    SPECIAL APPLICATION CP451-008 shown with optional docking cradle. MANUAL PART NUMBER: 400-0518-001 CP451-008 MULTITOUCH WIRELESS TOUCH SCREEN CONTROLLER USER’S GUIDE...
  • Page 2: Table Of Contents

    PREPARING CONTROL SOFTWARE ...10 INSTALLING FILES AND APPLICATIONS...10 INSTALLING LARGE FILES...10 AVSNAP ...11 TROUBLESHOOTING GUIDE ... 11 POWER IS NOT ON...11 SOFTWARE/FILES ARE MISSING ...11 ALTINEX POLICIES ... 12 LIMITED WARRANTY/RETURN POLICIES ...12 CONTACT INFORMATION ...12 400-0518-001 SPECIAL APPLICATION Page...
  • Page 3: Precautions / Safety Warnings

    Any changes or modifications to the unit not expressly approved by ALTINEX, Inc. could void the user’s authority to operate the equipment. cause undesired...
  • Page 4: About Your Cp451-008

    Since the CP451-008 can run on battery power, most setups use the WLAN feature. For added flexibility, consider ALTINEX TCP/IP to RS-232 Adapter. This adapter allows RS-232 communication through a standard LAN connection. Place the AC301-201 on an RS-232 controlled device and then connect it to a wireless router for an instant wireless network.
  • Page 5: Technical Specifications

    TECHNICAL SPECIFICATIONS Specifications are subject to change. www.altinex.com for up-to-date information. FEATURES/ DESCRIPTION Details LCD Size Resolution Colors AMD Geode™ LX 800 WLAN Solid State Drive (SSD) External Connections External Battery Docking Bay 12VDC Microphone Headphones Agency Approval Safety Accessories Included...
  • Page 6: Product Description

    PRODUCT DESCRIPTION Network LED Power Switch USB Port 400-0518-001 SPECIAL APPLICATION Power/Charging LED Microphone Docking Port Connector Stylus Headphones Microphone In Brightness Control +12VDC In Speaker...
  • Page 7: Application Diagrams

    SPECIAL APPLICATION APPLICATION DIAGRAMS DIAGRAM 1: TYPICAL SETUP 400-0518-001...
  • Page 8: Diagram 2: Dimensions

    SPECIAL APPLICATION DIAGRAM 2: DIMENSIONS 400-0518-001...
  • Page 9: Diagram 3: Ac404-101 (Optional)

    DIAGRAM 3: AC404-101 (OPTIONAL) The docking cradle uses the CP451-008’s power supply as its input power source. The cradle makes an excellent charging station as well as providing an Ethernet port and 2 additional USB ports. A network connection, USB keyboard, and USB mouse can be permanently attached to the cradle making it a central base and charging station.
  • Page 10: Installing Your Cp451-008

    INSTALLING YOUR CP451-008 Step 1. The CP451-008 only requires power to be operational. If using the docking cradle, determine the best location for installation. The docking cradle should be centrally located to the CP451-008’s operational area so users will remember to return the unit to the cradle for charging.
  • Page 11: Operation

    OPERATION The CP451-008 is designed for use in a fixed application where the system boots up directly into the user application and does not allow access to the operating system. The application and GUI interface are normally created using a standard desktop computer and then installed onto the CP451-008 using a USB drive or network connection.
  • Page 12: Avsnap

    The CP450 has a problem. If there is AC power to the adapter and the LED still does not turn on, the CP451-008 or the power adapter may require service, call ALTINEX at (714) 990-2300. Changes were not committed to memory.
  • Page 13: Altinex Policies

    9.1 LIMITED WARRANTY/RETURN POLICIES Please ALTINEX www.altinex.com for details on warranty and return policies. 9.2 CONTACT INFORMATION ALTINEX, Inc. 592 Apollo Street Brea, CA 92821 USA TEL: 714 990-2300 TOLL FREE: 1-800-ALTINEX WEB: www.altinex.com E-MAIL: solutions@altinex.com 400-0518-001 SPECIAL APPLICATION website...
