Niles Music Anywhere! In-Ceiling Kit Installation And Operation Manual page 4

INSTALLATION
Cutting the Hole When the bracket is secure,
bend the tabs back against
the inside of the drywall and
Once you have decided
insert the screws so that they
upon an ideal installation
penetrate the tabs, clamping
location for the Wall-
the bracket to the drywall.
Mounted Volume Control,
(See Figure 7)
hold the Mounting Bracket
up to the wall surface. Level
the Mounting Bracket and
Running the
mark the wall by tracing the
Speaker Cable
inside perimeter of the
Mounting Bracket with a
Conceal the Speaker Cable
pencil. Repeat the same
between the stereo equip-
procedure for the In-Ceiling
ment and the Wall-Mount
Speakers using the supplied
Volume Control, and
template to trace a 9-1/4"
between the Wall-Mount
diameter hole for each In-
Volume Control and the
Ceiling Speaker.
Speakers.
(See Figure 3)
Be sure to measure the
!
If you are cutting a painted
approximate distance
or wallpapered ceiling, use
from your equipment to
a razor-knife to cleanly cut
the Wall-Mount Volume
the wallpaper. Then use a
Control location, and from
drywall saw to cut the dry-
the Wall-Mount Volume
wall. (See Figure 4)
Control to the first and
second Speaker locations
Be very careful not to saw
!
to ensure that you have
through existing wires,
enough wire to complete
pipes or structure.
the installation.


y z  y z |
Installing the (See Figure 8)
Mounting Bracket
Figure 6
Place the Mounting Bracket
y  |
against the hole.
(See Figure 5)
Bend the tabs at a 90° angle
and insert into the hole.
(See Figure 6)
Figure 3
Figure 4

| z
 |  y z
Figure 5

| z y  |   |
y z

y
y zy
y z | |        |
Figure 7
5
INSTALLATION
Connecting the conductors and remove 1/4"
Speaker Cable to of insulation from the end of
the Volume Control each conductor. Twist the
end of each conductor so
the ends are not frayed.
! Connecting the Volume
Make sure that no more
Control backwards could
than 1/4" of bare wire is
damage your amplifier.
exposed.
Make sure to connect the
Speaker Cable coming
! Exposing too much wire
from your amplifier to
could cause the wires to
the INPUT of the Volume
touch and create a "short"
Control (labeled AMPLIFI-
which could damage
ER), and the OUTPUT of
z
y y zz


your equipment.
the Volume Control
(labeled SPEAKERS) to
Connect the exposed ends
the In-Ceiling Speakers.
of each of the Speaker
Cable's conductors to the
Strip the wire jacket back 2"
removable connectors pack-
to expose the four colored

    y z | |
Figure 8
green
white
red and black
(unused)
Left Speaker
red black
Carefully make a 12" incision in the wire jacket to
!
expose all four colored conductors (be careful
not to damage the colored conductors inside!).
Cut only the red and black wires at the top of the
incision and strip approx. 3/8" of insulation from
!
the ends of each conductor. Connect the red and
black wires to the speaker as shown above.
aged with the Wall-Mount
Volume Control. (See
"Connect the wires" at
the bottom of page 7.)
If you are going to connect
more than two pairs of
speakers to the amplifier,
the Volume Control's
"Impedance Magnifying"
jumpers must be reset.
(See Figure 10, Page 8
of this manual)
yy
z
Refer to the Installation
section on page 8 of the
VCS-2D-IM Volume Control
manual included with your
Music Anywhere! In-Ceiling
z
    | | y y
see Inset
Right Speaker
Inset
white
green
to "speaker"
red black
connection on
volume control
6
