VM2144VS/VM2145SS/VM2146UX and to prevent fire and shock hazard. Please read them carefully and heed all warnings. 1.1 GENERAL Qualified ALTINEX service personnel, or their authorized representatives must perform all service. 1.2 INSTALLATION To prevent fire or shock, do not expose this unit to rain or moisture.
ABOUT YOUR V-MATRIX™ VIDEO/SYNC OUTPUT CARDS VM2144VS/VM2145SS/VM2146UX 8-out V-MATRIX™ Video/Sync Output Cards The VM2144VS/VM2145SS/VM2146UX are 8- output Cards designed for use in a V-Matrix™ enclosure and can handle a wide array of signal formats and connector types. When installed in a V-Matrix™...
Application 3: Setting Jumpers for Sync - Positive Polarity (VM2145SS) Note: In the diagram above, the jumpers are set for positive polarity on the following ports: P7, P4, P6, P5, P13, P12, P15, and P14. For positive polarity, set jumper on the top pin and middle pin (pins are the dark circles).
Application 4: Setting Jumpers for Sync-Negative Polarity (VM2145SS) Note: In the diagram above, the jumpers are set for negative polarity on the following ports: P7, P4, P6, P5, P13, P12, P15, and P14. For negative polarity, set jumper on the bottom and middle pins (pins are dark circles).
Application 5: Setting Jumpers for Video (VM2146UX) Note: In the diagram above, the jumpers are set for video on the following ports: P8, P9, P11, P10, P16, P17, P18 and P19. For video, set jumper on the top pin and middle pin (pins are dark circles). The jumpers are the dark rectangles on the left side of the diagram next to the bold port numbers.
Application 6: Setting Jumpers for Sync-Positive Polarity (VM2146UX) Note: In the diagram above, the jumpers are set for positive sync polarity on the following ports: P8, P9, P11, P10, P16, P17, P18, P19, P7, P4, P6, P5, P13, P12, P15, and P14. For sync, set the jumpers on the left to the bottom pin and middle pin.
Application 7: Setting Jumpers for Sync-Negative Polarity (VM2146UX) Note: In the diagram above, the jumpers are set for negative sync polarity on the following ports: P8, P9, P11, P10, P16, P17, P18, P19, P7, P4, P6, P5, P13, P12, P15, and P14. For sync, set the jumpers on the left to the bottom pin and middle pin.
Make sure that you have signal sources connected to compatible displays. If the image quality is poor, please make sure that a high quality of cables is used. We recommend ALTINEX-made cables for best results. there VM2145SS/VM2146UX please call ALTINEX at (714) 990-2300.
9.2 RETURN POLICY It is very important to ALTINEX that you receive the products that you have ordered and that this product fulfills your need. In the unlikely event, that an...
