Ricoh MP7080A User Manual

Cd-r/rw & dvd-rom drive

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Conventions

Introduction

Handling Procedures

Features

System environment

Drive functions and settings

Installing the Drive

How to Use the Drive

Specifications

Contents

Conventions

Introduction

Handling Procedures

Features

System environment

Drive functions and settings

Installing the Drive

How to Use the Drive

Specifications

NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communication. However, there is no guarantee that interference

will not occur in a particular installlation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

Consult the dealer or an experienced radio / TV technician for help.

FCC WARNING

Changes or modification not expressly approved by the party responsible for compliance could void the

user's authority to operate the equipment.

CAUTION

Use of controls or adjustments or performance of procedures other than those specified herein may

result in hazardous radiation exposure.

Akustischer Geräuschpegel

Use of controls or adjustments or performance of procedures other than those specified herein may

result in hazardous radiation exposure.

Dieser Druckerüberschreitet einen Ger

uschpegel von 70 dB (A) w

hrend dem Betrieb nicht.

Table of Contents

Need help?

Do you have a question about the MP7080A and is the answer not in the manual?

Questions and answers

Summary of Contents for Ricoh MP7080A

Page 1: System Environment
Conventions Contents Introduction Handling Procedures Conventions Features Introduction System environment Handling Procedures Drive functions and settings Features Installing the Drive System environment How to Use the Drive Drive functions and settings Specifications Installing the Drive How to Use the Drive Specifications NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device,...
Page 2 Declaration of Conformity "The Product complies with the requirements of the EMC Directive 89/366/EEC and the Low Voltage Directive 73/23/EEC." Please take notice that the manufacturer of this equipment does not offer any warranty against data loss due to inappropriate installation or handling, or direct or indirect damages. Please take notice that the manufacturer will bear no responsibility for direct or indirect damages caused by the use of this product or its malfunction.
Page 3 Conventions This manual uses the following symbols which indicate important information. Be sure to read the information. Ignoring this warning and incorrect handling may result in serious personal injury or damage to the product. Indicates restriction or caution that you should notice. Provides useful additional information.
Page 4 Introduction This manual contains important notes and product handling information. Be sure to read the manual before using the product. For easy reference in the future, please keep the manual at a handy location. Multimedia Printer series Thank you for purchasing the Multimedia Printer series drive MP7080A (hereafter referred to as the drive). The drive enables you to play CD-ROM discs, write once and play CD-R discs, or write, play, and rewrite CD-RW discs.
Page 5 Handling Procedures Obey the following cautions when handling the drive or discs. Cautions During Installation Install the drive in accordance with the specifications. Be careful to avoid locations likely to cause vibration or shock. Avoid locations where there is high humidity, excessive dust, or poor ventilation. Avoid locations in direct sunlight, with severe changes in humidity, or places where there are extremely high or low temperature variations.
Page 6 Check to see if there is dirt on the surface of the disc. Be careful not to touch the disc with the fingers when doing this. (See Fig. 1) After cleaning the disc with compressed air, place it on the disc tray and mount it.(See Fig.
Page 7 fig1 1. Check 2. Recording surface fig2 1. 50 to 100mm Back...
Page 8 Features Completely sealed door construction provides high reliability. An improved anti-heat design means that no cooling fan is needed. Easy-to-use tray model. Enhanced-IDE (ATAPI) model Compliant with industry standard Orange Book Part II (CD-R) and Part III (CD-RW). Can read not only CD-R and CD-RW discs, but also video CDs, music CDs, photo CDs, and CD-Text Can read data at 32x speed (4.8MB/sec data transfer rate) and write data at 8x speed (1,200KB/sec data transfer rate).
Page 9 +5V/+12V power socket required CD-R, CD-RW discs Ricoh, Mitsubishi Chemical, Taiyo Yuden, Mitsui Chemicals, Ritek, CMC, Princo, TDK, Kodak, Memorex, Maxcell or Philips discs are recommended. Average access time of 12msec or less and data transfer speed of 5MB/sec or greater are recommended.
Page 10 Specifications Drive Disc Drive : MP7080A Type Internal type Interface Enhanced-IDE (ATAPI) Data buffer memory Data transfer speed 16.7MB/sec. (Max.) CD-R/CD-RW 32X: 4.80 MB/sec. (Mode1, Mode2, Form1)[Read only] Write/Read speed (Ave.) 20X: 3.00 MB/sec. (Mode1, Mode2, Form1)[Read only] 20X: 3.40 MB/sec. (Mode2, Form2)[Read only] 1,200 KB/sec.
Page 11 * The above specifications are for Ricoh CD-R and CD-RW discs * Recommended Discs CD-R (74min./63min.) : Ricoh, Taiyo Yuden, Mitsubishi Chemical, Mitsui Chemicals, Ritek, CMC, Princo, TDK, Kodak, Memorex, Philips, and Maxell discs Taiyo Yuden, TDK, Maxell, Philips CD-R (80min.)
Page 12: Front Panel
Drive functions and settings Front Panel Rear panel Front Panel Disc tray This is the tray for the disc. Place the disc on the ejected disc tray, then lightly push the tray (or push the eject button) and the disc will be mounted. Caution Don't use force to pull out or push in the disc tray.
Page 13 How to Use the Drive Caution When using CD-ROM discs, CD-R discs or CD-RW discs, do not attach any stickers or labels to the discs. Using discs with labels attached not only causes read and write errors, but data on the disc may be lost due to damage to the disc itself.
Page 14: Rear Panel
Busy indicator This indicator lights orange when a disc is mounted into the drive. When the disc is being accessed, it flashes or lights orange. If a disc is not mounted, the indicator does not light even when the power is turned on. When a illegal disc is loaded or some hardware trouble occurs, the indicator blinks.
Page 15 Connect to the IDE (Integrated Device Electronics) interface using a 40-pin flat IDE cable. Caution Do not connect or disconnect the cable when the power is on, as this could cause a short circuit and damage the system. Always turn the power OFF when connecting or disconnecting the cable.
Page 16 Emergency Eject This drive has a function that allows the CD to be ejected manually, if this becomes necessary in an emergency such as failure of the drive or a power outage. Follow the following procedures in such a case. Caution This feature is a last measure to be used only in an emergency.
Page 17 Disc ejection 1. Press the eject button 2. Slowly take the disc out of the disc tray 3. Press the eject button or push the disc tray and the tray will be inserted back into the drive.
Page 18 Caution After ejecting the disc, return the disc tray inside the unit quickly. When the disc tray is in the ejected position, dust and other debris will enter, possibly causing read errors, write errors, or drive failure. Back Next Load the disc |Disc ejection | Emergency Eject Using the Drive in a Vertical Position...
Page 19 Load the disc 1. Press the eject button. 2. Place the disc on the disc tray. Caution When using a 120mm CD, place it in the large round depression. When using a 80mm CD, place it in the small round depression. The face with the label on it should be up.
Page 20 3. Load the disc by pressing the eject button or by lightly pushing in the disc tray.
Page 21 Next Load the disc | Disc ejection Emergency Eject Using the Drive in a Vertical Position...
Page 22 Using the Drive in a Vertical Position The drive can be installed in a vertical position. 1. Locate the four tabs on the disc tray. Turn each of them inwards untill they click into place. 2. When loading a disc, insert it into the inner side of the tabs. Caution Make sure the eject button is at the top of the unit when install the unit in a vertical position.
Page 23 Installing the Drive Specific knowledge of hardware and software is necessary to install the drive. We cannot guarantee against direct or indirect damage resulting from improper connections. Ask your supplier for details of the installation procedure. Before Installation Before installing the drive, please note the following points. You will need the following: A Phillips head screw driver of a suitable size to fit the securing screws for the drive unit.
Page 24: Jumper Set Up
Jumper Set Up Before installation, set the jumper on the jumper connector on the rear panel. 1. Master (MA) Drive set as Master (factory default) 2. Slave (SL) Drive set as Slave 3. Cable Select (CS) Drive mode set by CSEL on the host IDE interface The drive can be connected as the Master or Slave on an E-IDE (ATAPI) interface.
Page 25 If two peripheral devices with the same settings are both connected to the Primary or to the Secondary E-IDE bus, the host computer may fail to run, or may malfunction, so careful attention is necessary. Make sure that the host computer is turned OFF when connecting or removing a jumper.
Page 26: Removing The Computer Cover
Removing the Computer Cover Make sure all peripheral devices of the computer and the computer itself are turned off, and then remove the cover. Refer to the manual for the computer for details about removing the cover. Caution There may be sharp edges inside the computer take care to avoid injury. Back Next 1.
Page 27: Mounting The Drive
Mounting the Drive 1. Remove the 5 inch drive bay panel from the computer. Refer to the manual for the computer for details. 2. Insert the drive unit into the bay. Do not apply excessive pressure to the cables inside the computer. 3.
Page 28: Table Of Contents
Back Next 1. Jumper Set Up 2. Removing the Computer Cover 3. Mounting the Drive | 4. Connecting the Power Connector 5. PC Connections 6. Sound Card Connection 7. Replacing the Computer Cover 8. Device Drivers...
Page 29: Connecting The Power Connector
Connecting the Power Connector Connect the power cable from the computer's power supply to the socket on the drive unit, fitting the connector properly into the socket. If there is no spare power cable available in the computer, you will have to purchase a splitter cable of a suitable type. Back Next 1.
Page 30: Pc Connections
PC Connections The drive connects to the motherboard of the host computer using an IDE interface cable. Both Primary and Secondary connectors are usually provided on the motherboard, which may be connected as follows: 1. Master 2. Slave 3. Motherboard 4.
Page 31 To Install as a Slave Drive...
Page 32 To install the drive as a Slave, change the jumper setting on the rear panel. 1. Master drive (Booting hard disk) 2. Slave drive (MP9060A) 3. Secondary connector 4. Primary connector 5. Master drive (Other IDE drive)
Page 33 Back Next 1. Jumper Set Up 2. Removing the Computer Cover 3. Mounting the Drive 4. Connecting the Power Connector 5. PC Connections | 6. Sound Card Connection 7. Replacing the Computer Cover 8. Device Drivers...
Page 34: Sound Card Connection
Sound Card Connection If the computer has a sound card, the drive can be connected to the sound card with an audio cable. Make sure the connections are oriented so that L corresponds to L and R to R. Refer to the manual for the sound card for detailed information regarding connection. Audio digital output The drive supports S/PDIF(IEC958) for digital audio output.
Page 35: Replacing The Computer Cover
Replacing the Computer Cover When the installation of the drive unit is complete, replace the computer cover. Back Next 1. Jumper Set Up 2. Removing the Computer Cover 3. Mounting the Drive 4. Connecting the Power Connector 5. PC Connections 6.
Page 36: Device Drivers
Device Drivers When using Windows 98/95 or Window NT Workstation Ver. 4.0, the installation of any special device drivers are not required. In order to ensure normal drive operation or if the drive is not recognized by your computer, please check the following: In order to ensure normal drive operation If the drive is not recognized by your computer In order to ensure normal drive operation...
