Fairchild Harrier 447 Specification Sheet

Description
The Harrier 447™ is a high­performance
imaging camera for use in applications that
demand high resolution and dynamic range.
The camera is based upon the CCD 447, a
scientific grade 2k x 2k multi­port sensor.
The camera boasts a low­noise, multi­
speed, multi­port readout architecture
providing the optimal combination of frame­
rate and sensitivity. Linear, 14­bit dynamic
range and sophisticated features such as
software control over gain and binning make
the Harrier™ a flexible and agile instrument
for scientific optical imaging. USB 2.0 provides an easy plug­and­play interface that
allows host computer control as well as an efficient data path. The camera is packaged
in a compact and rugged housing and supports standard F­mount lenses and mounting
hardware.
Features
2k x 2k Sensor
31 mm x 31 mm Imaging Area
Multiport Readout
Software Selectable Gain
Linear 14­bit Dynamic Range
TTL trigger I/O
USB 2.0 interface
1801 McCarthy Blvd., Milpitas CA 95035 • (800) 325­6975 • Facsimile (408) 435­7352 • www.fairchildimaging.com • Rev B
Benefits
High resolution (4 Megapixel)
High optical throughput
Optimal design for speed and sensitivity
Tailor system for dynamic range or sensitivity
Scientific precision and accuracy
Simple integration with other apparatus
Easy plug­and­play
HarrierÔ 447
