- Page 1 TRANSCODERS MANUAL PART NUMBER: 400-0031-003 PRODUCT REVISION: 1 TR6102HD HDTV/DVD/COMPONENT VIDEO TO RGBHV TRANSCODER USER’S GUIDE...
-
Page 2: Table Of Contents
INSTALLING YOUR TRANSCODER...4 OPERATION ..4 RGB OUTPUT..5 POWER ..5 CABLE REQUIREMENTS ..5 ACCESSORIES..5 ALTINEX POLICY ..6 LIMITED WARRANTY..6 RETURN POLICY ..6 CONTACT INFORMATION ... 6 Page... -
Page 3: Precautions / Safety Warnings
TRANSCODERS Do not place heavy objects on top of the TR6102HD. If the TR6102HD is to be mounted to a table or wall, use only Altinex made mounting accessories, such as the mount mini- brackets DA1295SX and cables for optimum setup. -
Page 4: About Your Transcoder
Any changes or modifications to the unit not expressly approved by Altinex, Inc. could void the user’s authority to operate the equipment. ABOUT YOUR TRANSCODER The TR6102HD Transcoder is a product of exceptional quality and design. It offers one HDTV input and three buffered outputs. -
Page 5: Application Diagram
APPLICATION DIAGRAM INSTALLING YOUR TRANSCODER Step 1. Connect the video output of the W-VHS VCR or HDTV camera to the video input of the TR6102HD using 3-BNC coaxial cables. Step 2. Connect the display device to one of the 3 output ports of the TR6102HD using the proper cable. -
Page 6: Power
CONNECTOR CONNECTOR TYPE Table 5. Main output RGBSHV output configuration 6.3 POWER The power module is configurable to 110 or 220 volts. To reconfigure the unit, squeeze together the two prongs of the fuse module of the power module and pull it out from its socket. Remove the fuse box and install it to display the desired voltage in the voltage window. -
Page 7: Altinex Policy
8.2 RETURN POLICY It is very important to Altinex that you receive the products that you have ordered and that this product fulfills your need. In the unlikely event,...
