First Steps
AIR SPACE
Installation
LE_/EUNG FEET
Unpackingand Leveling - Upright Freezers
REW8
TOP
_C
HINGE _
_
i
HINGE COVER
Upright Freezer Door Removal
F_I_!
To allow door to
close and seal praperly, DO NOT let
food packages eetend paet the from
of shelves,
Before starting
the freezer,
follow
these important
first
steps:
Installation
• Choose a place that is near a grounded electrical outlet.
• The freezer should be located where surrounding temperatures will not exceed
110°F (43°C). Temperatures of 32°F (0°C) and below will NOT affect freezer
operation. Additional compressor heaters are not recommended.
• AIIow space around the unit forgoodaircirculation.
Leave a 3 inch (75 mm)space
on all sides of the freezer for adequate circulation.
Leveling
The freezer must have all bottom corners resting firmly on a solid floor. Thefloor must
be strong enough to support a fully loaded freezer. NOTE: It isVERYIMPORTANT for
your freezer to be level in order to function properly. If the freezer is not leveled during
installatioin, the door may be misaligned and not close or seal properly, causing
cooling, frost, or moisture problems.
To Level Upright Unit:
After discarding crating screws and wood base, use a carpenter's level to level the
freezer from front-to-back. Adjust the plastic leveling feet in front, V2bubble higher,
so that the door closes easily when left halfway open.
To Level Chest Unit:
If needed, add metal or wood shims between feet pads and floor.
Cleaning
• Wash any removable parts, the freezer interior, and exterior with mild detergent
and warm water. Wipe dry. DO NOT USE HARSH CLEANERS ON THESE
SURFACES.
Do not use razor blades or other sharp instruments, which can scratch the appliance
surface when removing adhesive labels. Any glue left from the tape can be
removed with a mixture of warm water and mild detergent, or touch the residue
with the sticky side of tape already removed. DO NOT REMOVE THE SERIAL
PLATE.
Upright Freezer Door Removal
If door must be removed:
1. Lift up plastic hinge cover and fold back.
2. Usea Phillips@ screwdriver to loosen and retighten the screws on the top hinge to
ensure that a secure assembly and prevent hinge slippage.
3. Remove the top hinge from cabinet and lift door off the lower hinge pin.
4. After door is removed, remove the two screws from the bottom hinge.
5. To replace door, reverse above order.
Shelf Frorlt
4
