- Page 1 MULTI-TASKER™ MANUAL PART NUMBER: 400-0401-001 MT100-108 12-SLOT MULTI-TASKER™ ENCLOSURE USER’S GUIDE...
-
Page 2: Table Of Contents
PRODUCT DESCRIPTION ...4 INSTALLING YOUR MT100-108 ...5 OPERATION ...5 RS-232 CONNECTION ...5 RS-232 PROTOCOL ...6 TROUBLESHOOTING GUIDE ...6 CARD CAGE IS NOT WORKING ...6 CARD IS NOT WORKING ...6 ALTINEX POLICY ...6 LIMITED WARRANTY/RETURN POLICY ...6 CONTACT INFORMATION ...6 400-0401-001 MULTI-TASKER Page... -
Page 3: Precautions / Safety Warnings
1.3 RACK-MOUNT INSTALLATION Use only ALTINEX supplied rack-mount ears for mounting the MT100-108 into a rack. The maximum operating ambient temperature is 35ºC (95ºF). -
Page 4: About Your Mt100-108
ABOUT YOUR MT100-108 MT100-108 Multi-Tasker™ 12-Slot Enclosure Empty card-cage with 12 slots available Basic foundation of Multi-Tasker™ solutions 3U high, full rack wide Rack ears included The Multi-Tasker™ 12-Slot Enclosure, MT100-108, comes with a front panel installed. However, the front panel MT101-115 must... -
Page 5: Product Description
PRODUCT DESCRIPTION MT100-108 FRONT PANEL OPTION 36 PROGRAMMABLE BUTTONS MT100-108 REAR VIEW 400-0401-001 MT101-115 RS-232 CONTROL FROM FRONT PANEL SLOTS 1-12 MULTI-TASKER 9 10 11 12 RS-232 RS-232 CONTROL POWER INPUT... -
Page 6: Installing Your Mt100-108
INSTALLING YOUR MT100-108 Step 1. Connect the power entry connector of the MT100-108 to the power outlet with the provided power cord. The power supply is universal and will work throughout the world with voltages from 110V-240VAC. Step 2. If a control system is used to control the cards in the MT100-108, connect the RS-232 port of the MT100-108 to the control... -
Page 7: Rs-232 Protocol
LED lights in that slot. If it lights, then the original card may be the source of the problem. Call ALTINEX at (714) 990-2300. If the original card was not the source of the problem, see Cause 2. 400-0401-001 Cause 2: Solution 1: Push the card in all the way.
