Service Kit
753-0873
Use this parts sheet when ordering any replacement parts for the cutting deck.
42-inch deck for electric PTO
REF.
PART
NO.
NO.
4
683-0254
Deck Adjustment Bracket w/ Weld Nut
5
714-0470
Pin: Cot : 1/8 x 1.25
6
726-0233
Push Nut, 1/4 x .50
9
710-0528
Hex Cap Screw, 5/16-18 x 1.25
12
710-0751
Hex Cap Screw, 1/4-20 x .62
13
710-1260A
Self Tapping Screw, 5/16-18 x .75
17
712-0417A
Nut: Hex: Flange: 5/8 - 18
19
712-3006
Hex Flange Lock Nut, 1/4-20
20
712-0431
Hex Flange Lock Nut 3/8-16
21
717-1553A
Deck Adjustment Gear
22
731-1032B
Side Discharge Chute Assembly
23
732-0306
Compression Spring, .406 x .531 x 1.75
25
734-0973
Deck Wheel, 5 x 1.38
26
736-0105
Bell Washer, .401 x .87 x .063
55
19
6
22
48
32
5
20
29
26
12
25
DESCRIPTION
SUBJECT:
MODELS AFFECTED: 600 through 619 with electric
47
32
41
9
5
27
21
23
6
4
23
48
19
12
13
49
17
REF.
PART
NO.
NO.
27
736-0119
29
738-0373
30
754-0472
32
747-1116
40
16606
41
618-0427
42
683-0198B
43
710-0604A
47
731-2231
48
736-0270
49
742-0616
55
753-0873
R-438
CODE:
May 16, 2000
DATE:
42" Deck Replacement
PTO
43
20
49
40
17
DESCRIPTION
Lock Washer, 5/16
Shoulder Bolt, .498 x 1.53
Deck V-Belt (Not Shown)
Deck Release Pin
Retainer Hook
Spindle Assembly w/ Fitting, 5.75 Dia
42-inch Deck Shell
Self Tapping Screw, 5/16-18 x .625
Belt Cover
Bell Washer, .265 x .75 x .062
Three-in-one Blade, Star Center, 21.23
42-inch Deck Assembly Complete
(w/o mulch kit)
Form No. 770-1664
29
25
26
42
(05/00)
