  • Page 1 COLOR TV..OW °...
  • Page 2 Important Information WARNING TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER To prevent fire or shock SERVICEABLE PARTS INSIDE. REFER SERVICING RISK OF ELECTRICSHOCK hazard, do not expose this DO NOT OPEN TO QUALIFIED SERVICE PERSONNEL TV to rain or moisture.
  • Page 3 Table of Contents Important Information Warning, Product Registration Quick Guide to Your TV Startup Hook up your TV, Plug in the TV, Put Batteries in the Remote, Turn on the TV, Place Channels into Memory, Set the Time Basic Tour of the Remote Basic Button Layout and Functions Menu Basics Colors, Menu Buttons, Moving through the Menus...

  • Page 4: Startup

    Quick Guide to Your TV Startup The steps below will get your TV connected and ready for watching. For more details, see the page numbers listed. Hook up any antennas, cables or 1. Hook up your TV other equipment to your TV before Details are in the Connections you follow the steps below.

  • Page 5: Startup

    Quick Guide to Your TV Startup Press "IVon the remote. Turn on the TV Press POWER on the TV. A. Press MENU until the Setup 5. Place all available menu is selected. This menu is channels in memory white. (AutoProgram) Press + to start placing channels 3ontrol_ Alarm Adiust Controls Alarm Ad...

  • Page 6: Basic Tour Of The Remote

    Quick Guide to Your TV Basic Tour of the Remote Basic information about your remote is shown below. This will give you a general idea of how your remote works. For more details, see pages 6-15. TV Power Button Turns the TV on. Sets the remote to control the TV.
  • Page 7 Quick Guide to Your TV Menu Basics General information about using the on-screen menu system is shown below. Details on using the remote buttons are on pages 6-7. Many menu items are explained in detail in Using the Advanced Features starting on page 20. Yellow Green Light White Colors...

  • Page 8: With Remote Buttons

    Using Your TV and Remote With Remote Buttons Power Buttons Turns off the TV. Turns on the TV. Turns off compatible VCRs. Shows the displays on the screen. Sets the remote to control the TV. ON/OFF See Using the Remote with a VCR, Turns on a component after a Cable Box, Laserdisc Player and Audio...

  • Page 9: With Remote Buttons

    Using Your TV and Remote With Remote Buttons Component Buttons VCR2 and LDISC can only be AUDIO, VCR1, VCR2, LDISC, CABLE, TV programmed for one component: Sets the remote to control the either a Laserdisc Player or a VCR. component. See Using the Remote with a VCR, Cable Box, Laserdisc Player and Audio equipment on pages 8-15.

  • Page 10: With Vcrs

    Quai'tz..........02 Instant Replay ......... 08 Quasar ..........Wards ..........JCL............ RCA ....00,05,07,08,28,35,37 .... 05,06,07,08,12,13,15,25,31,35 JCPenney ..02,05,07,08,14,16,30,35 Realistic ..02,06,08,09,12,15,19,43 Yamaha ......02,14,16,30 JVC ........02,14,16,30 Samsung ....... 07,13,22,32,42 Zenith ......... 11,17 Kenwood ......02,14,16,30...
  • Page 11 Using Your TV and Remote With VCRs: Setting the VCR1 Channel The VCR 1 Channel works with VCR1 on the remote. If the VCR 1 Channel is set, pressing VCR1 selects the channel to see the VCR picture. The VCR 1 Channel setting depends on which diagram you have used from the Connection Guide.
  • Page 12 Using Your TV and Remote With VCRs: Basic Operation If the remote operates your VCR, this page and the next will show you how to use it for basic functions. See page 7for more details on buttons used with your VCR. A.

  • Page 13: With Vcrs

    Using Your TV and Remote With VCRs: Basic Operation If the remote operates your VCR, this page and page 10 will show you how to use it for basic functions. See page 7for more details on buttons used with your VCR. A.

  • Page 14: With A Cable Box

    ..07,08,19,21,26,28,29,32,33,40,41 Tocom ......... 17,21,49,50 ....04,05,15,2,3,24,25,50,36,46 Pioneer ........18,20,44 Unika ........31,32,41 Hamlin .......12,13,34,48 Randtek ........07,08 Viewstar ..........Hitachi ........37,43,46 RCA ..........0 0,27 ..07,08,19,21,26,28,29,32,33,40,41 Jerrold............ Regal ..........12,13 Warner Amex ........44 ..04,05,15,23,24,25,30,36,45,46,47 Regency ........02,33 Zenith ........... 14,42 MACOM ........37,43 Samsung ..........44...

  • Page 15: With A Cable Box

    Using Your TV and Remote With a Cable Box: Setting the Cable Channel The Cable Channel works with CABLE on the remote. If the Cable Channel is set, pressing CABLE selects the channel to see cable channels. The Cable Channel setting depends on which channel your cable box must be on to see cable channels.
  • Page 16 C. Press ON/OFF to turn it on. D. Use the buttons on the remote that relate to laserdisc player functions. Not all buttons high- lighted may work with your laserdisc player. E. Press ON/OFF to turn it off. Laserdisc Player Codes I ......Pro_an .......33 RCA......33...

  • Page 17: With Audio Equipment

    Basic Operation Refer to the Connection Book or your Audio equipment owner's manual to hook up your audio equipment. Your remote controls only RCA audio equipment such as a radio, CD player, tape player, turntable, or amplifier. remote may need to be programmed for your equipment.

  • Page 18: Overall Picture

    Adjusting Your TV Overall Picture Follow the steps below to lighten or darken the overall picture without changing the color levels. Press MENU to select the Controls Select the Controls Menu menu. This menu is yellow. Alarm Ad Press CHANNEL down to 2.

  • Page 19: Picture Settings

    Adjusting Your TV Picture Settings Follow the steps below to change the picture on the screen to your personal setting. The chart at the bottom of the page explains your options. Press MENU repeatedly to select the Select the Adjust Menu Adjust menu.

  • Page 20: Sound Settings

    Adjusting Your TV Sound Settings: Stereo and Tone Follow these steps to adjust the Stereo or Tone of your TV. The chart below explains your options. Press MENU to select the Controls Select the Controls Menu menu. This menu is yellow. Alarm Press CHANNEL down to 2.

  • Page 21: Sound Settings

    Adjusting Your TV Sound Settings: Speakers Follow the steps below to turn the speakers on or off in your TV. The chart below explains your options. Press MENU repeatedly to select 1. Select the Setup Menu the Setup menu. This menu is white.

  • Page 22: Placing Channels In Memory/Autoprogram

    Using Advanced Features Placing Channels in Memory (Autoprogramming) Only channels 2-13 appear in the TV's memory when you first turn it on. The channels available in your area must be programmed into the TV's memory when you hook up your TV. Using CHANNEL up or down allows you to scan through these channels.

  • Page 23: Naming The Channels

    Using Advanced Features Naming the Channels You can name the channels using the character list below. Full appears beside Label when the memory is used up. Fixed appears beside Label for channel 00--it cannot be named. A. Press MENU repeatedly to select Name a channel the Setup menu.
  • Page 24 Using Advanced Features Setting the Sleep Timer You can set your TV to turn itself off. If you're watching TV at night and fall asleep, the TV will turn off for you. Press MENU to select the Set Sleep Tuner Controls menu and highlight Sleep Timer.

  • Page 25: Setting The Alarm Clock

    Using Advanced Features Setting the Alarm Clock The TV can be set to turn on each day like your alarm clock. You can set it to turn on to your favorite channel at a certain time. You can also set it to turn itself off again.

  • Page 26: Watching Picture-In-Picture

    Using Advanced Features Watching Picture-in-Picture (Not on all models) Picture-in-Picture allows you to display a small picture within the big picture of the TV screen. To watch two different programs at once, you must connect a VCR, Laserdisc Player or Camcorder. You may need to disable the VCR1 Channel if you can not get two different programs at once.

  • Page 27: Watching Picture-In-Picture

    Using Advanced Features Watching Picture-in-Picture (Not on all models) Press MOVE to move the small Move the small picture picture to the next comer. Press SWAP to switch the small Swap the big picture with picture with the big picture. the little picture A.

  • Page 28: Watching Closed Captioning

    Using Advanced Features Watching Closed Captioning Closed captioning displays the audio portion of a program as words on the TV screen. It is useful for the deal hearing impaired, or anyone who wants to watch a program without sound. If you have turned Closed Captioning on and it does not appear on the screen, it is not available on the channel you are watching.

  • Page 29: Setting Your Tv For Antenna Or Cable

    Using Advanced Features Setting Your TV for Antenna or Cable Your TV automatically adjusts this feature when the TV places channels in memory (autoprogram). Follow the steps below to change the setting as needed. Press MENU repeatedly to select 1. Select the Setup menu the Setup menu.

  • Page 30: Front Panel Buttons

    References Front Panel Buttons For details on using buttons with menus, see Menu Basics on page 5. MENU Shows menus on screen. Moves fi'ommenu to menu. CH A and v Channel up and down. Scans up and down through channels in the TV's memory. Moves up and down menus.

  • Page 31: Displays On The Screen

    References Displays on the Screen Your TV shows the settings of several features on the screen. To see what features have been set on your TV, press DISPLAY on the remote. 12:00 AM KNBC 13 or Video 00, S-Vid 00 Alarm Sleep PIP 00...

  • Page 32: Trouble Checks

    References Trouble Checks You may have problems that can be fixed with a few minor adjustments. Look for the type of problem you are having below and then try the suggestions to get your TV going again. For warranty information see page 32. Trouble Checks and Adjustments...

  • Page 33: Trouble Checks

    References Trouble Checks Trouble Checks and Adjustments Remote Buttons don't work when you Press "IV to set the remote to control the TV. See buttons on page 6-7. press them Clear the path between the remote and TV of any objects. Works part or none of the time Aim the remote at the component...

  • Page 34: Limited Warranty

    RCA Television Servicenter for the new or, at our option, rebuilt replacement parts and picture tube required to repair your television. How you get service: For screen sizes of 20" and smaller: Take your RCA television to any Authorized RCA Television Servicenter.

  • Page 35: Order Form For Parts

    References Order Form for Parts Remote #215419 Order Form If your TV has the Book No. 1Q57 368-05A picture-in-picture feature, this is the remote that came packed with your Part Part Number Price Total TV. You can use the order form at Cleaner AH035 i $ 6.95...

  • Page 36: Order Form For Parts

    References Order Form for Parts U.S. and Canadian Orders USE YOUR CREDIT CARD By Phone: Copy complete account number 1 - 800 - 338 - 0376 Call this toll-free number between IIII I I-T-I7 F-V-I] [-T-[--I 8AM and 8PM Eastern Standard Time and place your order using your Visa or MasterCard.

  • Page 37: Glossary

    References Glossary S-VHS Antenna Display A device used to receive broadcast A word, words or graphics that Super Video. A format used by some VCRs and Camcorders appear on the TV screen. signals from TV stations. which improves the picture Audio Inputs quality.

  • Page 38: Index

    References Index CABLE/ANTENNNA Jack ..15 Delete Channels from Memory .20 Adding Channels to Memory..20 Disabled ........35 Cable Box ......... 12,13 Adjust Menu Cable Box Codes ......12 DISPLAY Button ....... 6,23 Autocolor ........17 CABLE Button ...... 7,12,13 Displays (On-Screen) ....
  • Page 39 Trouble Checks ....... 30,31 Turn on Alarm ......23 Menu ..........REC / Record Button .... 7,11,15 Turn on Picture-in-Picture ..24,25 References ....... 28-37 MENU Buttons ......4,5 Turn on TV ........2 Menus ..........Glossary ........35 Menu Colors ........5 Order Form for Parts ...
  • Page 40 Thomson Consumer Electronics is one of the first corporations to take part in a special program to improve our environment. Thomson has committed itself to a voluntary initiative program through the U.S. Environmental Protection Agency. The program's purpose is to reduce toxic air emissions and to promote pollution prevention.
