Specifications - Universal Remote Control MRX-10 Owner's Manual

MRX-10 A

Specifications

Input & Outputs:
12V/.2A: Two (Programmable)
IR: Eight adjustable output
USB: One (for future use)
Ethernet: One 10/100 RJ45 port (Indicator 2LED)
RS-232: Four, supporting TX, RX and GND
Sensor: Four, supporting Video or Voltage sensing
(requires URC sensors)
Relays: NO, NC or COM
RF:
Frequency: 2.4GHz (Two-way RF)
Range: 50 to 100 feet, depending upon the environment
Power Supply: 12v DC 3.5A External Power Supply
Size: 1.7" x 17" x 8.7" (H X W x D
Weight: 4.5 lbs. (2.05 Kg)
N
DVANCED ETWORK
Page 4
S C
YSTEM ONTROLLER
