Summary of Contents for Scytek electronic SkyTrak-3000
- Page 1 VEHICLE TRACKING SYSTEM SKYTRAK-3000...
- Page 2 Limited Lifetime Warranty This vehicle tracking system is warranted to the original purchaser, to be free from defects in material and workmanship. The manufacturer will repair or replace at its option, and free of charge for the first twelve (12) months, any part that proves defective in material or workmanship under normal installation, use, and service, provided the product is returned to the manufacturer freight prepaid.
-
Page 3: Table Of Contents
Table of Contents About Your System ............Page 1 Quick Start Guide . -
Page 5: About Your System
About Your System The SkyTrak 3000 is a Vehicle Tracking System System Features: • Unlimited Real-time GPS tracking with user-friendly internet software • Bread Crumb History Trail • Fast Response Time • High gain GPS/Cellular antenna • Issue commands via internet or web enabled Cell Phone •... -
Page 6: Quick Start Guide
Quick Start Guide for SkyTrak 3000 System Registration: To Register your SkyTrak 3000 1- Login on to www.scytrak.net 2- Click on the “Click to register” Page 2 - SkyTrak 3000... -
Page 7: New Master Account Registration Page
New Master Account Registration Page New Master Account Registration screen. In the “User ID” area type in your login ID, then complete the rest of the information. After completing Master Account registration page, click on “O.K” at the bottom far right side. -
Page 8: New Vehicle Registration Page
New Vehicle Registration Page New Vehicle Registration screen In the “Vehicle’s ID ” area type in the Vehicle name such as Johny’s Car or Vehicl’s model, then complete the rest of the information. SkyTrak 3000 - Page 4... -
Page 9: Billing Information Page
Billing Information Page Billing information screen. In the Service Term Area, select the yearly plan that you like. then complete the rest of the information. SkyTrak 3000 - Page 5... -
Page 10: Sub User Account
Sub User Account Subuser account allowes for additional users to manage the fleet vehicles with varies degrees of control. Click on Subuser Management to edit the page. Register the subuser and assign the vehicles and checkmark the desired privilege of the user. -
Page 11: Skytrak 3000 Login Page
SkyTrak 3000 Login Page login page www.scytrak.net SKYTRAK 3000 GPS Login Page: Login: input your Login ID and your Password. “you may changeyour password at any time for your personal security” Click on the field marked "Sign in" and you will then be taken to your SKYTRAK 3000 GPS Home Page. SkyTrak 3000- Page 7... -
Page 12: The Home Page
The Home Page Your SKYTRAK 3000 GPS Home Page will have your vehicle(s) listed and look very similar to this. Click on the Vehicle name to select that particular vehicle, the screen will refresh displaying the map with the breadcrumb trail showing the last locations of the vehicle. - Page 13 Vehicle Alert Window: Vehicle alert window is located bellow the map, it contains; 1. Number of events displayed on the map Select the number of events on the map by selecting 1,10,40 of 80, recorded events will be displyed showing the state of the vehicle and tthe dirction of the motion.
-
Page 14: Skytrak 3000 Main Page
System Alerts 1. Geo Fence Alert setup: Type in the address of the Geo Fence window and the boundary size, chose if alert is for antry into or exit from the boundaries. Select the Geo Fence Alert. 2. Time Fence Alert: Set the time alert window, when alert is on, if the vehicle ignition is turned on within the time window an alert will be set. - Page 15 SkyTrak 3000 Main Page In the main Page provides tracking and control of the vehicles. View all vehicle locations on the map by checking the Check all box and clicking on the Track Today/Refresh button. Refresh location manually by clicking on the Track button of the specific vehicle. When sucess result appears the map will refresh automatically and diplay the latest vahicle location.
- Page 16 Outputs SkyTrak system has been provided with four outputs. The system is designed for stand alone use or with combination of ScyTek Security systems. Using with combination of ScyTek Security Output 3 - Arms or Disarms the Security System Output 4 - Starts or Stops Vehicle Remote Start Output 1 - Trunk Release Output 2 - Momentary activation of auxiliary output Stand Alone Mode:...
-
Page 17: Landmark Management
Landmark Management From the vehicle history table click on the set button in Landmark column, the landmark window will open up. Select the appropriate icon and name the landmark. The icon will appear on the map for easy vehicle location identification. Page 13 - SkyTrak 3000... -
Page 18: Mounting The Skytrak 3000
Mounting the skyTrak 3000 The main unit can be mounted under the dashboard. The GSM/GPRS antenna affixes to the windshield with the double sided tape. he GPS Antenna affixes on the dashboard with double sided tape. The GSM and GPS anttena can be hidden under the dashboard. Note: The GPS antenna if hidden the top side must be faced towards the sky. -
Page 19: Door Lock Diagrams
Door Lock Diagrams Adding Actuators Negative Trigger Reverse Polarity Positive Trigger blue green Starter Interrupt Positive Horn Honk Page 15 - SkyTrak 3000... -
Page 20: Wiring Diagram
Wiring Diagram ANTENNA SKYTRAK 3000 GPRS ANTENNA GPRS ScyTek Galaxy Security System Green Output 1 (-) Pulsed BLUE Output 2 (-) Pulsed ORANGE Output 3 (-) Latched On/Off WHITE Output 4 (-) Latched On/Off GRAY Input 4 (+) Trigger BROWN Input 3 (-) Trigger PINK Input 2 (-) Trigger...
