CIRCLE SURROUND 3X
FOR HOME CINEMA
CS-3X, Jr.
The SMART Center Surround 3X for Home Cinema adds that extra dimension
of sound to your Dolby Digital
TM
or DTS Digital
TM
soundtracks from LaserDiscs
or DVD Discs. Add one or more rear wall speakers and additional amplifiers to
get the full enjoyment from the latest film releases encoded with the new
Surround EX
format. In addition, this product even allows you to play your
TM
existing digital soundtracks and hear them in a way you have never heard them
before. The existing in-phase material present in the Left Surround and Right
Surround channels is routed to the rear wall speakers and the directionality is
greatly enhanced. A CENTER FILL level control lets you easily balance the rear
wall speakers against the Left Surround and Right Surround speakers. You can
easily select between the CS-3X mode and the regular LS-RS mode with the
push of a button. Built-in pink noise lets you easily set the surround channel
levels, and if you have equalizers installed, the pink noise source gives you a
signal that a Real Time Analyzer expects. This product even has a built-in
subwoofer output signal for adding those usually missing low frequencies to
your surround system. By adding a subwoofer system to the surrounds, when a
sound pans from the front speakers to the surrounds, the low frequency
information can also be heard from the surround system. This can significantly
enhance your listening experience if your surround speakers do not handle
low frequencies very well.
Copyright 1999-2000 by SMART Devices, Inc.
5945 Peachtree Corners East
Norcross, GA 30071-1337
Devices, Inc.
CS-3X, Jr. Rev 3 Manual
12/15/1999
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SMART CIRCLE SURROUND 3X
Summary of Contents for SMART CIRCLE SURROUND 3X
- Page 1 CIRCLE SURROUND 3X FOR HOME CINEMA CS-3X, Jr. The SMART Center Surround 3X for Home Cinema adds that extra dimension of sound to your Dolby Digital or DTS Digital soundtracks from LaserDiscs or DVD Discs. Add one or more rear wall speakers and additional amplifiers to...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION: --Read all of these instructions. --Save these instructions for later use. --Follow all warnings and instructions in this manual and on the product. Read all the safety and operating instructions before connecting and operating the product. Follow all operating and use instructions. -
Page 3: Table Of Contents
Thank you for buying this SMART product. Please take the time to familiarize yourself with this product by carefully reading this manual. Most questions can be answered by reading and following the in- structions contained herein. Because of the multitude of products from other manu- facturers, this manual cannot possibly cover all the different configurations and hookups. -
Page 4: Installation Precautions
INSTALLATION PRECAUTIONS Noise Interference may result if this product is placed too close to an operating television set or a computer, or if it is placed on top of an amplifier or power con- ditioner product. High temperatures are detrimental to the performance and longetivity of electronic equipment. -
Page 5: Setting Levels
SETTING LEVELS The CS-3X, Jr. comes from the factory set up for unity gain levels. This means that whatever levels are going in are also the same levels going out. This is probably adequate for most situations. However, there are trimpots provided for adjusting the levels of each individual channel. -
Page 6: Cautions
CAUTIONS This product requires that the LS and RS inputs have reasonably well-balanced levels and NO equalization or tone control shaping of the signals. If your proces- sor has gain or balance adjustments for the LS and RS channels, make sure that the signal levels are set the same. -
Page 7: Multi-Channel Matrix Decoder
MULTI-CHANNEL MATRIX DECODER This product can also be used as a complete multi-channel matrix decoder for use with a standard 2-channel audio source such as a Hi-Fi Stereo VCR, LaserDisc or DVD player. Using the product in this way requires that you have a proces- sor or control center with multi-channel analog inputs. -
Page 8: Specifications
8.6” W x 2.00” H x 6.25“ D LIMITED WARRANTY SMART products and accessories are warranted against malfunction or failure due to defects in workmanship or materials for a period of one year from the date of shipment. If a problem occurs during the warranty period, the unit will be repaired, without charge for materials or labor.
