Grizzly T10044 Instruction Sheet

To reduce the risk of injury when using this
equipment:
• Do not allow anyone to operate the
spreader without proper training.
• Do not allow children to use spreader.
• Always wear proper protective gear when
using the spreader.
• If an object becomes lodged in the hop-
per, do not attempt to remove it while the
impeller is moving.
• Keep all hardware tightened to be sure
the spreader is in safe working order.
Inventory (Figures 1, 2 & 3)
A. Hopper Assembly (not shown) ................... 1
B. Catch Tray (not shown) .............................. 1
C. Left Wheel Frame ....................................... 1
D. Right Wheel Frame .................................... 1
E. Handle Assembly ....................................... 1
F. Support Leg ................................................ 1
G. Connecting Rod .......................................... 1
H. Gear Box & Axle Assembly ........................ 1
I. Wheels ....................................................... 2
J.
Impeller ....................................................... 1
K. Hairpin Cotter Pin ....................................... 1
L.
Lock Nut M5-.8 ........................................... 1
M. Hex Bolt M5-.8 X 45 ................................... 1
N. Phillips Head Screw M4-.7 X 20 ................ 1
O. Hex Bolts M6-1 X 45 .................................. 2
P. Inner Axle Bushings ................................... 2
Q. Hex Bolts M6-1 X 40 .................................. 4
R. Axle End Covers ........................................ 2
S. Hex Bolts M6-1 X 65 .................................. 4
T.
Lock Nuts M6-1 .......................................... 8
U. Flat Washers 6mm ..................................... 4
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
-1-
COPYRIGHT © DECEMBER, 2007 BY GRIZZLY INDUSTRIAL, INC.
#JM10162 PRINTED IN CHINA
MODEL T10044
80 LB SEED/FERTILIZER
SPREADER
INSTRUCTION SHEET
C
E
D
Figure 1. Inventory 1.
H
J
Figure 2. Inventory 2.
L
K
N
Q
T
Figure 3. Inventory 3.
T10044 80 lb. Seed/Fertilizer Spreader
F
G
I
M
P
O
R
S
U
