- Page 1 Dynavector P-75 phono pre-amplifier and phono enhancer Instructions and Specifications www.dynavector.com Designed and manufactured by Dynavector Australia and New Zealand / Aotearoa...
- Page 2 There are no input or output coupling capacitors in the P-75 signal path. The P-75 incorporates the unique current amplifier invented by Dr Tominari of Dynavector Systems Ltd., Japan, called a Phono Enhancer. Note: The P-75 supply requires a higher peak current to start up and so we do not recommend using an adaptor of less than 500mA.
-
Page 3: Specifications
P-75 power supply requirements AC to DC power adaptor 12V 500mA DC Two pin adaptor centre negative outer positive Outer Diameter 5.5mm Inner Diameter 2.5mm Note: Power supply is not included. Please purchase a suitable supply at your local dealer. Specifications The P-75 is a stand-alone phono to line level amplifier. - Page 4 P-75 Jumper Diagram Output RCA plugs Input RCA plugs All the above adjustments are easily made by the user. No soldering or extra components are required. Always turn off power to the audio system (including power to the P-75) when altering jumpers or settings inside the P-75.
- Page 5 P-75 Jumper Settings High Output MC JB1 & 2 JB3 & 4 or MM open open short short JB5 & 6 short open Low Output MC Standard phono JB3 & 4 JB5 & 6 60dB gain (normal) short short open short 63dB gain (high) open...
- Page 6 P-75 jumper position examples open = remove jumper short = fit jumper any position Moving Magnet and High Output Moving Coil Low Output Moving Coil 63db gain, 100 ohm loading Phono Enhancer Medium resistance coil...
- Page 7 Refer all servicing to qualified service personnel. Warranty Dynavector manufactures its products to very high standards and we are confident our products will perform well. Accordingly, we warrant the Dynavector P-75 against manufacturing defects in material and workmanship to the original owner, for a period of one year from the original date of purchase.
