- Page 1 Product Manual Pulsar .2 SAS ® Standard Models Self-Encrypting Drive Models ST800FM0002 ST800FM0012 ST800FM0032 ST800FM0042 ST400FM0002 SED FIPS140-2 Models ST400FM0042 ST200FM0002 ST800FM0022 ST200FM0042 ST100FM0002 ST100FM0052 100666271 Rev. C March 2013...
- Page 2 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Pulsar and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. The FIPS logo is a certification mark of NIST, which does not imply product endorsement by NIST, the U.S., or Canadian governments.All other trademarks or registered trademarks are the property of their...
-
Page 3: Table Of Contents
ONTENTS ............... . 2 COPE . - Page 4 ONTENTS 5.3.7 Product warranty ..........18 .
- Page 5 ONTENTS 10.3 ............41 RIVE MOUNTING 10.4 .
- Page 6 IGURES Figure 1. Current profiles for 800GB models ..........24 Figure 2.
-
Page 7: Seagate Technology Support Services
Global Support Services telephone numbers & business hours • Authorized Service Centers • Warranty terms will vary based on type of warranty chosen: “Managed Life” or “Usage Based”. Consult your Seagate sales representative for warranty terms and conditions. For information regarding data recovery services, visit http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit http://www.seagate.com/partners... -
Page 8: Scope
Pulsar.2 drives support the SAS Protocol specifications to the extent described in this manual. The SAS Interface Manual (part number 100293071) describes the general SAS characteristics of this and other Seagate SAS drives. The Self-Encrypting Drive Reference Manual, part number 100515636, describes the interface, general operation, and security features available on Self-Encrypting Drive models. -
Page 9: Applicable Standards And Reference Documentation
Mounting by bottom holes must meet the requirements of Section 10.3. TANDARDS The Pulsar.2 family complies with Seagate standards as noted in the appropriate sections of this manual and the Seagate SAS Interface Manual, part number 100293071. The drives are recognized in accordance with UL 60950 and CSA 60950 as tested by UL(CSA) and EN60950 as tested by TUV. -
Page 10: Electromagnetic Compliance
(Pb), in electronic products effective July 2006. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the representations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our supplier contracts require compliance with our chemical substance restrictions, and our suppliers document their compliance with our requirements by providing material content declarations for all parts and materials for the drives documented in this publication. -
Page 11: China Restriction Of Hazardous Substances (Rohs) Directive
"X" indicates the hazardous and toxic substance content of the part (at the homogenous material level) is over the threshold defined by the China RoHS MCV Standard. EFERENCE DOCUMENTS SCSI Commands Reference Manual Seagate part number: 100293068 SAS Interface Manual Seagate part number: 100293071 ANSI SAS Documents SFF-82232.5”... -
Page 12: General Description
ENERAL DESCRIPTION Pulsar.2 drives provide high performance, high capacity data storage for a variety of systems with a Serial Attached SCSI (SAS) interface. The Serial Attached SCSI interface is designed to meet next-generation computing demands for performance, scalability, flexibility and high-density storage requirements. -
Page 13: Media Description
• Incorporates industry-standard Self-Monitoring Analysis and Reporting Technology (S.M.A.R.T.) • "Managed Life" or "Usage Based" warranty options [1] Warranty terms will vary based on type of warranty chosen: “Managed Life” or “Usage Based” Consult your Seagate sales representative for war- ranty terms and conditions. -
Page 14: Programmable Drive Capacity
In order to determine if Thin Provisioning is supported and what features of it are implemented requires the system to send a READ CAPACITY 16 (9Eh) command to the drive. Thin Provisioning and the READ CAPACITY 16 (9Eh) command is defined in the Seagate SCSI Command Reference 100293068.. -
Page 15: Unmap
3.8.3 UNMAP The UNMAP command requests that the device server break the association of a specific Logical Block address from a Physical Block, thereby freeing up the Physical Block from use and no longer requiring it to contain user data. An unmapped block will respond to a READ command with data that is determined by the setting of the LBPRZ bit in the READ CAPACITY parameter data. -
Page 16: Performance Characteristics
ERFORMANCE CHARACTERISTICS This section provides detailed information concerning performance-related characteristics and features of Pulsar.2 drives. Data provided is based on format at 512-bytes. Note. NTERNAL DRIVE CHARACTERISTICS Drive capacity 800400 200100 GB (formatted, rounded off value) Flash Memory Type NAND MLC Emulated LBA Size 512, 520, 524, 528, 4096, 4160, 4192, or 4224 Native Programmable... -
Page 17: Performance
4.2.3 Performance Table 6 Performance (Managed Life Warranty) ST800FM00 ST800FM00 ST400FM00 ST200FM00 ST100FM00 ST800FM00 Maximum Burst Transfer Rate 600MB/s Peak sequential 128KB read/write 370/200 370/190 data transfer rate (MB/s max) Sustained sequential 128KB read/ 370/200 370/140 370/70 370/35 write data transfer rate (MB/s) Peak 4KB random read/write 48,000/15,000 48,000/12,000... -
Page 18: Start / Stop Time
Sustained performance is defined as the worst case performance that the product will be able to achieve when the product is preconditioned as mentioned and host commands are aligned on 4KB boundaries. For models that support Lifetime Endurance Management, write values also take into account the worst case performance throttling that may occur to ensure the product meets specified reliability specifications. -
Page 19: Reliability Specifications
ELIABILITY SPECIFICATIONS The following reliability specifications assume correct host and drive operational interface, including all interface timings, power supply voltages, environmental requirements and drive mounting constraints. Read Error Rates Unrecovered Data Less than 1 LBA in 10 bits transferred Miscorrected Data Less than 1 LBA in 10 bits transferred Interface error rate:... -
Page 20: Endurance Management
Additionally, the Data Retention spec of the SSD needs to be considered to ensure the spec is met once the drive is worn out. Seagate has implemented a Lifetime Endurance Management technique which helps OEMS and user to avoid early wear out. -
Page 21: Reliability And Service
ELIABILITY AND SERVICE Integrators can enhance the reliability of Pulsar.2 drives by ensuring that the drive receives adequate cooling. Section 6.0 provides temperature measurements and other information that may be used to enhance the service life of the drive. Section 10.2 provides recommended air-flow information. -
Page 22: Thermal Monitor
Performance impact S.M.A.R.T. attribute data is saved to the media so that the events that caused a predictive failure can be recreated. The drive measures and saves parameters once every hour subject to an idle period on the drive interfaces. The process of measuring off-line attribute data and saving data to the media is interruptible. -
Page 23: Drive Self Test (Dst)
If DST encounters an error during either of these tests, it reports a "diagnostic failed" condition. If the drive fails the test, remove it from service and return it to Seagate for service. 5.3.6.1 DST failure definition The drive will present a “diagnostic failed”... -
Page 24: Product Warranty
Product warranty See See “Seagate Technology Support Services” on page 1 for warranty information. Warranty terms will vary based on type of warranty chosen: “Managed Life” or “Usage Based”. Consult your Seagate sales representative for warranty terms and conditions. Managed Life Warranty This warranty is term based and includes the Lifetime Endurance Management feature stated in section 6.2.6. -
Page 25: Physical / Electrical Specifications
HYSICAL ELECTRICAL SPECIFICATIONS This section provides information relating to the physical and electrical characteristics of the drive. OWER SPECIFICATIONS The drive receives DC power (+5V and +12V) through the standard SAS interface. 6.1.1 Power consumption Power requirements for the drives are listed in the tables beginning on page 21. Typical power measurements are based on an average of drives tested, under nominal conditions, using +5V and +12V input voltage at 60°C ambient temperature. -
Page 26: Dc Power Requirements
POWER REQUIREMENTS Table 9 800GB standard model DC power requirements 800GB (6.0G ARAMETER Regulation ±5% ±5% Voltage +12V URRENT URRENT OWER DC Average idle current 0.42 0.19 4.38 Maximum starting current (peak DC) DC 3σ 0.79 0.49 (peak AC) AC 3σ... - Page 27 Table 10 400GB standard model DC power requirements 400GB (6.0G ARAMETER Regulation ±5% ±5% Voltage +12V URRENT URRENT OWER DC Average idle current 0.41 0.12 3.49 Maximum starting current (peak DC) DC 3σ 0.50 0.35 (peak AC) AC 3σ 0.54 0.60 Delayed start (max) DC 3σ...
- Page 28 Table 11 200GB standard model DC power requirements 200GB (6.0G ARAMETER Regulation ±5% ±5% Voltage +12V URRENT URRENT OWER DC Average idle current 0.43 0.11 3.47 Maximum starting current (peak DC) DC 3σ 0.51 0.31 (peak AC) AC 3σ 0.61 1.26 Delayed start (max) DC 3σ...
- Page 29 Table 12 100GB standard model DC power requirements 100GB (6.0G ARAMETER Regulation ±5% ±5% Voltage +12V URRENT URRENT OWER DC Average idle current 0.43 0.12 3.59 Maximum starting current (peak DC) DC 3σ 0.48 0.32 (peak AC) AC 3σ 1.53 0.61 Delayed start (max) DC 3σ...
-
Page 30: Conducted Noise Immunity
6.3.1 Conducted noise immunity Noise is specified as a periodic and random distribution of frequencies covering a defined frequency. Maximum allowed noise values given below are peak-to-peak measurements and apply at the drive power connector. 250 mV pp from 100 Hz to 20 MHz. +12v 450 mV pp from 100 Hz to 100 KHz. -
Page 31: Figure 2. Current Profiles For 400Gb Models
Figure 2. Current profiles for 400GB models Figure 3. Current profiles for 200GB models .2 SAS P ULSAR RODUCT ANUAL... -
Page 32: Figure 4. Current Profiles For 100Gb Models
Figure 4. Current profiles for 100GB models .2 SAS P ULSAR RODUCT ANUAL... -
Page 33: Power Dissipation
OWER DISSIPATION 800GB models in 6Gb operation Typical power dissipation under idle conditions in 6Gb operation is 4.38 watts 14.95 BTUs per hour). To obtain operating power for typical random write operations, refer to the following I/O rate curve (see Figure 6). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis. -
Page 34: Environmental Limits
To obtain operating power for typical random write operations, refer to the following I/O rate curve (see Figure 7). Locate the typical I/O rate for a drive in your system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis. -
Page 35: Temperature
Non-operating –40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. Figure 9. -
Page 36: Shock And Vibration
Packaged Seagate finished drive bulk packs are designed and tested to meet or exceed applicable ISTA and ASTM standards. Volume finished drives will be shipped from Seagate factories on pallets to minimize freight costs and ease material handling. Seagate finished drive bulk packs may be shipped individually. -
Page 37: Air Cleanliness
Users should use caution exposing any electronic components to uncontrolled chemical pollutants and corrosive chemicals as electronic drive component reliability can be affected by the installation environment. The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. -
Page 38: Mechanical Specifications
ECHANICAL SPECIFICATIONS Refer to Figure 12 or 13 for detailed mounting configuration dimensions. See Section 10.3, “Drive mounting.” Weight: 0.353 pounds 160 grams These dimensions conform to the Small Form Factor Standard documented in SFF-8201 and Note. SFF-8223 found at www.sffcommittee.org. Figure 12. -
Page 39: Figure 13. Mounting Configuration Dimensions (400, 200 & 100Gb Models)
Weight: 0.220 pounds 100 grams These dimensions conform to the Small Form Factor Standard documented in SFF-8201 and Note. SFF-8223 found at www.sffcommittee.org Figure 13. Mounting configuration dimensions (400, 200 & 100GB models) .2 SAS P ULSAR RODUCT ANUAL... -
Page 40: About Fips
FIPS 140-2 Level 2 requirements. In order to operate in FIPS Approved Mode of Operation, these SEDs require security initialization. For more information, refer to 'Security Rules' section in the 'Security Policy' document uploaded on the NIST website. To reference the product certification visit: http://csrc.nist.gov/groups/STM/cmvp/documents/140-1/1401vend.htm, and search for "Seagate". Security Level 2 Security Level 2 enhances the physical security mechanisms of a Security Level 1 cryptographic module by adding the requirement for tamper-evidence, which includes the use of tamper-evident coatings or seals on removable covers of the module. -
Page 41: About Self - Encrypting Drives
The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. Seagate’s SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two SCSI commands: •... -
Page 42: Data Bands
In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: The download must be an SED file. -
Page 43: Defect And Error Management
EFECT AND ERROR MANAGEMENT Seagate continues to use innovative technologies to manage defects and errors. These technologies are designed to increase data integrity, perform drive self-maintenance, and validate proper drive operation. SCSI defect and error management involves drive internal defect/error management and SAS system error considerations (errors in communications between the initiator and the drive). -
Page 44: Drive Error Recovery Procedures
This is in contrast to the system having to use the REASSIGN BLOCKS command to reassign a location that was unreadable and then generate a WRITE command to rewrite the data. This operation requires that AWRE and ARRE are enabled—this is the default setting from the Seagate factory. .2 SAS P... -
Page 45: Protection Information (Pi)
Protection Information (e.g. 0xFFFFFFFF) to be stored on the media, but the 8 bytes will not be transferred to the host during a READ command. Type 3 - Seagate products do not support Type 3. 9.6.2 Setting and determining the current Type Level A drive is initialized to a type of PI by using the FORMAT UNIT command on a PI capable drive. -
Page 46: Installation
10.0 I NSTALLATION Pulsar.2 drive installation is a plug-and-play process. There are no jumpers on the drive. SAS drives are designed to be used in a host system that provides a SAS-compatible backplane with bays designed to accommodate the drive. In such systems, the host system typically provides a carrier or tray into which the drive must be mounted. Mount the drive to the carrier or tray provided by the host system using four M3 x 0.5 metric screws. -
Page 47: Drive Mounting
If forced air is determined to be necessary, possible air-flow patterns are shown in Figure 16. The air-flow patterns are created by one or more fans, either forcing or drawing air as shown in the illustrations. Conduction, convection, or other forced air-flow patterns are acceptable as long as the temperature measurement guidelines of Section 6.5.1 are met. -
Page 48: Interface Requirements
11.0 I NTERFACE REQUIREMENTS This section partially describes the interface requirements as implemented on Pulsar.2 drives. Additional information is provided in the SAS Interface Manual (part number 100293071). 11.1 FEATURES This section lists the SAS-specific features supported by Pulsar.2 drives. 11.1.1 Task management functions Table 14 lists the SAS task management functions supported. -
Page 49: Scsi Commands Supported
11.3 SCSI COMMANDS SUPPORTED Table 16 lists the SCSI commands supported by Pulsar.2 drives. Table 16 Supported commands OMMAND NAME OMMAND CODE UPPORTED CHANGE DEFINITION FORMAT UNIT [1] DPRY bit supported DCRT bit supported STPF bit supported IP bit supported DSP bit supported IMMED bit supported VS (vendor specific) - Page 50 Table 16 Supported commands OMMAND NAME OMMAND CODE UPPORTED Protocol-Specific Port log pages (18h) Read Error Counter page (03h) Read Reverse Error Counter page (04h) Self-test Results page (10h) Solid State Media log page (11h) Start-stop Cycle Counter page (0Eh) Temperature page (0Dh) Vendor Unique page (3Ch) Verify Error Counter page (05h)
- Page 51 Table 16 Supported commands OMMAND NAME OMMAND CODE UPPORTED READ LONG (16) 9Eh/11h Y (non-SED drives only) REASSIGN BLOCKS RECEIVE DIAGNOSTIC RESULTS Supported Diagnostics pages (00h) Translate page (40h) RELEASE (6) RELEASE (10) REPORT LUNS REQUEST SENSE Actual Retry Count bytes Extended Sense Field Pointer bytes RESERVE (6)
- Page 52 Table 16 Supported commands OMMAND NAME OMMAND CODE UPPORTED WRITE (16) WRITE (32) 7Fh/000Bh WRITE AND VERIFY (10) DPO bit WRITE AND VERIFY (12) WRITE AND VERIFY (16) WRITE AND VERIFY (32) 7Fh/000Ch WRITE BUFFER (modes 0, 2, supported) Y (non-SED drives only) WRITE BUFFER Firmware Download option (modes 5, 7, Ah and Bh) [2] Y (non-SED drives only)
-
Page 53: Inquiry Data
Bytes 16 through 26 reflect model of drive. The table above shows the hex values for Model ST800FM0002. Refer to the values below for the values of bytes 16 through 26 for a particular model: ST800FM0012 4D 30 ST800FM0022 4D 30 ST800FM0032 4D 30... -
Page 54: Mode Sense Data
11.3.2 MODE SENSE data The MODE SENSE command provides a way for the drive to report its operating parameters to the initiator. The drive maintains four sets of mode parameters: Default values Default values are hard-coded in the drive firmware stored in flash E-PROM (nonvolatile memory) on the drive’s PCB. These default values can be changed only by downloading a complete set of new firmware into the flash E-PROM. - Page 55 Table 18 MODE SENSE data for 800GB drives MODE DATA HEADER: 01 3e 00 10 01 00 00 10 BLOCK DESCRIPTOR: 00 00 00 00 5d 26 ce b0 00 00 00 00 00 00 02 00 MODE PAGES: DEF 81 0a c0 01 5a 00 00 00 0b 00 ff ff CHG 81 0a 38 00 00 00 00 00 ff 00 00 00 DEF 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 CHG 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
- Page 56 Table 19 MODE SENSE data for 400GB drives MODE DATA HEADER: 01 3e 00 10 01 00 00 10 BLOCK DESCRIPTOR: 00 00 00 00 2e 93 90 b0 00 00 00 00 00 00 02 00 MODE PAGES: DEF 81 0a c0 01 5a 00 00 00 0b 00 ff ff CHG 81 0a 38 00 00 00 00 00 ff 00 00 00 DEF 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 CHG 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
- Page 57 Table 20 MODE SENSE data for 200GB drives MODE DATA HEADER: 01 3e 00 10 01 00 00 10 BLOCK DESCRIPTOR: 00 00 00 00 17 49 f1 b0 00 00 00 00 00 00 02 00 MODE PAGES: DEF 81 0a c0 01 5a 00 00 00 0b 00 ff ff CHG 81 0a 38 00 00 00 00 00 ff 00 00 00 DEF 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 CHG 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
- Page 58 Table 21 MODE SENSE values for 100GB drives MODE DATA HEADER: 01 3e 00 10 01 00 00 10 BLOCK DESCRIPTOR: 00 00 00 00 0b a5 22 30 00 00 00 00 00 00 02 00 MODE PAGES: DEF 81 0a 00 01 5a 00 00 00 0b 00 ff ff CHG 81 0a 08 00 00 00 00 00 ff 00 00 00 DEF 82 0e 00 00 00 00 00 00 00 00 01 3a 00 00 00 00 CHG 82 0e 00 00 00 00 00 00 00 00 ff ff 00 00 00 00...
-
Page 59: Miscellaneous Operating Features And Conditions
Figure 17 shows the location of the SAS device connector J1. Figures 18 and 19 provide the dimensions of the SAS connector. Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of Seagate’s SAS drives are provided in the SAS Interface Manual. -
Page 60: Figure 18. Sas Device Plug Dimensions
0.80 (6X) 5.92 7.62 4.65 0.52 0.08 x 45 2.00 (3X) 0.45 0.03 (7X) 5.08 0.10 M E 42.73 REF. 41.13 0.15 0.20 B 0.30 0.05 (2X) 1.10 4.00 0.08 C OF DATUM D 0.15 D R0.30 0.08 (4X) 0.30 0.05 (4X) SEE Detail1 33.43... -
Page 61: Figure 19. Sas Device Plug Dimensions (Detail)
Detail A 6.10 0.30 0.05 x 45 (5X) 2.25 0.05 0.40 0.05 X 45 (3X) 4.85 0.05 0.10 B CORING ALLOWED IN THIS AREA. 4.40 0.15 R0.30 0.08 SEE Detail 2 1.95 0.08 0.35 0.05 SECTION C - C 3.90 0.15 SECTION A - A CONTACT SURFACE FLUSH... -
Page 62: Physical Characteristics
11.4.2 Physical characteristics This section defines physical interface connector. 11.4.3 Connector requirements Contact your preferred connector manufacturer for mating part information. Part numbers for SAS connectors will be provided in a future revision of this publication when production parts are available from major connector manufacturers. The SAS device connector is illustrated in Figures 18 and 19. -
Page 63: Sas Transmitters And Receivers
11.4.6 SAS transmitters and receivers A typical SAS differential copper transmitter and receiver pair is shown in Figure 20. The receiver is AC coupling to eliminate ground shift noise. Figure 20. SAS transmitters and receivers 11.4.7 Power The drive receives power (+5 volts and +12 volts) through the SAS device connector. Three +12 volt pins provide power to the drive, 2 short and 1 long. -
Page 64: Differential Signals
DDITIONAL INFORMATION Please contact your Seagate representative for SAS electrical details, if required. For more information about the Phy, Link, Transport, and Applications layers of the SAS interface, refer to the Seagate SAS Interface Manual, part number 100293071. For more information about the SCSI commands used by Seagate SAS drives, refer to the Seagate SCSI Commands Reference Manual, part number 100293068. - Page 65 NDEX class B limit 3 UMERICS clear ACA function 42 12 volt clear task set function 42 pins 57 CMVP 34 5 volt pins 57 commands supported 43 6 Gbps 58 condensation 29 condition met/good status 53 connector abort task set function 42 illustrated 56 AC coupling 57 requirements 56...
- Page 66 NDEX Endurance 13 guide 5 Endurance Management 14 interface environment 40 commands supported 43 environmental error rate 13 limits 28 errors 13 requirements 13 illustrated 53 environmental control 31 physical 53 EraseMaster 35 requirements 42 error internal defects/errors 37 management 37 internal drive characteristics 10 rates 13 Error reported to Host 9...
- Page 67 SAS-2 Specification 58 PI Levels 39 SCSI interface PI Returned for Thin Provisioned LBA 9 commands supported 43 PI Setting 9 Seagate Technology Support Services 1 pin descriptions 56 Secure ID 35 power 57 Security Protocol In 35 dissipation 27...
- Page 68 NDEX shipping 18 shipping container 29 warranty 18 shock 30 Wear Leveling 14 and vibration 30 Write Amplification 14 shock mount 41 WriteLockEnabled 35 SID 35 signal characteristics 57 single-unit shipping pack kit 8 zero latency read 53 SMART 7 SNW-3 training gap 58 Specification 58 SSD Physical format address descriptor 37...
- Page 69 Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100666271, Rev.
