EQUIUM 5200D Product Specifications
PROCESSOR
Intel Pentium 200Mhz (3.3v) w/VRT
MMX Technology
Integrated Coprocessor
Processor Cache
Socketed Processor
LEVEL 2 (L2) CACHE
Data Bus Width/Address Bus Width
Local Clock Bus Speed
DATA RAM:
1 Mbit PBS SRAM (3.3V)
Access time
SYSTEM ARCHITECTURE
PCI BUS (V2.1): (32-bit, 33mhz)
MEMORY: 16 Mbit EDO DRAM
Standard
Maximum
Speed
Parity
Hyper Page mode memory access
Data Bus Width/Address Bus Width
Local Clock Bus Speed
Socket Type:
BIOS (256KB FLASH EPROM, )
PnP 1.0a SUPPORT
Advanced Power Management 1.2 Support
EPA energy Star Compliant
DMI 2.0 Compliant
DPMS
DDC
NLS
VIDEO
Video Memory: SGRAM
Speed
PCI Bus Architecture
Controller Chip
Full motion video at 30 fps support
VESA support
YUV to RGB conversion
Graphics Accellerator Support
Supported Resolutions
SOUND SYSTEM
Chipsets:
16 bit stereo audio full duplexed
Sound formats supported:
ETHERNET SUPPORT
IEEE802, 3 auto-negotiation
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS 5200d.doc Rev. 3 04/04/00 nmm.
Equium 5200D
2.38 GB: PV1023U-01A
Yes
Yes
Yes
32KB: (16KB code; 16KB data)
Yes
Yes: 256KB Pipeline Burst
64-bit/32-bit
66 MHz
Yes
8 nsec
Yes
32 MB: (2*16 SIMMS)
192 MB (160MB without removing memory)
60ns
No parity
Yes
64-bit/32-bit
66 MHz
(6) SIMM sockets: Accepts 16MB or 32MB chips
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
2 MB expandable to 4MB
40 ns
Yes: 33 MHz Bus Clock Speed
ATI 3D Rage II Video Controller
Yes
Yes
Off-loads conversion from CPU for higher performance full motion video
without compromising picture quality or frame rate.
Includes 64-bit BitBLT, Hardware Cursor, DirectDraw, Direct3D
Colors/Pallette
640 x 480
16.7M colors/16.7M colors
800 x 600
16.7M colors/16.7M colors
1024 x 768
64K colors/64K colors
1280 x 1024
256 colors/256 colors
Creative Vibra 16C
Yes
SoundBlaster Pro , .WAV, MIDI, CD-ROM audio
Board Integrated: Intel EtherExpress
Yes: provides hardware selection of the highest operating speed
Refresh Rate (Non-Interlaced)
100 Hz
100 Hz
100 Hz
75 Hz
PRO/100B LAN Adapter
Page 1 of 3
