SGC SG-303 Manual

HIGH PERFORMANCE HF SSB ANTENNA FOR MARINE AND MOBILE USE
ITEM # 55-27: SG-303 W/ MOUNT / ITEM # 55-67: SG-303 W/O MOUNT
ITEM # 55-28: SG-307 W/ MOUNT / ITEM # 55-69: SG-307 W/O MOUNT
DESCRIPTION
The SG-303 and the SG-307 are designed to radiate efficiently at HF frequencies from 2-30 MHz.
Both antennas provide reliable long range communications. Their short length permits
communication from a vehicle in motion (60 MPH or 100 KPH speed maximum). The antennas
must be used with an antenna coupler (SG-230 or any coupler with a similar specification).
SPECIFICATIONS
Specification
Maximum Input Power.
Operating Range.
Primary Loading Resonance:
Secondary Loading Resonance
Mounting
Ratchet mount material:
Maximum vehicle or boat speed:
Radiation:
Shipping weight:
Maximum total height:
Maximum shipping length
ITEMS SUPPLIED
1. Loaded whip antenna (in two sections of 4 ft each for the SG-303)
2. 3 iinch, high voltage Delron insulator
3. 4-way stainless steel ratchet mount
4. Special SGC heavy duty, rubber encapsulated base spring
5. 3 ft. of high voltage wire, one end terminated by a ring lug
6. High voltage wall feed-through bushing (hole = .890 inch)
7. 3 ft of ¾ inch wide braided copper ground strap for coupler grounding
8. 12 releaseable tie wraps
9. Lug to connect high voltage wire to coupler
10. Manual
© SGC 2007
SG-303/307 WHIP ANTENNA MANUAL
SG-303
500 Watts PEP or CW
2-30 MHz
11 Mhz
22 MHz
High Voltage, 4-way
Ratchet
Stainless Steel
60 MPH/100 KPH
(when erect)
Omnidirectional
10 pounds
9 feet
4.5 feet
SG-307
150 Watts PEP or CW
2-60 MHz
8 Mhz
25 MHz
High Voltage, 4-way
Ratchet
Stainless Steel
60 MPH/100 KPH
(when erect)
Omnidirectional
8 pounds
7 feet
7.5 feet
