CEMENT MIXER
6 CU. FT.
Model 45198
OPERATING INFORMATION
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
Copyright
2001 by Harbor Freight Tools
. All rights reserved. No portion of this manual
©
®
or any artwork contained herein may be reproduced in any shape or form without the ex-
press written consent of Harbor Freight Tools.
For technical questions please call 1-800-444-3353
REV 01/02
Advertisement
Summary of Contents for Vanguard 45198
- Page 1 CEMENT MIXER 6 CU. FT. Model 45198 OPERATING INFORMATION ® 3491 Mission Oaks Blvd., Camarillo, CA 93011 Visit our Web site at http://www.harborfreight.com Copyright 2001 by Harbor Freight Tools . All rights reserved. No portion of this manual © ® or any artwork contained herein may be reproduced in any shape or form without the ex- press written consent of Harbor Freight Tools.
-
Page 2: Specifications Table
SPECIFICATIONS TABLE Weight 690 lb. Capacity 6 Cubic Feet Drum Diameter 28” Pneumatic Wheel Diameter 12” Barrel Pulley 14.5” Gas Engine HP 7.5 HP Gas Engine Pulley 3” Gas Engine Speed 3,600 RPM 20 RPM (Low speed to keep cement from setting) Drum Speeds 36 RPM (Maximum speed for heavy mixing) Less than 25 MPH... -
Page 3: Specific Product Warnings And Precautions
DRESS SAFELY. Nonskid footwear or safety shoes should be used when work- ing with this product. Do not wear loose clothing or jewelry as they can become caught in moving parts. Wear a protective hair covering to prevent long hair from becoming caught in moving parts. - Page 4 PRIOR TO USING THE CEMENT MIXER, MAKE SURE YOU READ AND COM- PLETELY UNDERSTAND THIS INSTRUCTION MANUAL AND THE GAS EN- GINE MANUFACTURER’S INSTRUCTION MANUAL. USE COMMON SENSE WHEN HANDLING GASOLINE. Transport gasoline only in approved safety containers. Do not refuel the Gas Engine with the Engine running or while it is hot.
-
Page 5: Operating Instructions
OPERATING INSTRUCTIONS NOTE: All parts below refer to the parts listed and shown on pages 8 and 9 of this manual. CAUTION: Do not attempt to move the Cement Mixer when it is full and/or in operation. Place the Cement Mixer on a solid, flat, and level surface that is capable of sup- porting the weight of the mixer and it’s load. - Page 6 To discharge the cement mix, grasp the Hand Wheel (51) firmly with one hand and release the Brake Handle (60). Then, slowly turn the Hand Wheel counter- clockwise to empty the Drum (4). CAUTION: To prevent accidental discharge of the cement mix, do not release the Brake Handle without holding the Hand Wheel firmly.
-
Page 7: Maintenance And Cleaning
MAINTENANCE AND CLEANING CAUTION: Never perform any services or maintenance on the Cement Mixer while it is running. Before performing services or maintenance, turn off the en- gine and disconnect the spark plug wire to prevent accidental starting. Before each use, inspect the general condition of the Cement Mixer. Check for loose screws, misalignment, binding of moving parts, loose or broken parts, and any other condition that may affect its safe operation. -
Page 8: Please Read The Following Carefully
PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIA- GRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFAC- TURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY RE- PAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. -
Page 9: Parts List
PARTS LIST SKU 45198 For technical questions, please call 1-800-444-3353. Page 9... -
Page 10: Assembly Diagram
ASSEMBLY DIAGRAM NOTE: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. SKU 45198 For technical questions, please call 1-800-444-3353. Page 10...
