Exergen Transmitter IRt/c.XMTR Specification Sheet

Transmitter
IRt/c.XMTR
In-Line Pre-Calibrated 4-20
mA Transmitter
IRt/c Side
3 ft (1 m) 26 AWG stranded
twisted shielded pair
thermocouple wire.
Temperature at 4 mA
Temperature at 20 mA
Accuracy
Speed of Response
Operating Range
Temperature Drift
Output Noise
Input Break Indication
Power Supply @ Load
Storage Temperature
Weight
Housing
4 8 4 8 4 8 4 8 4 8
C O R P O R A T
The t/c.XMTR is specifically designed to interface any model IRt/c by a
simple thermocouple connector or splice. The two wire current loop can
be used in any conventional 4-20mA, 0-5V or 0-10V circuit that is scaled
for the temperature range of interest.
For OEMs, IRt/c sensors and t/c.XMTR can be supplied pre-wired
together.
· Use any existing wiring, for easy low cost installation
· Use existing PLC, computer or controller inputs
· In line design requires no mechanical support
· Pre-calibrated for IRt/c type, no span or zero adjustment neces-
sary
· Hermetically sealed construction exceeds NEMA 4, 4X, IP65, 66,
67
· Stainless Steel construction can withstand harsh environments
3.4 (86)
.50 (12,7)
Loop Side
10 ft (3 m) 22 AWG
stranded twisted pair wire.
J150
K150
150°F (65°C)
Stainless steel, hermetically sealed, meets or exceeds all applicable NEMA ratings, housing
51 Water Street, Watertown, MA 02172 USA
800-422-3006 • 617-923-9900 • Fax 617-923-9911
I O N
t/c connector
t/c.XMTR
Any Model IRt/c
J500 J1200
K500 K1200
32°F (0°C)
500°F (260°C) 1000°F (540°C)
±0.1% F.S. conversion of thermocouple mV input to mA output
160 msec (10Hz bandwidth)
32 to 158°F (0 to 70°C)
<0.02% F.S. per °C
<1nv rms (100Hz bandwidth)
Upscale: goes to >20 mA
12 VDC minimum @10; to 22 VDC minimum @1K
-85 to 257°F (-65 to 125°C)
2.4 oz (68 g) with cables
electrically isolated from signal.
4 - 20 mA
1000 Ohm
Max
12 - 36 VDC
K2100 S3000
2000°F (1100°C) 3000°F (1650°C)
