DRS-50 T
-L
RANS
INGUAL
CINEMA DIALOG
REPLACEMENT SYSTEM
I
NSTALLATION AND
O
M
PERATION
ANUAL
Devices, Inc.
Copyright 2000
by SMART Devices, Inc.
5945 Peachtree Corners East
Norcross, GA 30071-1337
1-800-45-SMART
or
770-449-6698
TXL1D600.P65
Published 05/30/2000
Advertisement
Summary of Contents for SMART DRS-50 Translingual
- Page 1 DRS-50 T RANS INGUAL CINEMA DIALOG REPLACEMENT SYSTEM NSTALLATION AND PERATION ANUAL Devices, Inc. Copyright 2000 by SMART Devices, Inc. 5945 Peachtree Corners East Norcross, GA 30071-1337 1-800-45-SMART 770-449-6698 TXL1D600.P65 Published 05/30/2000...
- Page 2 Our limited warranty does not cover damages resulting from accident, mis- use or abuse, lack of responsible care, or failures not attributable to manu- facturing defects, except as provided herein. SMART Devices, Inc. makes no warranties, express or implied, including warranties of merchantability or fitness for a particular purpose.
- Page 3 SMART DRS-50 Trans-Lingual. We strongly encourage new owners of the DRS-50 to thoroughly read this en- tire manual before placing their new SMART product into service. This will ensure that the DRS-50 will be operated properly to give the superior per-...
- Page 4 DRS-50 TRANS-LINGUAL OVERVIEW 1. Description The SMART DRS-50 Cinema Translingual is a dedicated dialog replacement system designed as a simple and cost- effective tool for presenting foreign language films in small theatres. A live translator can dub over a soundtrack channel at the touch of a button.
- Page 5 USER’S GUIDE 1. Rack Active indicator 2. Monitor Volume Level 3. Rack Intercom “push to talk” button 4. VOX sensitivity level 5. Remote Active indicator 6. Headphone volume level 7. Power/Mode dial 8. Remote Intercom “push to talk” button 9. Headphone jack 10.
-
Page 6: Installation
12 pin Phoenix connectors to the cables. Make sure the wiring on each end is the same. The suggested wiring diagram with the SMART cable part is as follows (from left to right looking at the back of... - Page 7 USER’S GUIDE SIGNAL WIRE COLOR ON/OFF GREEN BLUE BLACK (insulated pair) RED (insulated pair) LHEAD PURPLE RHEAD YELLOW RED\BLACK ORANGE RED\WHITE BROWN BLACK Make sure the remote unit’s VOX/MAN/OFF knob is set to the OFF position. Plug the Phoenix connectors into the rear of the rack and remote units.
-
Page 8: Operation
DRS-50 TRANS-LINGUAL MIC LEVEL. R54 sets the overall level of the microphone signal when in dub mode. These pots have been set at the factory for standard operation. Test the Trans-Lingual in your auditorium with these settings, and then adjust settings as desired. OPERATION REMOTE CONSOLE OFF/MANUAL/VOX KNOB. - Page 9 USER’S GUIDE COUGH/MUTE. While this button is pushed, the VOX detection circuit is deactivated. MANUAL. Pressing this button engages the dubbing action. RACK UNIT ACTIVE LED. This LED indicates when the Trans- Lingual is in dubbing mode. MONITOR LEVEL. This controls the volume of the monitoring speaker in the rack unit.
- Page 10 DRS-50 TRANS-LINGUAL...
- Page 11 USER’S GUIDE...
- Page 12 DRS-50 TRANS-LINGUAL...
