or point to Settings and click Control Panel).
  • Page 47 Quick Start Guide Figure 1 - 18 - Display Properties Desktop Intel Display Mode Description Single Mode One of the connected displays is used as the display device Intel(R) Dual Display Clone Mode Both connected displays output the same view and may be configured independently Extended Desktop Mode Both connected displays are treated as separate devices, and act as a virtual desktop Table 1 - 5 - Display Options...

  • Page 48: Power Options

    Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 25) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, display and sleep mode from the left menu. Note that the Power saver plan may have an affect on computer performance.

  • Page 49: Optimizing Battery Life

    Quick Start Guide Optimizing Battery Life To optimize your battery life, follow the instructions below and also see “Conserving Battery Power” on page 3 10. You can check the battery’s current capacity from the gauge at the rear of the computer (see “Battery Gauge”...

  • Page 50: Removing The Battery

    Quick Start Guide Removing the Battery If you need to remove the battery follow the procedure below. Turn the computer off (unless you are hot swapping the battery), and turn it over. Remove screws at points Remove the battery cover Grip the tab and lift the battery out in the direction of the arrow Figure 1 - 21 - Battery Removal...

  • Page 51: Hot-Swapping The Battery

    Quick Start Guide Hot-Swapping the Battery If you have more than one battery included in your purchase option you can swap the battery while the system is running. Check the level of the backup battery from the on-screen menu. Press the battery level button to display the indicator: Main Battery Level Bridge Battery Level...
  • Page 52 Quick Start Guide 1 - 32...

  • Page 53: Features & Components

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer. • Hard Disk Drive/Solid State Drive • 5-in-1 Card Reader • ExpressCard Slot • Audio Features •...

  • Page 54: Hard Disk Drive/Solid State Drive

    Features & Components Hard Disk Drive/Solid State Drive The hard disk drive or solid state drive (factory options) is used to store your data Upgrading the in the computer. The HDD/SSD can be taken out (please check with your service HDD/SSD representative before undertaking any upgrade or replacement procedures to find out if this will VOID your warranty) to accommodate other 2.5"...

  • Page 55: 5-In-1 Card Reader

    Features & Components 5-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).

  • Page 56: Expresscard Slot

    Features & Components ExpressCard Slot The computer is equipped with an ExpressCard 34 slot. ExpressCards are the suc- ExpressCard cessors to PCMCIA (PC Cards). Make sure you install the Card Reader driver Slot Cover Make sure you keep card reader cover closed when not in use.

  • Page 57: Audio Features

    Features & Components Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).

  • Page 58: Tablet Pc Options

    Features & Components Tablet PC Options Chapter 1 contains basic information on calibration (see “Calibrating the Touch Panel” on page 1 - 11), pen options and tablet settings (see “Pen Options & Tablet Settings” on page 1 - 13) and the On-Screen keyboard (see “On-Screen Keyboard”...
  • Page 59 Features & Components Screen Orientation If you prefer to orientate the screen differently follow these steps. Screen Orientation - Windows Control Panel Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Mobile PC (or just double-click Tablet PC Settings) and then click Tablet PC Settings.
  • Page 60 Features & Components Screen Orientation - Intel GMA Control Panel Open the Display Settings control panel (see “Video Features” on page 1 - and click Advanced Settings (button). Click the Intel(R)... tab and click Graphics Properties (button). Go to the Intel GMA control panel (see “Video Features”...
  • Page 61 Features & Components Touch Package Settings You can also configure the pen options from the Touch Package control panel. Other Tools Double-click the Touch tool utility icon on the desktop OR from the Touch Package folder in the Programs/All Programs group (the driver must be The Touch Package installed).
  • Page 62 Features & Components Pen and Input Devices You can configure the pen options from the Pen and Input Devices control panel. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Mobile PC (or just double-click Pen and Input Devices) and then click Pen and Input Devices.
  • Page 63 Features & Components Other Useful Windows Vista Features for Tablet PC Users Multi-Select Files in Windows Explorer The option to multi-select files in Windows Explorer in Windows Vista is very useful when using a pen as your input device. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Appearance and Personalization and click Folder Options (or just double-click Folder Options).

  • Page 64: Adding A Printer

    Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- ble to the printer.

  • Page 65: Power Management

    Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.

  • Page 66: The Power Sources

    Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack on the left of the computer.

  • Page 67: Turning On The Computer

    Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on press the power but- Shut Down ton and release it. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot- ways shut your comput- er down by choosing the key button when you press and release it in less than 4 seconds (pressing the power...

  • Page 68: Power Plans

    Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
  • Page 69 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Intel GMA Driver Power Settings Choose High performance for maximum performance when the computer is pow- Use the Power Set-...

  • Page 70: Power-Saving States

    Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where Power Button you left off. Sleep is the default power-saving state in Windows Vista. The Power Button Earlier versions of Windows used Stand By and Hibernate as system power-saving the Start Menu (in Clas- sic View use the Shut states.

  • Page 71: Hibernate

    Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.

  • Page 72: Configuring The Power Buttons

    Power Management Configuring the Power Buttons The power button, sleep button (on any attached keyboard) or Sleep command from Password the Lock Button Menu in Windows Vista may be set to send the computer in to a Protection power-saving state. It is recommended that you enable a password on wake up in order to...

  • Page 73: Resuming Operation

    Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button on an attached keyboard. Power Status To Resume Icon Color Power Off Press the Power Button Press the Power Button Table 3 - 1 Sleep...

  • Page 74: Battery Information

    Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power When the battery is criti- Your computer’s battery power is dependent upon many factors, including the pro- cally low, immediately grams you are running, and peripheral devices attached.

  • Page 75: Conserving Battery Power

    Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.

  • Page 76: Battery Life

    Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...

  • Page 77: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.

  • Page 78: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
  • Page 79 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears). Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...

  • Page 80: Battery Gauge

    Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

  • Page 81: Battery Indicators

    Power Management Battery Indicators On-screen indicators will display the battery status if the battery level button is pressed or the AC/DC adapter is not connected. Action Icon Description The on-screen Main Battery Level Indicator battery level Table 3 - 1 button is pressed.
  • Page 82 Power Management 3 - 18...

  • Page 83: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities This chapter deals with installing the drivers and utili- What to Install ties essential to the operation or improvement of some of the computer’s subsystems. The system takes ad- You will need to attach a CD/DVD drive to the com- puter in order to access the drivers on the Device Driv- vantage of some newer hardware components for ers &...

  • Page 84: Driver Installation

    Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers (button), or Option Driv- Drivers Installer menu below.
  • Page 85 Drivers & Utilities Manual Driver Installation Vista (SP1) Driver Page # Click Browse CD (button) in the Drivers Installer ap- plication and browse to the executable file in the ap- Chipset Page 4 - 5 propriate driver folder. Video Page 4 - 5 Windows Update Page 4 - 5 After installing all the drivers make sure you enable...

  • Page 86: Updating/Reinstalling Individual Drivers

    Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control (Win Vista) If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue/Al- this go to the Control Panel in the Windows OS and low, and follow the installation procedure as directed.

  • Page 87: Driver Installation Procedure

    Drivers & Utilities Driver Installation Procedure Chipset Insert the Device Drivers & Utilities + User’s Manual 1. Click 1.Install Chipset Driver > Yes. disc into your attached CD/DVD drive and click In- 2. Click Next > Yes > Next > Next. stall Drivers (button), or Option Drivers (button) to 3.

  • Page 88: Touch Panel Application

    Drivers & Utilities Touch Panel Application 1. Click 4.Install Touch Panel Driver > Yes. 2. Click Next > Next > Install. Windows Update 3. Click Finish. After installing all the drivers make sure you enable Win- 4. Click OK to restart the computer. dows Update in order to get all the latest security up- 5.

  • Page 89: Optional Drivers

    Drivers & Utilities Optional Drivers Bluetooth Module See the pages indicated overleaf for the driver installa- Note: The operating system is the default setting for tion procedures for any modules included in your pur- Bluetooth control in Windows Vista, and does not re- chase option.
  • Page 90 Drivers & Utilities 4 - 8...

  • Page 91: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.

  • Page 92: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...

  • Page 93: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 94: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and manage ba- sic features and subsystems (e.g. port configuration). Note that you will need to attach a USB keyboard to one of the USB ports in order to edit the BIOS settings.

  • Page 95: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.

  • Page 96: Main Menu

    BIOS Utilities Main Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:12:05] System Date: [04/24/2009] <Tab>, <Shift Tab>, or Large Disk Access Mode: [DOS] <Enter> selects field. Primary Master [TOSHIBA MK1246GSX-(P] Primary Slave...

  • Page 97: Large Disk Access Mode (Main Menu)

    BIOS Utilities Large Disk Access Mode (Main Menu) This refers to the representation of hard disk drive geometries as addressed by dif- ferent operating systems. Select “Other” if you are using systems such as Novell, UNIX etc. Select “DOS” (default) if you are using Windows. Primary Master/ Primary Slave (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a HDD/optical de- vice on the computer’s Primary Master/Primary Slave channels is applicable.

  • Page 98: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 Phoenix SecureCore(tm) Setup Utility Advanced Menu Main A A dvanced Advanced Security Boot Exit Item Specific Help Installed O/S: [WinXP/Vista] Reset Configuration Data: [No] Select the operating Boot-time Diagnostic Screen: [Disabled] system installed on POST Boot Sound [Disabled] your system which you...

  • Page 99: Reset Configuration Data (Advanced Menu)

    BIOS Utilities Reset Configuration Data (Advanced Menu) This item is set to No as default. You can change the setting to Yes if you have in- stalled a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot.

  • Page 100: Security Menu

    BIOS Utilities Security Menu Phoenix SecureCore(tm) Setup Utility Security Menu Security Main Advanced S S e e c c u u r r i i t t y y Boot Exit Item Specific Help changes Supervisor Password Is: Clear make here affect the User Password Is: Clear Supervisor Password...

  • Page 101: Set User Password (Security Menu)

    BIOS Utilities Set User Password (Security Menu) You can set a password for user mode access to the Phoenix SecureCore Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless you choose to set a Password on Boot (see below). Many menu items in the Phoenix SecureCore Setup Utility cannot be modified in user mode.

  • Page 102: System Backup Reminder (Security Menu)

    BIOS Utilities System backup reminder (Security Menu) You can set a system backup reminder here to be enabled at system boot. The re- minder can be set to be given Daily, Weekly (every Monday), or Monthly (on the Password Warning 1st day of the month).

  • Page 103: Boot Menu

    BIOS Utilities Boot Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 5 Main Advanced Security Boot Exit Boot Menu Item Specific Help Boot priority order: IDE FDC: Keys used to view or USB CDROM: configure devices: USB KEY: Up and Down arrows USB HDD: select a device.

  • Page 104: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 Phoenix TrustedCore(tm) Setup Utility Main Advanced Security Boot Exit Exit Menu Item Specific Help Exit Saving Changes Exit System Setup and Exit Discarding Changes save your changes to Load Setup Defaults CMOS. Discard Changes Save Changes Help...

  • Page 105: Modules

    Modules Chapter 6: Modules Wireless Device Overview Operation Aboard This chapter contains information on the following modules, which come with your Aircraft computer, depending on the configuration purchased. If you are unsure please con- The use of any portable tact your service representative. electronic transmission devices aboard aircraft usually...

  • Page 106: Bluetooth Module

    Modules Bluetooth Module The operating system’s Bluetooth Devices (the Bluetooth module is a Factory Op- Wireless Device tion) control panel is used to configure the Bluetooth settings in Windows Vista, and Operation Aboard therefore does not require a driver. Use the On-Screen Menu button to power Aircraft ON the Bluetooth module (see...

  • Page 107: Bluetooth Configuration In Windows Vista

    Modules Bluetooth Configuration in Windows Vista Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar Make the device discoverable (to do this check your device documentation). Icon If you cannot see the To Turn the Bluetooth Module On Bluetooth icon in the...
  • Page 108 Modules To Add a Bluetooth Device Access the Bluetooth Devices control panel. Click Options (tab), and make sure that Allow Bluetooth devices to connect to Passkey Options this computer check box (Connections) has a tick inside it. Click Devices (tab), and then click Add. You can allow the sys- The Add Bluetooth Device Wizard will appear.
  • Page 109 Modules To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click General, type a new name and click OK). •...

  • Page 110: Wireless Lan Module

    Modules Wireless LAN Module Before installing the WLAN module driver use the On-Screen Menu button Wireless Device to power ON (the default setting is OFF) the WLAN module (see “On-Screen Operation Aboard Menu” on page 1 - 18). Make sure you install the drivers in the order indicated in Aircraft Table 4 - 1, on page 4 - The use of any portable...

  • Page 111: Wireless Lan Module

    Modules Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 6 - 5 Taskbar Menus Click icon...
  • Page 112 Modules Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network). Figure 6 - 7 Connecting Move the cursor over the taskbar icon...
  • Page 113 Modules To disconnect from the wireless network you can click the taskbar wireless icon and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make sure that any network you...

  • Page 114: Windows Mobility Center

    Modules Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).

  • Page 115: Pc Camera Module

    Modules PC Camera Module Before installing the PC Camera module driver use the On-Screen Menu button Camera Button to power ON (the default setting is OFF) the PC Camera module (see “On- Screen Menu” on page 1 - 18). Make sure you install the drivers in the order indicated Press the Camera Button Table 4 - 1, on page 4 - to run the BisonCap ap-...
  • Page 116 Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
  • Page 117 Modules Figure 6 - 11 Audio Setup for PC Camera Right-click PC Camera Module 6 - 13...
  • Page 118 Modules BisonCap BisonCap is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. Pre-Allocating File Space Run the BisonCap program from the Start > Programs/All Programs > Bison- Cam menu (it is recommended that you set the capture file before the capture You may pre-allocate the process - see Set Capture File below).
  • Page 119 Modules Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
  • Page 120 Modules Zoom The BisonCap program allows you to zoom the camera in and out. Run the BisonCap program. Go to Zoom and select Zoom Out/Zoom In. Figure 6 - 12 Zoom/Setting Note that the Zoom Mode buttons DO NOT zoom the camera, but do allow you to Snapshot Folder zoom in and out of captured pictures (e.g.

  • Page 121: Fingerprint Reader Module

    Modules Fingerprint Reader Module If you have included the fingerprint reader in your purchase option you will need to Help & Manual install the driver as per the instructions below. Right-click the taskbar icon Make sure you have administrator’s rights to your computer, and have a Windows to bring up the menu to password enabled for full security protection.

  • Page 122: User Enrollment

    Modules User Enrollment Click Start > Programs/All Programs > Protector Suite > Control Center, or double click the taskbar icon (click Initialize). Fingerprint On the first run of the program you will be asked to click the Accept button to Enrollment accept the license.
  • Page 123 Modules Click the button above any of the fingers to begin the enrollment process for that finger. Swipe the finger until the progress bar reaches 100% to enroll that finger. Fingerprint Repeat the process for all the fingers you wish to enroll (see sidebar), and then Enrollment click Save and Continue.
  • Page 124 Modules 11. Right-click the taskbar icon and select Start Control Center (and then swipe a finger) to allow you to Edit Fingerprints, register Applications, edit Settings and access the Help menu etc. You can also run the Control Center etc. from the Protector Suite item in the Programs/All Programs menu 12.

  • Page 125: Fingerprint Control Center Features

    Modules Fingerprint Control Center Features Application Launcher Help The Application Launcher allows you to register applications to be launched when assigned to a particular finger. Simply copy the application icon on to one of the reg- For more information on istered fingers and ten click OK to close the application window.

  • Page 126: Gps Module

    Modules GPS Module If you have included an Global Positioning System (GPS) receiver module in your purchase option, you will need to obtain map software suitable for your global loca- tion. Map software programs are both commercially available and downloadable di- rectly from the internet.

  • Page 127: Configuring The Com Port For The Gps Module

    Modules Configuring the COM Port for the GPS Module You need to make sure that the COM port for the GPS module is set to COM 3 at a 4800 baud rate. To do this follow the instructions below: Click Start (menu), point to Settings and click Control Panel (or click Control Panel). Double-click Device Manager (icon);...

  • Page 128: Rfid Reader Module

    Modules RFID Reader Module If you have included the RFID Reader module in your purchase option, you will need to obtain software suitable for your system. The scanner for the module is lo- cated at the top of the computer. •...

  • Page 129: Configuring The Com Port For The Rfid Reader

    Modules Configuring the COM Port for the RFID Reader You need to make sure that the COM port for the RFID reader is set to COM 1 at a 9600 baud rate. To do this follow the instructions below: Click Start (menu), point to Settings and click Control Panel (or click Control Panel). Double-click Device Manager (icon);...
  • Page 130 Modules 6 - 26...

  • Page 131: Troubleshooting

    Troubleshooting Chapter 7: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 132: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 133: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 134: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 135: Adding New Hardware/Software

    Troubleshooting Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing (please check with your service representative before undertaking any upgrade procedures to find out if this will VOID your warranty).
  • Page 136 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 137: Problems And Possible Solutions

    Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present but it doesn’t work. and seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
  • Page 138 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer isn’t sitting on a thermal surface. Make sure you’re using the correct hot. adapter. Make sure that your computer is completely powered off before putting it into a travel bag (or any such container).
  • Page 139 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious.
  • Page 140 Troubleshooting Problem Possible Cause - Solution The Hibernate function You have a computer with 4GB of RAM and have installed Windows Vista Service Pack 1. This disappeared is a known issue if your computer has 4GB of RAM and is running Windows Vista Service Pack Windows Vista).

  • Page 141: Interface (Ports & Jacks)

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Ports and Jacks View Port/Jack Description...
  • Page 142 Interface (Ports & Jacks) View Port/Jack Description 4.Headphone-Out Jack Headphones or speakers may be connected through this jack. Right View Note: Set your system’s volume to a reduced level before connecting to this jack. 5.External Monitor Port This port allows you to connect an external monitor, or Flat Panel Display, to get dual video or simultaneous display on the LCD and external monitor/FPD.

  • Page 143: Intel Video Driver Controls

    Intel Video Driver Controls Appendix B: Intel Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Intel Video Driver Installation DVMT Notes DVMT is not local video Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 - memory.
  • Page 144 Intel Video Driver Controls Intel Graphics Properties More advanced video configuration options are provided by the Intel(R) Graphics Taskbar Icon Media Accelerator Driver for ultra mobile. The Intel GMA control Open the Display Settings control panel (see “Video Features” on page 1 - panel can also be ac- and click Advanced Settings (button).
  • Page 145 Intel Video Driver Controls You may make changes to the devices, color, schemes, Hot Keys etc. by clicking the appropriate menu item or button. Click Information (button) to obtain useful in- formation about the graphics properties of the computer, and see the Support tab in Help Menus Information to get weblinks to the latest information on the Intel Website.

  • Page 146: Display Settings

    Intel Video Driver Controls Display Settings You can adjust the Color Quality, Screen Resolution and Refresh Rate for any at- tached display(s) from the Intel(R) GMA Driver for ultra mobile control panel, or from Display Settings (see page 1 - 26) in Windows.

  • Page 147: Power Settings

    Intel Video Driver Controls Power Settings Use the Power Settings control to allow the Intel(R) GMA Driver for ultra mo- bile control panel to adjust the power options when the computer is running on bat- tery power. To set the power settings: Attach your external monitor to the external monitor port, and turn it on.

  • Page 148: Attaching Other Displays

    Intel Video Driver Controls Attaching Other Displays Besides the built-in LCD, you can also use an external monitor/flat panel display, On-Screen Menu connected to the external monitor port at the rear of the computer, as your display Button device. The following are the display options: You can use the On- The built-in LCD OR an external monitor/flat panel display connected to the exter- Screen...
  • Page 149 Intel Video Driver Controls ® Configuring Displays from Intel GMA Driver for ultra mobile Go to the Intel GMA control panel (see “Intel Graphics Properties” on page B - 2) and click Display Devices. Multiple Display Click to choose the display option from the Multiple Display menu. Click Apply (and OK to confirm the settings change) and OK (button).
  • Page 150 Intel Video Driver Controls Display Modes Single Display Only one of your attached displays is used. Intel(R) Dual Display Clone (mirrored) This mode will drive multiple displays with the same content. Each device may be configured independently for different resolutions, refresh rates, color quality etc. Use this feature to display the screen through a projector for a presentation.
  • Page 151 Intel Video Driver Controls To Enable Intel(R) Dual Display Clone Attach your external monitor to the external monitor port, and turn it on. Go to the Intel GMA control panel (see “Intel Graphics Properties” on page B - 2) and click Display Devices. Click to choose Intel(R) Dual Display Clone (Multiple Display).
  • Page 152 Intel Video Driver Controls To Enable Extended Desktop Attach your external monitor to the external monitor port, and turn it on. Go to the Intel GMA control panel (see “Intel Graphics Properties” on page B - Display Settings 2) and click Display Devices. Extended Desktop Click to choose Extended Desktop (Multiple Display).
  • Page 153 Intel Video Driver Controls Using Windows Vista to Enable Extended Mode Attach your external display to the external monitor port, and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Display Settings Windows Mobility Center control panel (Mobile PC >...
  • Page 154 Intel Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the external monitor port, and turn it on. Open the Display Settings control panel (see “Video Features” on page 1 - 26). Click the monitor icon (e.g. ), and make sure you have checked “Extend my Windows desktop onto this monitor.”...

  • Page 155: Specifications

    Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.

  • Page 156: Processor Options

    Specifications Processor Options Video Adapter Audio Intel® Atom Processor: Intel® US15W Integrated Video Intel® High Definition Audio (Intel® Graphics Media Accelerator 500) Built-In Microphone 512K On-die L2 Cache, 533MHz FSB, 2 * Built-In Speakers (1.5W) FC-BGA8 Package Video Camera Z520 (1.33GHz), Z530 (1.60GHz), Z540 Button Keys (1.86GHz) 2M Pixel Video Camera Module with USB...

  • Page 157: Card Reader/Expresscard

    Specifications Card Reader/ExpressCard Power Dimensions & Weight Intel® US15W Integrated 5-in-1 Card Full Range AC/DC Adapter 239mm (w) * 190mm (d) * 30mm (h) Reader (SD/ Mini SD/ SDIO/ MMC/ RS AC input 100 - 240V, 50 - 60Hz, Around 1.5 kg With Battery MMC) Note: Mini SD/ SDIO/ RS MMC DC Output 19V, 1.58A or 19V, 1.57A (30 Indicators...

  • Page 158: Factory Options

    Specifications Factory Options GPS Module Bluetooth 2.1 + EDR (Enhanced Data Rate) Module HF RFID Reader 8.9” WSVGA (1024 * 600) TFT LED Backlight LCD with Touch Panel (Stylus Pen & Finger Sensitivity) 8.9” WSVGA (1024 * 600) TFT LED Backlight LCD with Touch Panel (Stylus Pen &...

  • Page 159: Windows Xp Information

    Windows XP Information Appendix D: Windows XP Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows XP OS. D - 1...

  • Page 160: D - 2 Tablet Notebook Input

    Windows XP Information Tablet Notebook Input Use the stylus pen provided to interact with the computer in the same way you would use the mouse (tap twice to double-click and keep the pen in contact with the screen to right-click). Before using the stylus pen you should calibrate the touch screen.
  • Page 161 Windows XP Information 4. Use the stylus pen to touch the blinking symbol until symbol changes color (maintain contact until the symbol stops blinking) and you will be prompted to lift up the pen. 5. Repeat the process for all the remaining screen points. 6.

  • Page 162: On-Screen Menu

    Windows XP Information On-Screen Menu Pressing the Menu button (or double-click the Pop Menu icon in the taskbar) on the computer will bring up the on-screen menu (make sure you install the pop menu driver - see “Pop Menu Utility” on page D - 35).
  • Page 163 Windows XP Information Function On-Screen Button Function On-Screen Button Brightness Bluetooth Module Decrease/Increase Power Toggle Volume Decrease/ PC Camera Module Increase Power Toggle G-Sensor Mute Toggle Protection Mode Toggle GPS Module Power Display Toggle Toggle Display Battery RFID Module Level Power Toggle WLAN Module Power Toggle...

  • Page 164: G-Sensor - Hard Disk Drive Protection

    Windows XP Information G-Sensor - Hard Disk Drive Protection The built-in G-Sensor gives protection to the system and hard disk (the G-Sensor does not function with Solid State Drives) in the event that the computer is accidentally dropped when the system is powered on (40cm drop approved when the system is powered on and 120cm drop approved when the system is powered off).

  • Page 165: Windows Xp Start Menu & Control Panel

    Windows XP Information Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 166: Audio Features

    Windows XP Information Audio Features You can configure the audio options on your computer from the Sounds and Audio Devices Windows con- trol panel, or from the Realtek HD Audio Manager icon in the taskbar/control panel (this will bring up the Realtek Audio Configuration menus).

  • Page 167: Video Features

    Windows XP Information Video Features You can switch display devices, and configure display options, from the Display Properties control panel in Win- dows as long as the appropriate Intel video driver is installed. To access Display Properties in Windows: 1. Click Start, point to Settings and click Control Panel (or just click Control Panel). 2.
  • Page 168 Windows XP Information Display & Graphics Properties Besides the built-in LCD, you can also use an external VGA monitor (CRT) or external Flat Panel Display connected to the external monitor port as your display device. Taskbar Icon You can also access the controller properties from the taskbar.
  • Page 169 Windows XP Information You may make changes to the devices, color, schemes, Hot Keys etc. by clicking the appropriate menu item or button. Help Menus Right-click on many of the items in the tabs to bring up the “What’s This?” button. Click the “What’s This?”...

  • Page 170: D - 12 Attaching Other Displays

    Windows XP Information Attaching Other Displays Besides the built-in LCD, you can also use an external monitor/flat panel display as a display device. The fol- lowing are the display options: The built-in LCD OR an external monitor/flat panel display connected to the external monitor port (Single Display). 2.

  • Page 171: Display Modes

    Windows XP Information Display Modes Single Display On-Screen Menu Only one of your attached displays is used. Button You can use the On- Intel(R) Dual Display Clone Screen Menu button This mode will drive multiple displays with the same content. Each device may be to quickly toggle through the display op- configured independently for different resolutions, refresh rates, color quality etc.
  • Page 172 Windows XP Information To Enable Intel(R) Dual Display Clone Mode Attach your external display to the external monitor port and turn it on. 2. Open the Intel(R) GMA Driver for ultra mobile control panel. 3. Click to choose Intel(R) Dual Display Clone from Display Devices (tab). 4.
  • Page 173 Windows XP Information To Enable Extended Desktop Mode: Attach your external monitor to the external monitor port and turn it on. 2. Open the Intel(R) GMA Driver for ultra mobile control panel. 3. Click to choose Extended Desktop from Display Devices (tab). 4.
  • Page 174 Windows XP Information To Enable Extended Desktop (Display Properties) Attach your external monitor to the external monitor port and turn it on. 2. Click Start, point to Settings (or click Control Panel) and click Control Panel (if you are in Category View choose Appearance and Themes).

  • Page 175: Power Management Features

    Windows XP Information Power Management Features To conserve power, especially when using the battery, your computer uses the ACPI OS Note power management system. Power management conserves power by controlling in- dividual components of the computer (the monitor and hard disk drive) or the whole Power management system.

  • Page 176: The Power Sources

    Windows XP Information The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/DC adapter will damage the computer and its components.

  • Page 177: Turning On The Computer

    Windows XP Information Turning on the Computer Now you are ready to begin using your computer. To turn it on press the power button Shutdown and release it. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot-key ways shut your comput- er down by choosing the button when you press and release it in less than 4 seconds (pressing the power but-...

  • Page 178: Power Schemes

    Windows XP Information Power Schemes You can set your computer to conserve power through individual components by Resuming means of Power Schemes. You can also adjust the settings for each scheme to set Operation the monitor to turn off after a specified time, and the computer's hard disk motor to turn off if the hard disk drive has not been accessed for a specified period of time (if Press a key on an at- the system reads or writes data, the hard disk motor will be turned back on).
  • Page 179 Windows XP Information Each Windows Power Scheme will also adjust the processor performance of your machine in order to save pow- er. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.

  • Page 180: System Power Options

    Windows XP Information System Power Options You can use the system power options to stop the computer’s operation and restart where you left off. This sys- tem features Stand by and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - see “Hibernate”...
  • Page 181 Windows XP Information Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle System Resume at its slowest speed.

  • Page 182: Configuring The Power Button

    Windows XP Information Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hiber- nate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery) or orange (AC/DC adapter). If you are in a power saving mode set to save power through individual components (e.g.

  • Page 183: Battery Information

    Windows XP Information Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery New Battery Warning Always completely discharge, then fully charge, a new battery (see “Battery FAQ” When the battery is criti- on page D - 28 for instructions on how to do this).
  • Page 184 Windows XP Information Battery life may be shortened through improper maintenance. To optimize the life and improve its perfor- mance, fully discharge and recharge the battery at least once every 30 days. If you need to remove the battery for any reason, see “Removing the Battery”...

  • Page 185: Battery Guidelines

    Windows XP Information Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.

  • Page 186: Battery Gauge

    Windows XP Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t Caution turn off the computer by yourself even when you see a message that indicates the bat- Danger of explosion if tery is critically low, just let the computer use up all of the battery power and shut battery is incorrectly re-...

  • Page 187: Battery Indicators

    Windows XP Information Battery Indicators On-screen indicators will display the battery status if the battery level button is pressed or the AC/DC adapter is not connected. Action Icon Description The on-screen Main Battery Level Indicator battery level button is pressed. Bridge Battery Level Indicator Main Battery Level is Under 3% Plug-in the AC/DC Adapter...

  • Page 188: Removing The Battery

    Windows XP Information Removing the Battery If you need to remove the battery follow the procedure below. Turn the computer off (unless you are hot swapping the battery), and turn it over. Remove screws at points Remove the battery cover Grip the tab and lift the battery out in the direction of the arrow Figure D - 17 - Battery Removal...

  • Page 189: Hot-Swapping The Battery

    Windows XP Information Hot-Swapping the Battery If you have more than one battery included in your purchase option you can swap the battery while the system is running. Check the level of the backup battery from the on-screen menu. Press the battery level button to display the indicator: Main Battery Level Bridge Battery Level...

  • Page 190: D - 32 Driver Installation

    Windows XP Information Driver Installation 1. Check the driver installation order from Table D - 3 (the drivers must be installed in this order) which is the You will need to attach a CD/DVD drive to the com- same as that listed in the Drivers Installer menu below. puter in order to access the drivers on the Device Driv- 2.

  • Page 191: Windows Vista Service Pack

    Windows XP Information WinXP SP3 Driver Page # Chipset Page D - 34 Windows XP Service Pack 3 Make sure you install Windows XP Service Pack 3 (or a Video Page D - 34 Windows XP version which includes Service Pack 3) be- fore installing any drivers.
  • Page 192 Windows XP Information Updating/Reinstalling Individual Drivers Driver Installation Procedure If you wish to update/reinstall individual drivers it may Insert the Device Drivers & Utilities + User’s Manual be necessary to uninstall the original driver.To do this go disc into the attached CD/DVD drive, click Install Driv- to the Control Panel in the Windows OS and double- ers/Option Drivers (button) and then click the appropri- click the Add/Remove Programs item.
  • Page 193 Windows XP Information Module Drivers 1. Click 4.Install LAN Driver > Yes. See the following pages for the driver installation pro- cedures for any of the optional modules included in 2. Click Next > Install. 3. Click Finish. your purchase configuration. 4.

  • Page 194: Bluetooth Module

    Windows XP Information Bluetooth Module Bluetooth & Wireless LAN Modules Note: The operating system is the default setting for Bluetooth control in Windows XP, and does not re- quire a driver. See “Bluetooth Module” on page D - Wireless Device Operation Aboard Aircraft for configuration instructions.
  • Page 195 Windows XP Information Bluetooth Module The operating system’s Bluetooth Devices (the Bluetooth module is a Factory Option) control panel is used to configure the Bluetooth settings in Windows XP, and therefore does not require a driver. Use the On-Screen Menu button to power ON the Bluetooth module (see “On-Screen Menu”...
  • Page 196 Windows XP Information Bluetooth Local Area Connection Icon If you want to display the Local Area Connection icon for the Bluetooth connection in the taskbar, set it up as follows: 1. Access the Network Connections control panel in Windows (Start > Settings > Network Connections OR Start >...

  • Page 197: Bluetooth Configuration In Windows Xp

    Windows XP Information Bluetooth Configuration in Windows XP Setup your Bluetooth Device so the Computer Can Find it Bluetooth Taskbar Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. 2. Make the device discoverable (to do this check your device documentation). Icon If you cannot see the To Turn the Bluetooth Module On...

  • Page 198: To Add A Bluetooth Device

    Windows XP Information To Add a Bluetooth Device 1. Access the Bluetooth Devices control panel. 2. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it. 3. Click Devices (tab), and then click Add. 4.
  • Page 199 Windows XP Information To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. 2. Click on the device you want to change and click Properties to: Bluetooth Module & • Change the name of the device (click General, type a new name and click OK). Resuming From •...

  • Page 200: D - 42 Wireless Lan Module

    Windows XP Information Wireless LAN Module Before installing the WLAN module driver use the On-Screen Menu button Wireless Device to power ON (the default setting is OFF) the WLAN module (see “On-Screen Operation Aboard Menu” on page D - 4). Make sure you install the drivers in the order indicated in Aircraft Table D - 3, on page D - The use of any portable...
  • Page 201 Windows XP Information Network Connection Use the Windows Net- work Connections con- trol panel access available wireless net- works (Start > Settings > Network Connections or Start > Connect To > Show all Connections). Figure D - 28 Wireless Network Control Panels Wireless LAN Module D - 43...

  • Page 202: D - 44 Pc Camera Module

    Windows XP Information PC Camera Module Before installing the PC Camera module driver use the On-Screen Menu button Camera Button to power ON (the default setting is OFF) the PC Camera module (see “On- Screen Menu” on page D - 4).
  • Page 203 Windows XP Information PC Camera Audio Setup To capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double-click the Sounds &...
  • Page 204 Windows XP Information BisonCap BisonCap is a video viewer for general purpose video viewing and testing, and cap- turing video files to.avi format. Pre-Allocating File Space 1. Run the BisonCap application from the Start > Programs/All Programs > Bison- Cam menu (it is recommended that you set the capture file before the capture You may pre-allocate process - see Set Capture File below).
  • Page 205 Windows XP Information Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties) If necessary you can remove the recorded video file to a removable medium e.g.
  • Page 206 Windows XP Information Zoom The BisonCap program allows you to zoom the camera in and out. Snapshot Folder 1. Run the BisonCap program. 2. Go to Zoom and select Zoom Out/Zoom In. The Snapshot folder’s default location is on the desktop.

  • Page 207: Fingerprint Reader Module

    Windows XP Information Fingerprint Reader Module If you have included the fingerprint reader in your purchase option you will need to Help & Manual install the driver as per the instructions below. Right-click the taskbar icon Make sure you have administrator’s rights to your computer, and have a Windows to bring up the menu to password enabled for full security protection.

  • Page 208: User Enrollment

    Windows XP Information User Enrollment 1. Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon (click Initialize). 2. On the first run of the program you will be asked to click the button to accept the license, and then click OK.
  • Page 209 Windows XP Information 9. Click Next > Next (if you have the “Run interactive tutorial” tickbox selected you will run through the Fingerprint Tutorial). 10. Click Next for each window of the tutorial (you can click the button to “skip tutorial” at any Fingerprint time).
  • Page 210 Windows XP Information 17. Right-click the taskbar icon to Start Control Center to allow you to Edit Fingerprints, register applications, manage Password Bank, File Safe and access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu.

  • Page 211: Fingerprint Control Center Features

    Windows XP Information Fingerprint Control Center Features Application Launcher The Application Launcher allows you to register applications to be launched when assigned to a particular fin- ger. Simply copy the application icon on to one of the registered fingers and ten click OK to close the application window.

  • Page 212: D - 54 Gps Module

    Windows XP Information GPS Module If you have included an Global Positioning System (GPS) receiver module in your purchase option, you will need to obtain map software suitable for your global location. Map software programs are both commercially available and downloadable directly from the internet. A Global Positioning System satellite continually transmits high-frequency radio signals containing the time and location of the satellite in relation to the earth.
  • Page 213 Windows XP Information Configuring the COM Port for the GPS Module You need to make sure that the COM port for the GPS module is set to COM 3 at a 4800 baud rate. To do this follow the instructions below: Click Start (menu), point to Settings and click Control Panel (or click Control Panel).
  • Page 214 Windows XP Information RFID Reader Module If you have included the RFID Reader module in your purchase option, you will need to obtain software suitable for your system. The scanner for the module is located at the top of the computer. •For RFID Reader - Simply hold any RFID enabled card (up to a distance of 2CM) in front of the scanner to obtain a reading.
  • Page 215 Windows XP Information Configuring the COM Port for the RFID Reader You need to make sure that the COM port for the RFID reader is set to COM 1 at a 9600 baud rate. To do this follow the instructions below: Click Start (menu), point to Settings and click Control Panel (or click Control Panel).
  • Page 216 Windows XP Information D - 58...
  • Page 217 ExpressCard 34 Approved List Appendix E: ExpressCard 34 Approved List The ExpressCards listed in the table below are approved for use with this computer. Please make sure any Ex- pressCards you use with this computer are included in the list. For further information contact your service cen- ter.
  • Page 218 ExpressCard 34 Approved List E - 2...

Table of Contents
