Summary of Contents for Equator CM 3000
- Page 1 EQUATOR SERVICE MANUAL SPARE PARTS CATALOG First Edition - October 2003 BUFFET CART MODELS: CM 3000 www.EquatorOnline.com Advanced Appliances...
-
Page 3: Table Of Contents
TABLE OF CONTENTS WARRANTY SERVICE HINTS TECHNICAL DATA WIRING DIAGRAM EXPLODED VIEW PARTS LIST... -
Page 4: Warranty Information
WARRANTY INFORMATION Your Equator appliance is protected by this warranty under normal, personal, family or household use (1 Year), and limited commercial use (90 days) in the USA and Canada. WARRANTY Equator Corporation undertakes to the consumer-owner to repair or, at Equator Corporation’s option, to replace... -
Page 5: Disassembly And Assembly
DISASSEMBLY AND ASSEMBLY ENSURE APPLIANCE IS DISCONNECTED FROM THE ELECTRICITY SUPPLY BEFORE DISASSEMBLING. NOTE ALL CONNECTION DETAILS AND ROUTING OF LEADS BEFORE DISASSEMBLING. Numbers appearing in the text rater to illustrations and parts list numbers. A. SLIDING TABLETOPS Slide both tabletops open. Remove cover caps 130 end the two screws securing handle 105. Withdraw the handle from the tabletop assembly. -
Page 6: Mains Lead
D. MIDDLE AND BOTTOM ELEMENT ASSEMBLY / NEON Remove rear cover strip 510 as shown in C.1. And disconnect the middle shelf element leads 113 from terminal block 120 (See note in C. 1.) Remove the two screws securing the element assembly through the rear panel of the cabinet, and two screws from under the front edge of the shelf (bottom element front screws are under the front of the cabinet,behifld the bottom. -
Page 7: Service Information
CABINET ITEMS Magnetic catches 111 are a push-fit in front top panel 109. To remove front top panel 109, remove both sliding tabletops completely (see A.1.) and magnetic catches 111. Drill out the rivet at each end of the front slide panel using a 3mm bit. Use extreme care when drilling Withdraw leg top caps 108, and then remove the front top panel assembly. -
Page 9: Spare Parts List
ITEM GLASS DISH & LID GLASS DISH HOLDER TABLE TOP COVER TABLE TOP HANDLE TABLE TOP SLIDING BLOCK TOP ELEMENT ASSEMBLY LEG TOP CAP FRONT TOP PANEL GROMMET SLEEVE MAGNETIC CATCH (FS10) MID ELEMENT ASSEMBLY BRUANDET CASTER (4 PACK) CASTOR INSERT NEON ASSEMBLY TERMINAL BLOCK STRAIN RELEASE BUSH...
