Installation Instructions

IMC-101

1TX to 1MMFX Ethernet Converter

Trend supply the following Ethernet media converter:

IMC-101-M-SC

:Industrial10/100BaseT(X) to 100 BaseFX Converter, multi mode, SC connector, 0 to

60 °C

Other options referred to in the installation instructions, and other accessories are not supplied.

The attached installation instructions are supplied by Moxa Networking Company Ltd:

P/No: 18020010102 edition 3, 01/07/04

For additional information see IMC-101 data sheet TA200837

IMC-101 Installation Instructions TG200840 Issue 1/A 10/12/04

Table of Contents

Need help?

Do you have a question about the IMC-101 and is the answer not in the manual?

Questions and answers

Summary of Contents for Novar IMC-101

Page 1: Installation Instructions
Other options referred to in the installation instructions, and other accessories are not supplied. The attached installation instructions are supplied by Moxa Networking Company Ltd: P/No: 18020010102 edition 3, 01/07/04 For additional information see IMC-101 data sheet TA200837 IMC-101 Installation Instructions TG200840 Issue 1/A 10/12/04...
Page 2 Website www.trend-controls.com Telephone +44 (0)1403 211888 Fax (International) +44 (0)1403 210982 Fax (UK) +44 (0)1403 241608 E-mail trendinfo@novar.com Registered office. Novar House 24 Queens Road Weybridge Surrey KT13 9UX Registered in England No 1664519 IMC-101 Installation Instructions TG200840 Issue 1/A 10/12/04...
Page 3 MOXA Industrial Media Converter IMC-101 Hardware Installation Guide Third Edition, July 2004...
Page 5: Package Checklist
Overview MOXA Industrial Media Converter, which is specially designed for a reliable and stable operation in harsh industrial environments, provides industrial grade media conversion between 10/100BaseT(X) and 100BaseFX. Its reliable industrial design is excellent for keeping your industrial automation applications running continually, and comes with a relay output warning alarm to help prevent damages and losses.
Page 6 Panel Layout of IMC-101 series Grounding screw Terminal block for power input PWR1/PWR2 and relay output Heat dissipation orifices Dip switch Power input PWR1 LED Power input PWR2 LED Fault LED 100BaseFX (ST connector) Port FX port’s 100 Mbps LED FX port’s Full Duplex/Collision LED TP port’s 100 Mbps LED 10/100BaseT(X)
Page 7: Mounting Dimensions
Mounting Dimensions (Unit = mm) DIN-Rail Mounting The aluminum DIN-Rail attachment plate should be fixed to the back panel of IMC when you take it out of the box. If you need to reattach the DIN-Rail attachment plate to IMC, make sure the stiff metal spring is situated towards the top, as shown in the figures below —...
Page 8: Wall Mounting (Optional)
STEP 1: STEP 2: Insert the top of the DIN-Rail into the The DIN-Rail attachment unit will slot just below the stiff metal spring. snap into place as shown below. To remove MOXA Industrial Media Converter from the DIN-Rail, simply reverse Steps 1 and 2 above.
Page 9: Wiring Requirements
STEP 3: Once the screws are fixed in the wall, insert the four screw heads through the large parts of the keyhole-shaped apertures, and then slide MOXA Industrial Media Converter downwards, as indicated below. Tighten the four screws for added stability. Wiring Requirements Do not disconnect modules or wires unless power has been switched off or the area is known to be non hazardous.
Page 10: Wiring The Alarm Contact
Safety First! Be sure to disconnect the power cord before installing and/or wiring your MOXA Industrial Media Converter. Safety First! Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes dictating the maximum current allowable for each wire size. If the current goes above the maximum ratings, the wiring could overheat, causing serious damage to your equipment.
Page 11: Wiring The Redundant Power Inputs
FAULT: The two middle contacts of the 6-contact terminal block connector are used to detect both power faults and port faults. The two wires attached to the Fault contacts form an open circuit when: 1. IMC has lost power from one of the DC power inputs.
Page 12: Communication Connections
Communication Connections IMC-101 models have one 10/100BaseT(X) Ethernet port, and one 100BaseFX (SC or ST type connector) fiber port. 10/100BaseT(X) Ethernet Port Connection The 10/100BaseT(X) ports located on IMC’s front panel are used to connect to Ethernet-enabled devices. Below we show pinouts for both MDI (NIC-type) ports and MDI-X (HUB/Switch-type) ports, and also show cable wiring diagrams for straight-through and cross-over Ethernet cables.
Page 13: Redundant Power Inputs
SC-Port Pinouts SC-Port to SC-Port Cable Wiring ST-Port Pinouts ST-Port to ST-Port Cable Wiring This is Class 1 Laser/LED product. Do not stare into the Laser Beam. Redundant Power Inputs Both power inputs can be connected simultaneously to live DC power sources.
Page 14: Dip Switch Setting
Dip Switch Setting IMC-101 series DIP switch Dip Switch 1 (Default: Off ) ON: Enables the PORT Alarm. If the port’s link fails, the relay will form an open circuit and the fault LED will light up. Off: Disables the corresponding PORT Alarm. The relay will form a closed circuit and the Fault LED will never light up.
Page 15: Auto Mdi/Mdi-X Connection
100BaseTX Port’s link is inactive FX port’s 100 Mbps is active 100M Data is being transmitted at 100 GREEN Blinking (FX) Mbps 100BaseFX port is inactive 100BaseFX port is being transmitted at full duplex FDX/COL GREEN Collision occurs Blinking 100BaseFX port is being transmitted at half duplex Auto MDI/MDI-X Connection The Auto MDI/MDI-X function allows users to connect MOXA Industrial...
Page 16: Specifications
Specifications Technology Standards IEEE802.3, 802.3u, Link Fault Pass-Through Interface RJ45 ports 10/100BaseT(X) Fiber ports 100BaseFX (SC, ST connectors available) LED Indicators Power, Fault, 10/100M, Full Duplex/Collision, Dip Switch Port break alarm mask, 100BaseFx Full/Half duplex selection Alarm Contact One relay output with current carrying capacity of 1A @ 24 VDC Optical Fiber Distance...
Page 17: Environmental Type Tests
EN61000-4-4 (EFT), level 3 EN61000-4-5 (Surge), level 3 EN61000-4-2 (CS), level 3 Shock IEC 60068-2-27 Free Fall IEC 60068-2-32 Vibration IEC 60068-2-6 WARRANTY 5 years EMS Type Tests Severity Test Description Test Levels Levels +/- 8 KV discharge Contact +/- 6 KV discharge 61000-4-2 contact...
Page 18: Moxa Internet Services
MOXA Internet Services Customer satisfaction is our number one concern, and to ensure that customers receive the full benefit of our products, Moxa Internet Services has been set up to provide technical support, driver updates, product information, and user’s manual updates.
Page 19: Revision History
Revision History Document Revision Date Revision Details Edition June 15, 2004 Updated the edition of this manual on the title page. Changed the Moxa logo on the title page. Added several “Attention” messages Added one product feature: Operating temperature ranges from 0 to 60°C, or extended operting temperature from –40 to 75°C for (-T) models.
