Panasonic Toughbook 31 Brochure

Toughbook 31 Specs
Durability
MIL-STD-810G and IP65 certified 2
n
MIL-STD-461F certified
n
IP65 certified 2
n
Hard drive heater
n
Full magnesium alloy case with handle
n
Shock-mounted flex-connect hard drive with quick-release
n
Reinforced locking port covers
n
Pre-installed replaceable screen film
n
Operating System
Genuine Windows ® 7 Professional 32-bit 1 or
n
Genuine Windows 7 Professional 64-bit
® 1
CPU
Intel Core i5-3360M vPro Processor (2.8GHz)
® ™ ™
n
Intel Core i5-3320M vPro Processor (2.6GHz)
® ™ ™
n
Intel ® Core ™ i3-3110M Processor (2.4GHz)
n
Storage & Memory
i5 models: 4-8GB SDRAM (DDR3L-1333MHz)
n
i3 model: 2-8GB SDRAM (DDR3L-1333MHz)
n
Display
13.1" XGA sunlight-viewable touchscreen LED 1024 x 768
n
– Panasonic CircuLumin ™ technology
– 2-1200 nit
– Circular polarizer
3
– Anti-reflective and anti-glare screen treatments
Expansion Slots
PC card type II x 1
n
SD card (SDXC)
n
ExpressCard/54 x 1
n
Interface
Docking connector 80-pin
n
HDMI Type A
n
VGA D-sub 15-pin
n
Headphones/speaker Mini-jack stereo
n
Microphone/line in Mini-jack stereo
n
Serial D-sub 9-pin
n
Ext. antenna conn. 50 ohm coaxial
n
i5 models: USB 3.0 (x 1), USB 2.0 (x 3) 4-pin
n
i3 models: USB 2.0 (x 4) 4-pin
n
Optional IEEE 1394a (FireWire) 4-pin
n
10/100/1000 Ethernet RJ-45
n
Optional 10/100 2nd LAN (Ethernet) RJ-45
n
Optional 56K Modem RJ-11
n
1.800.662.3537
panasonic.com/toughbook/31
Intel, the Intel logo, Intel Core, Intel vPro, Core Inside and vPro Inside are trademarks of Intel Corporation in the U.S. and other countries. Toughbook notebook PCs are
covered by a 3-year limited warranty, parts and labor. To view the full text of the warranty, log on to panasonic.com/toughbook/warranty. Please consult your Panasonic
representative prior to purchase. Panasonic is constantly enhancing product specifications and accessories. Specifications subject to change without notice.
©2012 Panasonic Corporation of North America. All rights reserved. B_31_09/12
Panasonic recommends Windows
®
Wireless
Optional integrated 4G LTE mobile broadband
n
Optional integrated 3G Gobi ™ mobile broadband
n
Intel ® 802.11a/b/g/n
n
Bluetooth v4.0 + EDR (Class 1)
®
n
Slide on/off switch
n
Battery
14.5 hours (varies by model)
4
n
21 hours with optional media bay 2nd battery
n
Warranty
3-year limited warranty, parts and labor
n
Dimensions & Weight
11.5"(L) x 11.9"(W) x 2.9"(H)
n
Weight varies by battery type: 7.9 or 8.2 lbs.
n
Integrated Options
4G LTE mobile broadband
n
3G Gobi ™ mobile broadband
n
Webcam
3
n
GPS receiver
n
Backlit keyboard – sealed rubber or plastic emissive
n
2nd LAN (10/100) 3 or FireWire or Modem
n
SmartCard reader
n
Fingerprint reader
n
Media bay 2nd battery
5
n
HDD and battery lock
n
128GB and 256GB solid state drives (SSD) with heaters
n
A full set of Windows XP drivers are available at panasonic.com/toughbook/support.
1
2 Tested by national independent third party lab following MIL-STD-810G Method
516.6 Procedure IV for transit drop test and IEC 60529 Sections 13.4, 13.6.2,
14.2.5 and 14.3 for IP65.
3 On i5 CPU models only.
4 14.5 hours (3320M), up to 12 hours (3360M), 9 hours (i3)
Not available on 3360M.
5
7.
