ENGLISH
Type
AZ-F920F
Deodorant dust collection
filter for air conditioner
(2-sheet package)
How to Change
Open panel
1
2
Deodorant dust
collection filter
3
2
1
Replace the deodorant dust collection filter at the intervals of 3-6
months depending on the cleanliness of the air.
• The dirty deodorant dust collection filter is not washable for reuse.
The new filter is available at your nearest dealer.
Applicable air-conditioner models
AY-XP7FR,AY-XP9FR,AY-XP12FR,
AY-XPM7FR,AY-XPM9FR,AY-XPM12FR,etc.
Precautions
• The filters are sealed in a plastic bag
to keep their dust collection effect. Do
not open the bag until using the filters.
(Otherwise the filters' life may get
shorter.)
• Do not expose the filters to direct sun-
light. (Otherwise they may deteriorate.)
Air filter
3
Deodorant dust
collection filter
Filter stopper
Replacement intervals guideline
1
Take out the air filters.
1 Open the open panel.
2 Push the air filters up slightly to unlock
them.
3 Pull the air filters down to remove them.
2
Change the deodorant dust collection filter.
1 Take off the old deodorant dust collection
filter from the air filter.
2 Set the new deodorant dust collection
filter, under the filter stoppers located on
the air filter.
3
Reinstall the air filters.
1 Reinstall the air filters in the original
position.
2 Close the open panel.
3 Push the arrow-marked of the panel firmly
to lock it in place.
Printed in Japan
TINSEA445JBRZ 05HO
1
