Extron electronics RGB 560 AKM Installation Manual

Universal computer-video interface

Hide thumbs Also See for RGB 560 AKM:

Ackermann GES9B floor

box installation

Advanced Digital Sync

Processing™

Active audio interfacing

300 MHz (-3dB) video

bandwidth

15-130 kHz compatibility

9-pin D input

(RGB 500 AKM)

Female 15-pin HD input

(RGB 560 AKM)

Buffered local monitor output

(RGB 560 AKM)

RGB 500 AKM

RGB 560 AKM

AND

Level/peaking control

Horizontal centering

RGsB, RGBS, or

RGBHV output

12-24VAC/VDC

Table of Contents

Need help?

Do you have a question about the RGB 560 AKM and is the answer not in the manual?

Page 1 Active audio interfacing 300 MHz (-3dB) video bandwidth 15-130 kHz compatibility 9-pin D input (RGB 500 AKM) Female 15-pin HD input (RGB 560 AKM) Buffered local monitor output (RGB 560 AKM) RGB 500 AKM RGB 560 AKM Level/peaking control Horizontal centering...
Page 2 ESCRIPTION Extron’s RGB 500 AKM and RGB 560 AKM with audio and ADSP are universal, computer-video interfaces designed for use ™ with the Ackermann floor tank system. The RGB 500 AKM or RGB 560 AKM fits flush within the included Ackermann GES9B mounting box for convenient and easy installation with RGB output connections on 6"...
Page 3 LBC Sun HR 6' A (61 kHz) ... 26-443-02 LBC Sun HR 6' A (71 kHz) ... 26-444-02 LBC Sun HR 6' A (81 kHz) ... 26-445-02 Signal input cable kits for RGB 560 AKM: VGA M6' MHR... 26-238-01 VGA M3' MHRA ... 26-490-01 VGA M6' MHRA ...
Page 4 Number/signal type ... 1 analog RGBHV, RGBS, RGsB Connectors ... 5 BNC female RGB 560 AKM ... 1 15-pin HD female for buffered local monitor output Minimum/maximum levels ... 0.70V to 0.75V p-p with no offset and 0.7V p-p input Impedance ...

Rgb 500 akm
